Seite 1/4
Product Registration
Registering your new BDI product allows us to send you important product updates, service information
and helpful hints related to your BDI products. Register today, and you will be entered to win free a BINK
table from BDI: www.bdiusa.com/register
Placement and Maintenance
Your ORLO End Table is designed for indoor use on level floors. Clean wood parts with a moist cloth.
Orlo is engineered for easy assembly. Carefully follow this procedure to prevent any damage.
Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such
as carpet. For missing hardware pieces, contact BDI Customer Service at: customerservice@bdiusa.com.
For all other concerns, please contact your BDI retailer.
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Orlo & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2018, BDI
Patent: www.bdiusa.com/ip
Made in China. 06.04.2018 V1
bdiusa.com
customerservice@bdiusa.com
ORLOTM 1956
END TABLE
A1 Spacer x 2
C2 Lower Shelf x 1
A2 Rear Leg x 2
A3 Front Leg x 1
C1 Upper Shelf x 1
bdiusa.com
customerservice@bdiusa.com
ORLO 1956
END TABLE
2
Step 2 - Attach Spacers to the bottom of the Upper Shelf
Place upper shelf C1 upside down on a non-marring surface. Attach the by screwing the 2 spacers A1
threaded studs into the inserts on the bottom of the Tighten by hand. upper shelf C1.
A1
C1
A1
bdiusa.com
customerservice@bdiusa.com
ORLO 1956
END TABLE
3
Step 3 - Attach Lower Shelf and rear legs
Orient lower shelf C2 so that the threaded insert is facing up and the 2 through holes are positioned above
the 2 spacers A1. Support the with 1 hand and with your other hand thread 1 of the lower shelf C2 rear legs
A2 through the hole and into the insert on the end of the spacer A1 rear leg A2. Align and attach the second .
Tighten both rear legs by hand.
Threaded insert
visible here
C2
A2
A2
A1
A1
