Seite 1/5
C1 Top Panel x 2
A1 Glass Panel x 2
C2 Middle Panel x 2
C3 Bottom Panel x 2
H2 Swivel Locking
Casters x 8
Product Registration
Registering your new BDI product allows us to send you important
product updates, service information and helpful hints related to your BDI
products. Register today, and you will be entered to win free a
BINK table from BDI: www.bdiusa.com/register
Placement and Maintenance
Your Müv Table is designed for indoor use on level floors.
Clean glass with glass cleaner and wood veneer with a moist cloth.
Müv is engineered for easy assembly. Carefully follow this procedure to
prevent any damage. Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, contact BDI Customer Service at: customerservice@bdiusa.com.
For all other concerns, please contact your BDI retailer.
bdiusa.com
customerservice@bdiusa.com
Designed by Matthew Weatherly
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Muv & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2018, BDI
Made in China. 5.17.2019 V5
MÜV™ 1252
Tables
Tool Required:
Phillips Screwdriver
H1 M4 x 12mm
Pan Head Screw x 32
T1 Hex Driver x 1
Component List
bdiusa.com
customerservice@bdiusa.com
MÜV 1252
Table
2
Step 2 - top panel C1Place the (which has a finger groove around the bottom edge as shown). Remove the
protective film from Slide one edge of into the matching glass panel A1. glass panel A1 (with aluminum rail)
slot on bottom side of If the aluminum channel is tight, brace the front edge of the top panel. top panel C1.
Step 3 - Take the and position it as shown until the connectors engage with each other. middle panel C2
Make sure the edges are flush.
C1 Top Panel
A1 Glass Panel
Finger Groove
Wall
bdiusa.com
customerservice@bdiusa.com
MÜV 1252
Table
3
Step 4 - hex driver T1 Place into the access holes at a 45 degree angle and tighten the connectors by turning
clockwise about 1/4 turn until tight. You may need to until the end of the driver engagwiggle the hex driver -
es with the connecting hardware. Tighten all 4 connectors.
Step 5 - bottom panel C3 Orient the as shown and slide it so that the aluminum channel goes into the slot on
bottom panel C3 Wiggle and lift bottom panel C3. Keep sliding until the mitered edges align and touch. to
align the joint and close the seam.
4 access holes
to tighten connectors
C2 Middle Panel
T1 Hex Driver
C3 Bottom Panel
Aluminum Channel
