DESIGNED FOR USE WITH AVIBALL. FOR BT880 STYLE BALL JOINT PRODUCTS
USE BT880-UN2 PROJECTOR MOUNT.
SUITABLE FOR M6, M5, M4 AND M3 MOUNTING HOLES. PLEASE USE THE
APPROPRIATE SCREWS AND WASHERS (PARTS 6 - 16) AS ILLUSTRATED.
THE LEGS (PARTS 4 + 5) CAN BE USED IN ANY NUMBER OR COMBINATION TO
SUIT YOUR PARTICULAR EQUIPMENT.
PARTS 19 - 21 ARE OPTIONAL AND CAN BE USED AS SPACERS AT THE
INSTALLERS DISCRETION. PARTS 22 CAN BE USED INSTEAD OF HAND WHEELS.
No
PART NAME
QTY
No PART NAME QTY
1 CAROUSEL
1 13 M4 PLAIN WASHER 4
2 COVER PLATE HALF
2 14 M3 X 12 SCREW 4
3 HAND WHEEL
4 15 M3 SPRING WASHER 4
4 SHORT LEG
4
16
M3 PLAIN WASHER 4
5 LONG LEG
4
17
M8 SPRING WASHER 1
6 M6 X 12 SCREW
4 18 M8 X 23 SQUARE END
ALLEN SCREW 1
7
M6 SPRING WASHER
4 19 M6 PLAIN WASHER 8
8 M5 X 12 SCREW
4 20 M6*T6 SPACER 4
9 M5 SPRING WASHER
4 21 M6*T3 PLAIN WASHER 4
10 M5 PLAIN WASHER
4 22 M6 DOME NUT 4
11 M4 X 12 SCREW
4 23 5MM ALLEN KEY 1
12 M4 SPRING WASHER
4 24 M6 NUT 4
23
24
3
2
