Seite 1/2
www.atlantis-land.com
ACCESS POINT
Wireless N 300Mbps PoE* MultiFunction
NetFly AP4 W300N+
Modalità WDS per rilanciare il segnale
wireless di un altro apparato compatibile
ampliandone così la copertura
Funzionalità
Virtual Access Point
(Client isolation)
Le dimensione compatte, il supporto al Passive
PoE e la possibilità del montaggio a muro,
rendono il dispositivo di facile collocazione
Configurabile in modalità Access Point
(5 porte F/E LAN) oppure come Router
(4 porte F/E LAN e 1 porta F/E WAN)
2 x 4 dBi
R-SMA Antennas
*Passive
Poe
Wall
Mount KIT
Wireless N
300Mbps
5 x LAN
Ports
Wireless
Distribution
System
Multi SSID
up to 3
Mbps
di throughput
300
www.atlantis-land.com
Wireless N 300Mbps PoE* MultiFunction
NetFly AP4 W300N+
ACCESS POINT
Package Contents • A02-AP4-W300N+ • Power Adapter AC-DC (5V, 1A) • UTP cat. 5 cable (RJ-45 connector), 2 x 4 dBi
Antennas • Quick Start Guide (English, Italian, French) • Cd-Rom contained manual • Warranty Card & WEEE Disclaimer •
Web browser, such as Microsoft Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later
ACCESS POINT
Codice: A02-AP4-W300N+
EAN: 8026974010915
• La conformità alle speciche IEEE 802.11n
(retrocompatibile con 802.11g/b) garantisce
prestazioni velocistiche sino a 10 volte e copertura
tripla rispetto allo standard 802.11g
• Congurabile in modalità Access Point (5 porte F/E
LAN) oppure come Router (4 porte F/E LAN e 1 porta
F/E WAN)
• Sicurezza senza compromessi grazie al supporto
WPA™/WPA2™
• 2 antenne R-SMA da 4 dBi per una copertura estesa
• Funzionalità Virtual AP (client isolation)
• Supporto avanzato per WDS e SSID Multipli (sino a 3)
• Dimensioni compatte, supporto Passive PoE e
possibilità di montaggio a muro
Technical Specifications
Standards IEEE 802.11b/g/n
Chipset Realtek® RTL8196C + RTL8188RE (400Mhz)
Memory 16MB/4MB Flash
Interface 5 x Fast Ethernet [(5 LAN) or (4 LAN
and 1 WAN)]
LED 8 (4 LAN, 1 WAN/LAN, WLAN, CPU, Power)
WPS/Reset ND/Yes
Antenna 2 x 4 dBi R-SMA external Antennas
Virtual AP • Client Isolation
• Multiple SSID
Multiple SSID • Up to 3 SSID (each SSID uses dierent encryption key)
WDS With WDS (Wireless Distribution System) mode, user can
use wireless media to communicate two or more LANs
through the AP with WDS mode, all of the LAN will be
combined in the WDS group.
The WDS feature (up to 4 AP) makes the device an ideal
solution for quickly creating and extending a wireless local
area network (WLAN) in oces or other workplaces, or
even at hotspots.
Advanced Features • DHCP Server/Client
• WMM
• IGMP, UPnP
• Dynamic DNS (TZO, DynDNS)
• PPPoE/DHCP Clients(WAN IP)
• Passive PoE (A02-Adapter3)
• DHCP Static Lease
Green • Realtek Active-ECO power saving mode, and will
dynamically enter various power-down stages based on
the network trac ow, ensuring power consumption is
one of the lowest in the AP/Router industry
• Supports IEEE 802.3az power-down. when there is no
network trac, and also supports Realtek’s ‘Green Eth-
ernet’ (reduces power to suit cable length for maximum
performance with minimum power use).
Operation Mode • Access Point (5 LAN ports)
• Wireless ISP (5 LAN ports/ WAN=WLAN)
• Gateway (4 LAN ports/ WAN=1 LAN port)
Firewall & Security • NAT
(Gateway/ISP Mode) • SOHO Firewall Security with NAT
Technology and Packet Filtering
• SPI, DoS, URL and Application Filter
QoS (Gateway/ISP Mode) • Bandwith Allocation
• Priority Queue
Frequency Band 2412 ~ 2472MHz
Radio Technology • IEEE 802.11g/n: Orthogonal Frequency Division Multiplex-
ing (OFDM)
• IEEE 802.11b: Direct Sequence Spread Spectrum (DSSS)
Modulations Scheme • OFDM: BPSK, QPSK, 16-QAM, 64-QAM
• DBPSK, DQPSK, CCK
Media Access Protocol CSMA/CA with ACK
Transmission Rate Up to 300Mbps (auto-sense with auto fallback)
Wireless Security • 64/128-bit WEP, WPA-PSK, WPA2-PSK
• MAC Filter(AP mode)
• WLAN Partition (AP mode)
• Wireless STA (Client) connected list
(Idle/Connection Time, Pkt statistics)
Transmitting Power • IEEE802.11n/g:
(17dBm@6~9 Mbps / MCS0
17dBm@12~18 Mbps / MCS2
15dBm@24~36 Mbps / MCS4
14dBm@48~54 Mbps / MCS6)
11n HT40 MSC7 : +13.5dBm
• IEEE802.11b: 17.5dBm@1, 11Mbps
Receiver Sensitivity •
IEEE802.11n:
( MCS0 @ -79dBm, MCS7 @ -61dBm) HT40Mhz
•
IEEE802.11g:
(6Mbps@ -90dBm, 54Mbps@ -70dBm)
•
IEEE802.11b:
(1Mbps@ -87dBm, 11Mbps@ -86dBm)
Standard IEEE 802.11n - NetFly AP4W+ è un Access Point multifunzione, con 5 porte LAN, in standard N progettato per soddisfare ogni esigenza sia in ambito domestico, che nella piccola
e media azienda. Il supporto del recente standard N a 300Mbps permette di ottenere un throughput ed una copertura decisamente superiori rispetto ad una rete in standard g. Il dispositivo
garantisce inoltre il pieno supporto hardware, senza nessuna degradazione di performance, degli standard di sicurezza più recenti, come il Wi-Fi Protected Access (WPA/WPA2).
La rete wireless sarà finalmente scattante ed a prova di hacker.
Access Point Multi-Funzione - La funzionalità WDS, utilizzando i più evoluti sistemi di sicurezza, permette, connettendo sino a 4 Access Point, di estendere la copertura wireless anche in zone
remote. La modalità Repeater, ideale in ambito domestico, permette di rilanciare il segnale wireless di un altro apparato ampliandone così la copertura.
La modalità Router (opzionale) permette di aggiungere tra le 2 interfacce (Wireless/Ethernet o LAN/WAN) i servizi NAT e di analisi del traffico quali Firewall e QoS.
Access Point multipli virtuali - Il supporto Multi-SSID e client Isolation permette di creare sino a 3 Access Point virtuali con permessi di accesso diversificati. Le dimensione compatte, il
supporto al Passive PoE e la possibilità del montaggio a muro, rendendo il dispositivo di facile collocazione.
All rights registered. Microsoft and Windows are registered trademarks of Microsoft Corporation. Mac OS X
is a trademark of Apple Inc. All trade names and marks are registered trademarks of respective companies.
Specifications are subjected to change without prior notice. No liability for technical errors and/or omissions.
Network conditions and environmental factors, including volume of network traffic, building materials and
construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely
affect wireless signal range. This product is based on IEEE draft 802.11n specifications and is not guaranteed
to be forward compatible with future versions of IEEE 802.11n specifications. Compatibility with draft 802.11n
devices from other manufacturers is not guaranteed.
Tutti i marchi riportati sono registrati ed appartengono ai rispettivi proprietari. Microsoft e Windows sono mar-
chi registrati di Microsoft Corporation. Mac OS X è un trademark di Apple Inc. Le specifiche riportate possono
cambiare senza preavviso. Nessuna responsabilità per errori e/o omissioni. Le condizioni ambientali e di utilizzo
possono pesantemente influenzare il throughput atteso. I prodotti Wireless N si basano sulle specifiche draft
IEEE 802.11n e la loro compatibilità con le future versioni dello standard IEEE 802.11n non è garantita. La
compatibilità con dispositivi draft 802.11n di altri produttori non è garantita.
Number of
Operational Channel Europe (13)
Range Coverage • Indoor: up to 120 meters
• Outdoor: up to 350 meters
Management • Conguration: Web-based conguration (HTTP)
• Firmware Upgrade: Upgrade rmware via web-browser
(Keep latest setting when f/w update)
• System monitoring: Status, Statistics and Event Log
• SysLog Client
• Bandwidth Measurement (QoS)
• IP range and bandwidth management
• Backup & Restore: Settings through Web
Certications CE (Europe)
Dimensions 150mm x 93mm x 25mm
(mm)/ Weight (without Antenna and plug) / 130g
Temperature Range Operation: 0°C ~ 32°C
Storage: -10°C ~ 60°C
Humidity 10% ~ 75% (non Condensing)
System Requirements •
TCP/IP protocol must be installed on each PC
•
Web browser, such as Microsoft Internet Explorer 5.0 or later,
Netscape Navigator 6.0 or later
2 x 4 dBi
R-SMA Antennas
*Passive
Poe
Wall
Mount KIT
Wireless N
300Mbps
5 x LAN
Ports
Wireless
Distribution
System
Multi SSID
up to 3
WDS
Mode
WDS
Mode
Access Point
Mode
Repeater
Mode
