RT-AX88U Pro
AX6000 Dual Band Wi-Fi Router
Quick
Start Guide
Hardware Explanations
I/O Ports Overview LED Lights Overview
DC Power adapter DC Output: +19.5V with 2.31A current
DC Output: +19V with 2.37A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
Speciîcations:
One Router Setup Steps
Prepare your Modem
01
1
Unplug the power of cable / DSL modem. If it
has a battery backup, remove the battery.
5
Launch [App] ASUS Router App and follow the
instructions to complete the setup.
WE SUGGEST...
Modem back
Install your Router
02
1
Plug the adapter into the DCIN port, and press the Power switch.
2
Connect your modem to WAN port at the back side of the router with the
network cable provided.
3
Power on the modem. Plug modem to the power outlet and power on.
4
Check the modem LED lights to ensure the connection is active.
If you are using DSL for internet,
you will need your username
/ password from your Internet
service provider (ISP) to properly
conîgure your router.
Modem front
â Or via web browser
3
Connect your PC to LAN port at the back side [Wired]
of the router using an additional network cable.
[Wireless] Connect to the network with default SSID shown on
the product label on the back side of your router âASUS_XXâ.
4
[Wired / Wireless] Open a web browser.
You will be redirected to the ASUS Setup Wizard. If not, navigate to
http://www.asusrouter.com.
Follow the instructions to
complete the setup.
îîîîîîî
îîîîîîîîîîîîîîîîîîîî
îîîîî
â Via app
3
On your iOS or Android mobile device, go [App]
to the app store, search forî , and ASUS Router
download the app.
4
On your iOS or Android mobile device, tapî[App] Settings > Wi-Fi, connect
to the default network SSID shown on the product label on the back side of
the router. Or scan the QR code on the product label to connect the default
network SSID.
* XX refers to the last two digits
of MAC address. You can înd
it on the label on the back of
your router.
îîîîîîîîîîîîîîîîîîîî
îîîî_îî
îîîîîîîîîîîîîîîîîîîî
îîîîîîîîîîîîîîîîî
îîîîîîîîîîîîîîîîî
î
îîîîî
5GHz LED
2.5G/1G WAN
LED
LAN LED
WPS LED
USB 3.2 Gen 1
LEDPower LED
2
The power LED will light up when the hardware is ready.
DCIN port
LAN 1-4 ports
WPS button
Reset button
2.5G/1G WAN port USB 3.2 Gen 1 port
Power button
2.5G/1G LAN
port
2.5G/1G LAN
LED
2.4GHz LED
Modem back
http://www.asusrouter.com/
FAQ FREQUENTLY ASKED QUESTIONS
Q1:
Where can I ïŹnd more information about the wireless router?
Technical support site: https://www.asus.com/support
Service and Support
https: www.asus.com/support//
Video Tutorials
https://qr.asus.com/wl_videotutorials
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1 2023/1/18 14:37:39
2023/1/18 14:37:39
2023/1/18 14:37:39
2023/1/18 14:37:392023/1/18 14:37:39
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our
environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other
components, as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed
recycling information in diîerent regions.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we
published the chemical substances in our products at ASUS REACH website at
http://csr.asus.com/english/REACH.htm
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
âą This device may not cause harmful interference.
âą This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception,
which can be determined by turning the equipment oî and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
âą Reorient or relocate the receiving antenna.
âą Increase the separation between the equipment and receiver.
âą Connect the equipment into an outlet on a circuit diîerent from that to which the receiver is connected.
âą Consult the dealer or an experienced radio/TV technician for help.
WARNING! Any changes or modiîcations not expressly approved by the party responsible for compliance could
void the userâs authority to operate the equipment.
Prohibition of Co-location
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.
IMPORTANT NOTE:
Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the speciîc operating instructions for satisfying RF exposure compliance. To maintain
compliance with FCC exposure compliance requirement, please follow operation instruction as documented in this manual.
This device is restricted for indoor use.
WARNING! This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 51cm from all
persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
This device is restricted for indoor use.
Compliance Statement of Innovation, Science and Economic Development Canada (ISED)
This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Operation in the band 5150â5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel
mobile satellite systems.
CAN ICES-003(B)/NMB-003(B)
Radio Frequency (RF) Exposure Information
The radiated output power of the ASUS Wireless Device is below the Innovation, Science and Economic Development
Canada radio frequency exposure limits. The ASUS Wireless Device should be used in such a manner such that the potential
for human contact during normal operation is minimized.
This equipment should be installed and operated with a minimum distance of 31cm between the radiator any part of your
body.
This device has been certiîed for use in Canada. Status of the listing in the Innovation, Science and Economic Development
Canadaâs REL (Radio Equipment List) can be found at the following web address:
http://www.ic.gc.ca/eic/site/ceb-bhst.nsf/eng/h_tt00020.html
Additional Canadian information on RF exposure also can be found at the following web:
https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Déclaration de conformité de Innovation, Sciences et Développement économique Canada (ISED)
Le prĂ©sent appareil est conforme aux CNR dâInnovation, Sciences et DĂ©veloppement Ă©conomique Canada applicables
aux appareils radio exempts de licence. Lâexploitation est autorisĂ©e aux deux conditions suivantes : (1) lâappareil ne doit
pas produire de brouillage, et (2) lâutilisateur de lâappareil doit accepter tout brouillage radioĂ©lectrique subi, mĂȘme si le
brouillage est susceptible dâen compromettre le fonctionnement.
La bande 5150 â 5250 MHz est rĂ©servĂ©e uniquement pour une utilisation Ă lâintĂ©rieur aîn de rĂ©duire les risques de
brouillage prĂ©judiciable aux systĂšmes de satellites mobiles utilisant les mĂȘmes canaux.
CAN ICES-003(B)/NMB-003(B)
Informations concernant lâexposition aux frĂ©quences radio (RF)
La puissance de sortie Ă©mise par cet appareil sans îl est infĂ©rieure Ă la limite dâexposition aux frĂ©quences radio dâInnovation,
Sciences et DĂ©veloppement Ă©conomique du Canada (ISED). Utilisez lâappareil sans îl de façon Ă minimiser les contacts
humains lors dâun fonctionnement normal.
Cet Ă©quipement doit ĂȘtre installĂ© et utilisĂ© avec un minimum de 31cm de distance entre la source de rayonnement et votre
corps.
Lâutilisation de cet appareil est autorisĂ©e au Canada. Pour consulter lâentrĂ©e correspondant Ă lâappareil dans la liste
dâĂ©quipement radio (REL - Radio Equipment List) dâInnovation, Sciences et DĂ©veloppement Ă©conomique du Canada,
rendez-vous sur : http://www.ic.gc.ca/eic/site/ceb-bhst.nsf/eng/h_tt00020.html
Pour des informations supplĂ©mentaires concernant lâexposition aux frĂ©quences radio au Canada, rendez-vous sur :
https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
For indoor use only.
Pour une utilisation en intérieur uniquement.
This radio transmitter [3568A-RTAX6800] has been approved by Innovation, Science and Economic Development Canada to
operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in
this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this
device.
Le présent émetteur radio (3568A-RTAX6800) a été approuvé par Innovation, Sciences et Développement économique
Canada pour fonctionner avec les types dâantenne Ă©numĂ©rĂ©s ci-dessous et ayant un gain admissible maximal dâantenne.
Les types dâantennes non inclus dans cette liste qui ont un gain supĂ©rieur au gain maximal indiquĂ© pour tout type listĂ© sont
strictement interdits pour une utilisation avec cet appareil.
Ant. Brand Name Model Name Antenna Type 2.4GHz 5GHz
UNII 1 UNII 2A UNII2C UNII3
1 PSA RFDPA171300SBLB820 Dipole 2.01 2.66 2.74 3.53 3.93
2 PSA RFDPA171300SBLB820 Dipole 1.25 1.8 1.59 2.37 2.6
3 PSA RFDPA171300SBLB820 Dipole 1.61 2.05 1.47 2.32 2.49
4 PSA RFDPA171300SBLB820 Dipole 1.81 2.7 1.47 3.17 3.83
The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the
equipment still complies with the e.i.r.p. limit.
le gain maximal dâantenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et 5470-5725 MHz doit se
conformer Ă la limite de p.i.r.e.
The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still
complies with the e.i.r.p. limits speciîed for point-to-point and non-point-to-point operation as appropriate.
le gain maximal dâantenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz) doit se conformer Ă la limite de
p.i.r.e. spĂ©ciîĂ©e pour lâexploitation point Ă point et non point Ă point, selon le cas.
Safety Notices
⹠Use this product in environments with ambient temperatures between 0°C(32°F) and 40°C(104°F).
âą Refer to the rating label on the bottom of your product and ensure your power adapter complies with this rating.
âą DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has been damaged.
âą DO NOT place or drop objects on top and do not shove any foreign objects into the product.
âą DO NOT expose to or use near liquids, rain, or moisture. DO NOT use the modem during electrical storms.
âą DO NOT cover the vents on the product to prevent the system from getting overheated.
âą DO NOT use damaged power cords, accessories, or other peripherals.
âą If the Adapter is broken, do not try to îx it by yourself. Contact a qualiîed service technician or your retailer.
âą To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
âą DO NOT mount this equipment higher than 2 meters.
Avertissements de sécurité
âą Utilisez ce produit dans un environnement dont la tempĂ©rature ambiante est comprise entre 0ËC (32°F) et 40ËC (104°F).
âą RĂ©fĂ©rez-vous Ă l'Ă©tiquette situĂ©e au dessous du produit pour vĂ©riîer que l'adaptateur secteur rĂ©pond aux exigences de
tension.
⹠NE PAS placer sur une surface irréguliÚre ou instable. Contactez le service aprÚs-vente si le chùssis a été endommagé.
⹠NE PAS placer, faire tomber ou insérer d'objets sur/dans le produit.
⹠NE PAS exposer l'appareil à la pluie ou à l'humidité, tenez-le à distance des liquides. NE PAS utiliser le modem lors d'un
orage.
âą NE PAS bloquer les ouvertures destinĂ©es Ă la ventilation du systĂšme pour Ă©viter que celui-ci ne surchauîe.
⹠NE PAS utiliser de cordons d'alimentation, d'accessoires ou autres périphériques endommagés.
âą Si l'adaptateur est endommagĂ©, n'essayez pas de le rĂ©parer vous-mĂȘme. Contactez un technicien Ă©lectrique qualiîĂ© ou
votre revendeur.
⹠Pour éviter tout risque de choc électrique, débranchez le cùble d'alimentation de la prise électrique avant de toucher au
systĂšme.
⹠Ne placez pas cet appareil à une hauteur supérieure à 2 mÚtres.
InformaciĂłn de seguridad
âą Use este producto en entornos sometidos a una temperatura ambiente comprendida entre 0 ËC (32 ËF) y 40 ËC (104 ËF).
âą Consulte la etiqueta de valores nominales situada en la parte inferior del producto y asegĂșrese de que su adaptador de
alimentaciĂłn cumple con dichos valores.
âą NO coloque el equipo sobre una superîcie irregular o inestable. Solicite asistencia tĂ©cnica si la carcasa resulta dañada.
⹠NO coloque ni deje caer objetos en la parte superior del producto y no introduzca objetos extraños dentro de él.
âą NO exponga el equipo a lĂquidos, lluvia o humedad, ni lo use cerca de ninguno de tales elementos. NO use el mĂłdem
durante tormentas eléctricas.
âą Para evitar que el sistema se sobrecaliente, no cubra las ranuras de ventilaciĂłn del producto.
âą NO cubra los oriîcios de ventilaciĂłn del equipo de sobremesa para evitar que el sistema se caliente en exceso.
âą No intente reparar la fuente de alimentaciĂłn personalmente si se averĂa. PĂłngase en contacto con un tĂ©cnico de
mantenimiento autorizado o con su distribuidor.
âą A în de evitar posibles descargas elĂ©ctricas, desconecte el cable de alimentaciĂłn de la toma de suministro elĂ©ctrico antes
de cambiar la posiciĂłn del sistema.
âą NO monte este equipo a una altura superior a 2 metros.
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2 2023/1/18 14:37:40
2023/1/18 14:37:40
2023/1/18 14:37:40
2023/1/18 14:37:402023/1/18 14:37:40
Produktspezifikationen
| Marke: | Asus |
| Kategorie: | Router |
| Modell: | RT-AX88U Pro |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Asus RT-AX88U Pro benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Router Asus
12 September 2024
11 September 2024
3 September 2024
29 August 2024
21 August 2024
20 August 2024
18 August 2024
14 August 2024
12 August 2024
12 August 2024
Bedienungsanleitung Router
- Router Acer
- Router Anker
- Router Belkin
- Router Gembird
- Router Gigabyte
- Router Hama
- Router HP
- Router Manhattan
- Router Medion
- Router Sweex
- Router Trust
- Router Clas Ohlson
- Router Makita
- Router ZyXEL
- Router Bosch
- Router Alfa
- Router Buffalo
- Router TechniSat
- Router Allnet
- Router Devolo
- Router Eminent
- Router Linksys
- Router Netgear
- Router Telekom
- Router König
- Router Thomson
- Router Black And Decker
- Router Schneider
- Router DeWalt
- Router Einhell
- Router Festool
- Router Topcom
- Router Nilox
- Router Motorola
- Router Xiaomi
- Router EZVIZ
- Router Hikoki
- Router Hitachi
- Router TCL
- Router Metabo
- Router Zoom
- Router Netis
- Router Aruba
- Router Lindy
- Router MSI
- Router Mercusys
- Router TRENDnet
- Router Sagem
- Router Sigma
- Router Western Digital
- Router AVM
- Router Zebra
- Router EnVivo
- Router TP-Link
- Router Kathrein
- Router Silverline
- Router Alcatel
- Router Black Box
- Router Milwaukee
- Router Huawei
- Router Nest
- Router Edimax
- Router DrayTek
- Router Eumex
- Router Technicolor
- Router Totolink
- Router Kogan
- Router Conceptronic
- Router D-Link
- Router T-Mobile
- Router QNAP
- Router Icidu
- Router Vodafone
- Router Powerplus
- Router Lancom
- Router LevelOne
- Router Beafon
- Router Phicomm
- Router ZTE
- Router Cisco
- Router Tenda
- Router Kasda
- Router Ubiquiti Networks
- Router Synology
- Router Kopul
- Router Kramer
- Router Intellinet
- Router Asrock
- Router AJA
- Router Hikvision
- Router Patton
- Router Nexxt
- Router Planet
- Router AT&T
- Router EnGenius
- Router Mikrotik
- Router Teltonika
- Router Porter-Cable
- Router Google
- Router Comtrend
- Router Davolink
- Router Digiconnect
- Router KPN
- Router Mercku
- Router On Networks
- Router PENTAGRAM
- Router Proximus
- Router Sitecom
- Router SMC
- Router Tele 2
- Router Telstra
- Router Ubee
- Router United Telecom
- Router UPC
- Router Verizon
- Router Vimar
- Router Cudy
- Router Siig
- Router RGBlink
- Router StarTech.com
- Router Kraun
- Router AirLive
- Router Smart-AVI
- Router Dahua Technology
- Router Gefen
- Router Atlantis Land
- Router Cradlepoint
- Router Multitech
- Router Arris
- Router ATen
- Router KanexPro
- Router SPL
- Router Advantech
- Router RAVPower
- Router Digicom
- Router BZBGear
- Router Brickcom
- Router 3Com
- Router B&B Electronics
- Router Eero
- Router Atlona
- Router WyreStorm
- Router AVMATRIX
- Router Alfatron
- Router Key Digital
- Router Rosewill
- Router HiRO
- Router Ocean Matrix
- Router AVPro Edge
- Router Blustream
- Router Dovado
- Router Mach Power
- Router ComNet
- Router MuxLab
- Router Avenview
- Router Netcomm
- Router Allied Telesis
- Router A-NeuVideo
- Router Sixnet
- Router OneAccess
- Router Cambium Networks
- Router Lantronix
- Router Sabrent
- Router Shinybow
- Router Starlink
- Router Actiontec
- Router Billion
- Router Intelix
- Router 7inova
- Router Nexaira
- Router FSR
- Router Amped Wireless
- Router Ruckus Wireless
- Router Milesight
- Router PulseAudio
- Router Predator
- Router Comprehensive
- Router Digitalinx
- Router Luxul
- Router Silentwind
- Router Keezel
Neueste Bedienungsanleitung fĂŒr -Kategorien-
16 September 2024
16 September 2024
16 September 2024
15 September 2024
15 September 2024
15 September 2024
15 September 2024
12 September 2024
12 September 2024
12 September 2024
