Seite 1/11
AW 5.2T+
AW 8.2T+
AW 3.2PAW 2.1P
AW 8.2T+ / AW 5.2T+
mounting bracket
AW 2.1 P / AW 3.2P
mounting bracket
1
AW 2.1P
2-inch wall-mount speakers
AW 3.2P
3-inch 2-way wall-mount
speakers
AW 5.2T+
5-inch 2-way wall-mount
speakers
AW 8.2T+
8-inch 2-way wall-mount
speakers
Operating and
Installation Manual
Tilt-swivel mountsAW-Series
2
AW Series wall-mount speaker Operating Manual
1. Heed all warnings; follow all instructions.
2. Refer all servicing to qualified personnel.
Servicing is required when the apparatus has
been damaged in any way.
Installation and Mounting
3. To prevent inductive effects from causing
hum, noise, loudspeaker lines should not
be laid together with other electric cables,
microphone or line level signal cables
connected to amplifier inputs.
4. To ensure proper sound reproduction,
correct loudspeaker phase is necessary.
Check “ ” and “ ” polarity at both the + −
amplifiers and the AW Series speakers.
5. Make sure loudspeaker lines are not shorted
before turning the amplifier on.
6. The entire audio system must comply with
the current local standards and regulations
regarding electrical systems.
7. Ashly recommends this product only
be permanently installed by licensed,
professional installers (or specialized firms)
who can ensure a correct installation and
certified by a local inspector.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Use only with mounts or brackets specified
by Ashly Audio.
10. Check the suitability of the support surface
to which the product is anchored (wall,
ceiling, structure, etc.) and the attachment
components (wall plugs, screws, brackets
etc.) to confirm that they are in compliance
with requirements set forth by local building,
safety and electrical codes.
11. Make sure all connections have been made
correctly and the loudspeaker input voltage
is suitable for the amplifier output.
12. Protect loudspeaker lines from damage.
Make sure they are positioned in a way that
they cannot be stepped on or crushed by
objects.
13. Make sure that no objects or liquids can get
into this product, as this may cause a short
circuit.
14. If used with the SP 12.1P subwoofer, make
sure that it is placed on a flat, rigid and anti-
skid surface.
Tilt - Swivel Mount
15. Please use the appropriate Tilt-Swivel
mount packed with each AW speaker.
16. For AW 3.2P, 5.2T+ and 8.2T+, make sure
that the safety cable is securely attached.
Operation
17. AW wall-mount speakers can deliver high
sound pressure that can surpass 90dB.
Exposure to high sound levels can cause
permanent hearing loss. Monitor and control
the volume at all times.
Safety and Operation Precautions.
18. If amplifiers or other connected equipped
displays “clipping”, “peak” or other overload
conditions, adjust to assure these are
operating below that threshold to prevent a
distorted signal, which may cause damage
to the speakers.
19. To avoid clipping, always use a clip limiter
if available. Always observe specified high
pass filtering recommendations, failure to
do so may result in damage to drivers.
20. Contact your authorized service center
or qualified personnel should any of the
following occur:
The loudspeaker does not function
normally).
The cable has been damaged.
Objects or liquids have gotten into the unit.
The loudspeaker has been damaged due to
heavy impacts.
21. Clean only with a dry cloth. Do not use
solvents, alcohol, benzene or other volatile
substances for cleaning the external parts of
this product.
22. Don’t unplug signal cables when the amp
connected to your AW Series speakers is still
on.
23. Don’t remove the metal grid of speaker,
which can cause damage to the speaker
cones.
24. Make sure to limit the number of connected
speakers to match the amplifier’s minimum
safe operating impedance.
Contents
Back Panel Connections .................................4
Typical AW 2.1 or AW 3.2P Connections.........5
AW 5.2T+ or AW 8.2T+ Connections ..............6
Ashly AquaControl and ProtℱĂȘaℱ software
presets for AW Speakers .................................7
AW Series Mounting Brackets. ......................8
AW 2.1P & AW 3.2P bracket ............................8
AW 5.2T+ & AW 8.2T+ bracket ........................9
AW Series Specifications 10
3
AW Series wall-mount speaker Operating Manual
AW Series
4-sizes from 2” to 8”
High-strength yet light ABS/
polypropylene enclosure
Enhanced sound with ProtĂȘa and
AquaControlℱ presets via selected Ashly
power amplifiers and DSP processors
Tilt-swivel mount provided
Available in Black or White
(except AW 3.2P and AW2.1P - Available
in black only)
Thank you for choosing Ashly AW Series wall-
mount speakers (and hopefully our matching
subwoofer). We know that there are many
choices on the market today; so we have worked
hard to create wall-mount speakers that set
themselves apart from the rest.
Outside, AW’s are perfect for balconies and
patios. Inside, this is the speaker that will deliver
great sound and tasteful design to restaurant
dining rooms and waiting areas, bars, lounges,
church foyers and crying rooms
anywhere you
need high intelligibility and smooth sound quality
in a small package.
