Areca ARC-8050T3U-4 Bedienungsanleitung
Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Areca ARC-8050T3U-4 (169 Seiten) in der Kategorie Server. Dieser Bedienungsanleitung war für 10 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/169
ARC-8050T3U
(4/6/8/12-bays ThunderboltTM 3 RAID Storage)
User Manual
Version: 2.5
Issue Date: June, 2022
Thunderboltâ„¢ Prod
uct
Copyright and Trademarks
The information regarding products in this manual is subject to change
without prior notice and does not represent a commitment on the part
of the vendor, who assumes no liability or responsibility for any errors
that may appear in this manual. All brands and trademarks are the
properties of their respective owners. This manual contains materials
protected under International Copyright Conventions. All rights
reserved. No part of this manual may be reproduced in any form or by
any means, electronic or mechanical, including photocopying, without
the written permission of the manufacturer and the author.
FCC Statement
This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against in-
terference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation.
Manufacturer’s Declaration for CE Certication
We conîš¿rm ARC-8050T3U series has been tested and found com-
ply with the requirements set up in the council directive on the ap-
proximation of the low of member state relating to the EMC Direc-
tive2004/108/EC. For the evaluation regarding to the electromagnetic
compatibility, the following standards where applied:
EN 55022: 2006, Class B
EN 61000-3-2: 2006
EN 61000-3-3: 1995+A1: 2001+A2: 2005
EN 55024:1998+A1:2001=A2:2003
IEC61000-4-2: 2001
IEC61000-4-3: 2006
IEC61000-4-4: 2004
IEC61000-4-5: 2005
IEC61000-4-6: 2006
IEC61000-4-8: 2001
IEC61000-4-11: 2004
Contents
1. Introduction 8 ................................................................
1.1 Overview 8 .........................................................................
1.2 Features 10 ........................................................................
2. Installation 13 ................................................................
2.1 Before You First Installing................................................. 13
2.2 Summary of RAID Storage Setup Steps .............................. 14
• For macOS .................................................................... 14
• For Windows .................................................................. 15
2.3 RAID Storage View 16 ..........................................................
2.4 Setting Up RAID Storage .................................................. 23
2.4.1 Physically Install RAID Storage and Drives 23 .....................
2.4.2 Mac Users ................................................................. 32
2.4.2.1 Install Areca driver for Mac 32 .....................................
2.4.2.2 Install the MRAID Utility ......................................... 38
2.4.2.3 Conîš¿gure RAID Volumes ......................................... 43
2.4.2.4 Format and Partition RAID Volumes 46 ..........................
2.4.2.5 Make A Bootable RAID Volume 48 ................................
2.4.2.6 Unmounting RAID Volumes ..................................... 48
2.4.3 Windows Users .......................................................... 50
2.4.3.1 Install the Thunderbolt Software 50 ..............................
2.4.3.2 Conîš¿gure RAID Volumes ......................................... 54
2.4.3.3 Format RAID Volumes 57 ............................................
2.4.3.4 Unmounting RAID Volumes ..................................... 57
3. ArcHTTP Conîš¿guration .............................................. 59
• General Conguration ..................................................... 59
• Mail (Alert by Mail) Conguration ..................................... 60
• SNMP Traps Conguration ............................................... 61
• Rescan Device Conguration ............................................ 63
• Collect Support Data 63 ......................................................
4. Web Browser-based Conîš¿guration ........................... 64
4.1 Start-up McRAID Storage Manager 65 ....................................
• McRAID Storage Manager from Local Administration (In-Band)
...................................................................................... 65
• McRAID Storage Manager Through LAN Port (Out-of-Band) 66 ..
4.2 McRAID Main Window 66 ......................................................
4.3 Main Menu 67 ....................................................................
4.4 Quick Function 67 ................................................................
