Seite 1/124
ARC-8050T2
(Thunderbolt 2 to 6Gb/s SAS RAID Storage)
User Manual
Version: 2.2
Issue Date: December, 2014
Thunderboltâ„¢ Prod
uct
Copyright and Trademarks
The information regarding products in this manual is subject to change
without prior notice and does not represent a commitment on the part
of the vendor, who assumes no liability or responsibility for any errors
that may appear in this manual. All brands and trademarks are the
properties of their respective owners. This manual contains materials
protected under International Copyright Conventions. All rights
reserved. No part of this manual may be reproduced in any form or by
any means, electronic or mechanical, including photocopying, without
the written permission of the manufacturer and the author.
FCC Statement
This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against in-
terference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation.
Manufacturer’s Declaration for CE Certication
We conî‚¿rm ARC-8050T2 has been tested and found comply with the
requirements set up in the council directive on the approximation of
the low of member state relating to the EMC Directive2004/108/EC.
For the evaluation regarding to the electromagnetic compatibility, the
following standards where applied:
EN 55022: 2006, Class B
EN 61000-3-2: 2006
EN 61000-3-3: 1995+A1: 2001+A2: 2005
EN 55024:1998+A1:2001=A2:2003
IEC61000-4-2: 2001
IEC61000-4-3: 2006
IEC61000-4-4: 2004
IEC61000-4-5: 2005
IEC61000-4-6: 2006
IEC61000-4-8: 2001
IEC61000-4-11: 2004
Contents
1. Introduction 8 ................................................................
1.1 Overview .........................................................................8
1.2 Features 10 ........................................................................
2. Installation 12 ................................................................
2.1 Before You First Installing................................................. 12
2.2 Summary of RAID Storage Setup Steps .............................. 13
• For Mac OS X 13 .................................................................
• For Windows 13 ..................................................................
2.3 RAID Storage View 15 ..........................................................
2.4 Locations of the Storage Component .................................. 16
2.4.1 Drive Tray LED Indicators 16 ............................................
2.4.2 LCD Panel LED Indicators 17 ............................................
2.4.3 Thunderbolt Port LED Indicators 17 ...................................
2.5 Setting Up RAID Storage .................................................. 18
2.5.1 Physically Install RAID Storage and Drives ..................... 18
2.5.2 Mac Users 22 .................................................................
2.5.2.1 Install the MRAID Software 22 .....................................
2.5.2.2 Congure RAID Volumes ......................................... 26
2.5.2.3 Format RAID Volumes 29 ............................................
2.5.2.4 Make A Bootable RAID Volume 31 ................................
2.5.2.5 Unmounting RAID Volumes 31 .....................................
2.5.3 Windows Users 32 ..........................................................
2.5.3.1 Install the MRAID Software 32 .....................................
2.5.3.2 Congure RAID Volumes ......................................... 36
2.5.3.3 Format RAID Volumes 39 ............................................
2.5.3.4 Unmounting RAID Volumes 39 .....................................
3. ArcHTTP Conguration .............................................. 41
• General Conguration ..................................................... 41
• Mail (Alert by Mail) Conguration ..................................... 42
• SNMP Traps Conguration ............................................... 43
• Rescan Device Conguration ............................................ 45
• Collect Support Data 45 ......................................................
4. Web Browser-based Conguration ........................... 46
4.1 Start-up McRAID Storage Manager 47 ....................................
• McRAID Storage Manager from Local Administration (In-Band)
...................................................................................... 47
• McRAID Storage Manager Through LAN Port (Out-of-Band) .. 48
