Product Manual
English
Foreword
Thank you for purchasing Light Octadome 120.
Light Octadome 120 is designed for LS 120d II,LS 300d II,LS 300X，
LS 600d Pro,Amaran 60,Amaran 100 and Amaran 200 series.
And also compatible with other Bowens Mount LED video light.
Check list
When you unbox the product, please make sure all the items listed
below are included. Otherwise, please contact the seller immediately.
According to the diagonal installation method, insert the eight
support rods, then lock the chuck, and fit the velcro on the softbox,
then install the softbox on the lamp.
Tips: The illustrations in the manual are only diagrams for reference. Due to the continuous
development of new versions of the product, if there are any differences between the product
and the user manual diagrams, please refer to the product itself.
Use Velcro to install the on the diffuser.Fabric Light Control Grid
Trademarks
Bowens is a trademark registered by Bowens in China and other
countries.
Disassembly: Pull out eight steel rods diagonally and in the opposite
direction
Speed Ring Adapter (1pc)
Installations
When using this unit, basic safety precautions should always be
followed, including the following:
4. Care must be taken when touching, installing or disassembling
the elastic support rod.
5. Let the fixture cool completely before storing.
6. To reduce the risk of injury, please install or disassemble the fixture
properly.
7.The use of an accessory attachment not recommended by the
manufacturer may increase the risk of fire, electric shock, or injury
to any persons operating the fixture.
8. Please do not place the fixture near any liquids or other
flammable objects.
9. Only use a dry microfiber cloth to clean the product.
10.This product is certified by RoHS. Please operate the product
in full compliance with the operation standards.
Please note that this warranty does not apply to repairs arising
from malfunctions, although you may request such repairs on a
chargeable basis.
IMPORTANT SAFETY INSTRUCTIONS
1. Read and understand all instructions before using.
2. Close supervision is necessary when any fixture is used by or
near children. Do not leave the fixture unattended while in use.
3. Care must be taken as burns can occur from touching hot surfaces.
11. The instructions and information in this manual are based on
thorough, controlled company testing procedures. Further notice
will not be given if the design or specifications change.
SAVE THESE INSTRUCTIONS
Light Octadome 120 softbox (1pc)
Inside Fabric Diffusion
(1pc) (1pc 1.5 Stop Diffusion,
1pc 2.5 Stop Diffusion)
Front Fabric Diffusion
Fabric Light Control Grid
（1pc）
Light Octadome 120
Carrying Bag (1pc)
Detailed product manual can be found on www.aputure.com.
Specifications
Item Dimension Net Weight
1705g
φ120cm*53.5cm/φ47.24in*21.06in
76x15x3cm/30*5.9*1.18in
φ120cm/φ47.24in
φ120cm/φ47.24in
φ120*5.3cm/φ47.24*2.08in
Standard Bowens Mount
softbox(built)
softbox(Collapsed)
Front Fabric Diffuser 1 1.5 stop( )
Front Fabric Diffuser 2 2.5 stop( )
φ34cm/13.6in
Inside Fabric Diffusion
Fabric Light Control Grid
Speed Ring Adapter
Aputure Imaging Industries Co., Ltd.
Add: F/3, Building 21, Longjun industrial estate,
HePing West Road, Shenzhen, Guangdong
E-MAIL: cs@aputure.com
Sales Contact: (86)0755-83285569-613
Aputure Imaging Industries Co., Ltd. warrants the original consumer purchaser
from defects in material and workmanship for a period of one (1) year after the
date of purchase. For more details of warranty visit www.aputure.com
Serial No.
Item Name
Purchase Date
Buyer Name
Buyer Phone
Buyer Add
Franchiser Seal
Add F/3, Building 21, Longjun Industrial Estate, Heping West Road, Shenzhen, Guangdong:
Aputure Imaging Industries Co.,Ltd.
Inspection: Qualified
2
1
2
1
3
1
2
(Inside diameter 107cm/42.1in)
(Inside diameter 107cm/42.1in)
(Inside diameter 107cm/42.1in)
(Inside diameter 107cm/42.1in)
深圳市爱图仕影像器材有限公司
地址：广东省深圳市龙华和平西路部九窝龙军工业区21栋3楼
邮箱：cs@aputure.com
销售热线：0755-83285569-613
服务热线：400-0999-028
保修条款(中文)
本公司对产品第一买主客户提供为期一年的质量保证期。质保内
容和细节，请登陆我们的网站www.aputure.cn。
重要说明：
请保留您原始购买单据及保修卡，确定您购买的供应商资料都在
此单据，同时包括您的购买日期，产品序列号等，这些资料质保服务
时都会需要提供。
质保范围不包括：
产品不当使用，破坏，意外，错误接线，不良或失调的外接装置，
不适合的外接装置所造成的损坏（包括暴露于雨水等损坏），不
在质保范围。
自购买日30天后产品外观的损伤，或是不当的表面处理接触造
成的外观损伤，不在质保范围。
经销商运送所造成的损坏，不在质保范围。
产品序列号标识已经被撕去或无法辨识，本质保条款无效。
产品未经本公司或者指定授权维修公司的检修及改装，本质保
条款无效。
质保无效说明：
折页成型（英文在正面）：
为折线(不印刷) 226 说明书-增加规格参数 AP-226-PR-01
20220224
Tina
版 本 V1.2
深圳市爱图仕影像器材有限公司
540*140mm 折页尺寸：90*140mm
70g 书纸，正反两面印刷
料号：PA0226MAN74Z
中 文
您可以在本公司网站 www.aputure.cn中找到本设备的详细使用者指南。
内部柔光布 (1pc)
2
1
1
22
1
3
外部柔光布
