Ass embly inst ru ct ions
Anthro Corporation® | 10450 SW Manhasset Dr. | Tualatin, OR 97062
Toll-free: 800.325.3841 | Fax: 800.325.0045 | email: sales@anthro.com | anthro.com
Outside the U.S. | Tel: 503.691.2556 | Fax: 503.691.2409
Zido® Adjustable-Height Cart
Rev K, January 2011
Zido Adjustable, NO LIP Part#
Adjustable, Heavy Load, 22" w ZAH22SB/CG4
Adjustable, Heavy Load, 25" w ZAH25SB/CG4
Adjustable, Light Load, 22" w ZAL22SB/CG4
Adjustable, Light Load, 25" w ZAL25SB/CG4
Zido Adjustable, WITH LIP Part#
Adjustable, Heavy Load, 22" w ZLH22SB/CG4
Adjustable, Heavy Load, 25" w ZLH25SB/CG4
Adjustable, Light Load, 22" w ZLL22SB/CG4
Adjustable, Light Load, 25" w ZLL25SB/CG4
WELC O ME
Thank you for purchasing this Zido
Height-adjustable cart!
If you have any questions or if we
can help you in any way, please
contact us at 800.325.3841.
PARTS L IST
Before beginning assembly of your Zido Height-adjustable
Cart, please review the parts list to verify that your shipment
is complete.
2
Product Quantity Part Number
01 Cap Shelf 1
For small cart, no lip 101-1025-06-50
For small cart, with lip 101-1072-03-50
For large cart, no lip 101-1026-06-50
For large cart, with lip 101-1073-03-50
02 Cap Shelf Bracket 1 225-2620-51
03 Base
For Small Cart 1 250-5064-52
For Large Cart 1 250-5065-52
04 Column
For Light Load Cart 1 835-5290-00
For Heavy Load Cart 1 835-5291-00
05 4" Non-locking Caster 2 150-5010-03
06 4" Locking Caster 2 150-5011-03
07 Release Lever and Paddle 1 835-5393-00
08 Lock Nut 4 325-5263-00
09 1" Cap Screws 4 325-5537-00
10 3/4" Flat-head Patch Screws 2 325-5466-00
11 3/4" Wood Screws 8 325-5106-000
12 3/16" Hex Key (not shown) 1 375-5028-00
13 5/32" Hex Driver (not shown) 1 375-5000-00
09
10
11
01
02
03
04
06
05
07
08
Zido Height-adjustable Carts Assembly Instructions 3
STEP 1A
Connect the Base with the Tube
¡ The column of your Zido cart comes with
two fasteners installed at the base to keep
the column components in place during
transit. Using the 5/32" hex driver provided,
remove those screws and discard them.
¡ Holding the column from the center (don't push from
the top) slide the tube into the base so that the tube
goes all the way to the bottom of the base.
¡Align the upper hole on the base with a threaded
hole in the column. (For the large cart, you'll use
the top hole; for the small cart, you'll use the second
hole.) Loosely attach the column to the base with the
second 3/4" Flat-head Screw.
STEP 1B
Insert the Casters
¡ Place Zido on its side. Add the locking casters
(the ones with the brakes) to the front of the
base assembly. Add the non-locking casters
to the back of the base assembly.
¡Use the 3/16" Hex Key to tighten the
adjustment screw at the bottom of the
column. Turn Zido right side up.
ASSEMBLY SEQUENC E
Plan out the assembly sequence to make your installation easier.
1. Pre-drill the top for accessories (Mouse Holder, Side Bin, Gel Cup/Probe Holder, Extension Tube).
2. Assemble the cart.
3. Base Storage Shelf.
4. Drawer, Keyboard Drawer, Handle.
5. SideRacks, Additional Shelves, Equipment Shelves, Metal Bin, IV bracket, SideRack.
6. Cable Bin, Glove Box Holder, Tank Holder.
7. Mouse Holder, Side Bin, Gel Cup Probe Holder, Extension Tube.&
8. Pole Cart Handle, 8" Handle, Flat Panel Mounts.
Adjustment Screw
3/4" Flat Hd Screw
325-5466-00
