TECHNOLOGY FURNITUREÂź
Trolley Cart
Assembly Instructions
01â Trolley Trunk Assembly (X) ..........Qty. 1 .................................................
TR18zz/xx.............................................................................. 835-5018-00
TT18zz/xx .............................................................................. 835-5401-00
02â 5â Total Lock Casters ................. Qty. 2 150-5081-00 ....................
03â 5/16-18 Button Head Screw ....... Qty. 16 325-5188-00 ..................
04â 5/16-18 X 1â Tube Screws ........... Qty. 4 325-5136-00 ....................
05â 5â Swivel Lock Casters .............. Qty. 2 150-5080-00 ....................
06â Trolley Trunk Covers ........................ Qty. 2 ................................................
TR18zz/xx..............................................................................225-5753-00
TT18zz/xx ..............................................................................225-4278-00
07â 18.25â Lower Cross Tube ............... Qty. 1 125-5244-xx ......................
08â Trolley Trunk Assembly (Y) ..........Qty. 1 .................................................
TR18zz/xx.............................................................................. 835-5019-00
TT18zz/xx .............................................................................. 835-5402-00
09â 12â Upper Cross Tube ............... Qty. 1 125-5243-00 .....................
10â Trolley Cable Wraps .........................Qty. 2 225-5756-00 .....................
11â 1/4-20 Keps Nuts ...............................Qty. 6 325-5202-00 .....................
12â 18â Handle .......................................... Qty. 1 125-5245-00 .....................
13â Shelf & Handle Side (X) ............ Qty. 1 225-5754-00 .....................
14â 18.5â Wide Trolley Shelf ................Qty. 1 100-6495-00 .....................
15â Shelf & Handle Side (Y) .................Qty. 1 225-5755-00 .....................
16â 3/4â Wood Screws ..............................Qty. 6 325-5106-00 ......................
17â 1/4-20 Button Head Screws ...... Qty. 14 325-5210-00 ...................
18â 1/4-20 X 2â Handle Screws ........ Qty. 2 325-5034-00 .....................
19â Non-Skid Pads (not shown) ......... Qty. 8 175-5068-03 .....................
Hello!
Thank you for choosing Anthro.
Before beginning assembly of your
Trolley, please take a moment to re-
view the parts listed below to verify
that your shipment is complete.
All fastener quantities shown are the
minimum needed for this assembly.
There may be a few extras provided
which are not required.
Questions? 1-800-325-3841
Step 7a
Install Non-skid Pads on the top of the Trolley Trunk
Covers to cushion the edge of each Trunk Assembly where it
meets the cover. Install pads on the inside face of the cover,
at the edge, about 3.5â below the threaded holes at the top of
the cover.
The following Tools (not shown at right) have
been provided:
Hex Driver
5/32â 375-5000-00 ............
Hex Key 6mm 375-5013-00 ...............
3
/16
â Allen Key 375-5028-00 ...............
3-way Wrench.............225-5196-03
5/32â Driver Bit ...........375-5003-00
Button Head Screws
AnthroÂź Corporation Technology FurnitureÂź 10450 SW Manhasset Drive Tualatin, Oregon 97062 anthro.com
SAVE THESE INSTRUCTIONS! November 2010, Rev H1-800-325-3841
Trunk Cover
Step 8
STOP: IF YOU PURCHASED A SWING OUT MOUSE SHELF READ
THOSE INSTRUCTIONS BEFORE INSTALLING THE TOP.
Finally, place the main Trolley Shelf onto the installed
Shelf & Handle Sides, aligning the six holes on the
Shelf with those on the Sides.
Secure the Shelf to the Sides using a total of six
3/4â Wood Screws. Tighten all Screws and Nuts.
Congratulations! Your assembly is complete!
3/4â Wood Screw
325-5106-00
3
/4â Wood Screws
into the six Trolley
Shelf holes
Step 7b
STOP: IF YOU PURCHASED A TROLLEY
EQUIPMENT SHELF, ADDITIONAL WOOD SHELF, OR TROLLEY
TRAY READ THOSE INSTRUCTIONS BEFORE INSTALLING THE
TRUNK COVERS.
Install the Trolley Trunk Covers by orienting both Covers with
the Trunk Assemblies.
Secure the top and bottom of each Cover using a total of four
Button Head Screws per Cover.
Non-Skid Pad
175-5068-03
Threaded holes
Button Head
Screws
03
05
02
01
08
04
07
06
09
10
11
12
15
16
17 18
13
14
(1/4-20 X .375â) Button Head Screw
325-5210-00 Component list for
part # TR18zz/xx and TT18zz/xx.
3.5â
Non-Skid Pads
Trolley Cart
AnthroÂź Corporation Technology FurnitureÂź 10450 SW Manhasset Drive Tualatin, Oregon 97062 anthro.com
Step 3 (requires the 6mm Hex Key)
Position both Trunk Assemblies and the 18â Lower Cross Tube
as shown.
Insert the 18â Cross Tube into the Large Holes of each Trunk
and loosely attach the Tube to each Trunk using one Tube
Screw per end.
NOTE: The 18â Cross Tube ends are keyed to ïŹt into the Trunk
Assemblies.
NOTE: If you purchased a Trolley Base Shelf, install the Casters
to the Trunk Assemblies during this Step.
anthro.com
Step 5 (requires the 3-Way Wrench)
Position one Trolley Shelf & Handle Side against a Trunk As-
sembly. Insert the two posts of a Side into holes 3 & 5 (from
the top) of the Trunk. Loosely attach the Side to the Trunk
with one Button Head Screw and Keps Nut. Repeat for the
other Side.
Place the Trolley Handle between both Sides. Insert a Handle
Screw through both ends of the Side and carefully thread into
the Handle. Tighten the Button Head Screws on the Sides.
NOTE: By installing the Side posts into holes 3 & 5, your ïŹnal
Shelf height will be 36â from the ïŹoor.
Questions? 1-800-325-3841
Step 2 (requires the 3-Way Wrench)
STOP: IF YOU PURCHASED A TROLLEY BASE SHELF, READ THOSE
INSTRUCTIONS NOW.
Install all four Casters to both Trunk Assemblies using four Button
Head Screws per Caster.
DOUBLE CHECK THE INSTALLATION of the Swivel Lock Casters
(Green Brake Pedal) by positioning the Trunk Assembly & Caster
as shown. Then depress the Brake. If it is installed correctly, the
Caster will be locked in a parallel orientation with the (as shown)
Trunk Assembly.
NOTE: Make certain to install one Swivel Lock Caster (green brake)
and one Total Lock Caster (black brake) onto each
Trunk Assembly.
Step 4 (requires the 6mm Hex Key)
Rotate the Cart Assembly (from Step 3) onto the Casters.
Place the 12â Upper Cross Tube between each Trunk Assembly
and align the Tube with the Large hole, midway
up the Trunk.
Carefully secure into place using one Tube Screw per end.
(5/16-18 X 1â) Tube Screw
325-5136-00
(5/16-18 X 3/4â) Button Head Screw
325-5188-00
(1/4-20 X .375â) Button Head Screw
325-5210-00
(1/4-20) Keps Nut
325-5202-00
(5/16-18 X 1â) Tube Screw
325-5136-00
(1
/4-20 X .375â) Button Head Screw
325-5210-00
(1/4-20) Keps Nut
325-5202-00 (1/4-20 X 2â) Handle Screw
325-5034-00
Total Lock Caster
(Black Brake Pedal)
front position
Swivel Lock Caster
(Green Brake Pedal)
rear position
Trunk Assembly (Y)
Trunk Assembly (X)
Keyed Cross Tube
ends
Large hole
Shelf & Handle Side
(X)
Trolley Handle and Shelf & Handle Side (Y)
are removed for clarity.
Hole 7
Hole 9
Shelf & Handle Side
(X)
Button Head
Screw
Keps Nut
Cable Hanger
Step 6 (requires the 3-Way Wrench)
Determine the location for your Trolley Cable Hangers, then
position one against a Trunk Assembly.
Insert two Button Head Screws through the Cable Hanger and
capture on the opposite side using two Keps Nuts.
Repeat for remaining Cable Hanger.
Step 1
BEFORE YOU BEGIN, take special notice of the features on the
Swivel Lock Casters (those with the Green Brake Pedals).
The teeth on the plate of both Swivel Lock Casters need to face
the rear of the Trunk Assemblies.
Step 2 will give further instructions about securing the
Casters to the Trunk Assemblies.
Teeth
(on the Plates) faces the rear of
the Trunk Assemblies Plate
Installed to the Trunk
Assemblies
NOTE: There are a matching set
of teeth on the truck. Since the
truck rotates, their orientation is
not critical.
Swivel Lock Caster
(Green Brake Pedal)
Rear of the Trunk As-
semblies
Truck
Trunk Assembly (Y)
Large hole
12â Cross Tube
Shelf & Handle Side
(Y)
Handle Screw
Button Head Screw
Keps Nut
Hole 3
Hole 5 Post
