Seite 1/4

www.amtelectronics.com www.amtelectronics.com

1 1

Safety precautions.

CAUTION! There are no user serviceable parts inside. Repair of the device

can be carried out only by qualified experts. If the device is not used it must be

disconnected from mains.

WARNING! In order to avoid fire or electric shock the device must not be

exposed to rain or moisture. Do not let water or other liquid get inside the device.

Do not place vessels such as vases filled with liquid on top of the device.

This symbol indicates important information related to the

device maintenance and servicing contained in the

accompanying documentation.

Please read the instruction manual very carefully.

1. Keep the user's guide at hand.

2. Pay attention to warnings.

3. Follow all instructions related to device operation.

4. To clean the device, use only a dry cloth having

disconnected the device from mains prior to that.

5. Do not place the device near heat sources, keep it from

direct sunlight.

6. Lay the mains cable so that it is not stepped on and avoid its

contact with sharp corners, etc. If you use the plug or outlet

for switching the device off they should be easily accessible.

7. Use only additional devices and accessories recommended

by the manufacturer.

8. Disconnect the device from mains in case of thunder-storm

or when the device is not in use for prolonged time.

9. All works related to the device repair must be done only by

qualified service personnel.

10. WARNING! All service instructions are intended only for

qualified personnel in order to avoid electric shock; do not

carry out any repair works which are not described in the

instruction manual. Repair works must be carried out only by

qualified experts.

Contents

Important instructions 1

Complete set 1

Introduction 2

Before you start 2

Specifications 2

Controls 3

Top panel 3

Right panel 3

Only for qualified service personnel 3

Batteries installation 3

Audio connections and switching 3

Audio connections (1-channel preamp) 3

Audio connections (2-channel preamp) 3

Audio connections (4-channel preamp) 4

Block diagram 4

IMPORTANTINSTRUCTIONS!

NON-OBSERVANCE OF THE FOLLOWING INSTRUCTIONS CAN CAUSE

DAMAGE OF THE AMPLIFIER OR SPEAKERS. THE DAMAGES RESULTED

BY NON-OBSERVANCE OF THESE INSTRUCTIONS MAKE THE

WARRANTY VOID.

¾ After transportation or storage of the product under

negative temperatures, before switching the device on it is

necessary to leave the device under room temperature in

its original package for AT LEAST 2 hours!

¾ To connect the guitar preamp to other devices use only the

cables intended for such connections.

¾ You must not use other cables types such as speaker, etc.

SWITCHING ON the guitar preamp:

¾ Switch the device on ONLY AFTER YOU HAVE DONE all

audio connections!

¾ Before connecting the preamp to mains make sure that the

case, the connecting cable and the of the power adapter

have no damages such as cuts, cracks, dents, etc. and are

operational.

¾ To switch the preamp on first insert the low-voltage

connector of the power adapter into corresponding jack on

the rear panel of the guitar preamp and only then plug the

adapter into the mains outlet.

SWITCHING OFF the guitar preamp:

¾ To switch the preamp off first disconnect the power

adapter from mains and then disconnect its low-voltage

connector from the jack on the rear panel of the guitar

preamp.

COMPLETE SET

The complete set includes:

1. The guitar preamp 1

2. Instruction manual 1

3. Packaging 1

4. Warranty card 1

www.amtelectronics.com www.amtelectronics.com

2 2

INTRODUCTION

Legend Amps M-1 GUITAR PREAMP is intended for studio recording and live

shows.

“AMT Legend Amps” is a novelty revolutionary series of 1-

channel JFET preamps from AMT Electronics based on the

completely new approach to the guitar sound shaping.

The new series of guitar preamps is based on the technology using analog

modeling of physical processes occurring in the real vacuum triode during guitar

signal limitation.

It was realized due to the use of original circuitry design.

The overdrive channels construction corresponds to the processes occurring in

real tube-based devices.

Thanks to that we achieved formation of limitation, dynamics and range similar to

popular tube amplifiers.

While having minimum size and power consumption inherent in semi-conductor

elements, the effects of AMT Legend amps series possess a number of unique

properties characteristic to authentic tube preamps and amplifiers:

9 The preamps of AMT Legend Amps series provide great playing dynamics

characteristic to tube devices.

9 With limitation range similar to tube the effects of the series offer

tremendous density and power of sound. Using AMT Legend Amps you

won’t feel the necessity to cut out the most informative mid-frequencies that

provide good readability of your guitar in a mix.

9 AMT Legend preamps like tube ones provide gradual increase in the

number of limiting cascades with sensitivity enhancement.

9 The preamps of the series use passive circuits of tone formation fully

corresponding to the adjustments of original tube overdrives.

9 High output level of AMT Legend Amps effects (+10dB at maximum Level)

corresponds to tube preamps output levels. In this way you have the

adjustable signal level which allows to connect the preamp to any input

(RETURN, DIRECT, LINE etc.), including INPUT POWER AMP.

Architecture and features of AMT Legend Amps series preamps:

9 The preamps of the series are single-channel devices with passive bypass.

9 Legend amps have two outputs: direct OUT of the preamp and a separate

CAB.SIM line output.

The sound features of guitar preamps of “AMT Legend Amps”

series:

AMT Legend Amps B-1

This preamp is intended for the admirers of a "clanking" sound with elastic punch.

Legend Amps B-1 emulates Sharp channel of such legend as Bogner Triple

Giant. AMT Legend Amps B-1 has the same sharpness, the same exactingness

of sound production, the same dynamism and the same sound brightness as the

original.

AMT Legend Amps M-1

It emulates the "forefather" of the majority of amplifiers created for heavy styles,

legendary Marshall JCM800. As well as the legendary "forefather", AMT Legend

Amps M-1 is perfectly on friendly terms with boosters.

AMT Legend Amps P-1

This device emulates one of the most esteemed one for its super heavy sound -

Peavey 5150. The sound of AMT Legend Amps P-1 is monstrous density and

aggression and huge amount of gain.

AMT Legend Amps R-1

This device embodies all the power and grace of Red-channel overdrive used in

one of the most popular hi-gain amps by Mesa Boogie.

AMT Legend Amps S-1

The device is intended for the production of sound peculiar to «drive» channels of

Soldano amps. It is distinguished by specific type of overdrive: open, wide and at

the same time tough and dynamic.

AMT Legend Amps F-1

The basic sounds of AMT F-1 are classic amps of Fender Twin series. AMT F-1

offer crystal clear sound with slight warm overdrive at high sensitivity.

AMT F-1 is a pioneer of the basic modules of the entire AMT LA series.

You can build around AMT F-1 your own complex of multi-channel preamp

consisting of AMT LA mono channels: P-1, B-1, M-1, R-1, S-1. The series is

constantly expanding to provide you with unique 100% analog tool forming the

sound of your guitar.

AMT F-1 is supplied with power adapter (unlike the other pedals of the series).

CAUTION!

The preamps of AMT Legend Amps series like many other

top-class devices are sensitive to power adapters’ quality.

We urgently recommend using either 9V battery 6F22 or the

quality adapter such as AC/DC Adapter SA09DC-9V 1,11A or

AC/DC Adapter SA12DC-12V 1,25A.

Before you start

For the purpose of transportation the device was carefully packed by the

manufacturer. However, if cardboard packaging is damaged, it is necessary to

check the device for the presence of external damages.

¾ In case of damages do not send the device to us, but

inform the seller and transport agency since otherwise you

lose the right to damage compensation.

¾ In order to avoid damages during storage and

transportation always use original packaging.

¾ Do not allow children to play with the device and

packaging materials.

¾ Please recycle all packaging materials in the way harmless

to environment.

¾ In order to avoid the device overheating provide sufficient

air flow, do not cover and do not place it near other heat-

generating devices.

¾ Operating the device next to powerful radio transmitters

and sources of high-frequency signals can lead to

significant sound distortion. In this case increase the

distance between the device and the transmitter and use

the screened cables for all interconnections.

WARNING!

Please be aware that high sound volume can harm your hearing

and / or to damage the speakers of your PA system. Before

switching the device on turn the controls "Volume" into

extreme left position (counter-clockwise). Always try to adhere

to moderate level of volume.

Specifications

Use only auxiliary devices and accessories

recommended by the manufacturer.

Input

Impedance 1,0 MOhm

Nom. sensitivity -20dB

Output

Output impedance 10 kOhm

Output signal level +10dB

CAB.SIM. output

Output impedance 10 kOhm

Output signal level -10dB

Power supply 6F22 battery

Voltageе DC 9V

Current consumption Approx. 6.0mA

Power adapter Recommended:

AC/DC Adapter SA09DC-9V 1,11A;

AC/DC Adapter SA12DC-12V 1,25A

Voltage DC 9V or DC 12V

Dimensions / Weight

Net dimensions (Wх хH D). 111х х58 73 mm.

Net weight (without battery) 0,23 kg.

Overall dimensions (WхHхD). Approx. 125х83х103 mm.

Weight (without battery) Approx. 0,3 kg.

www.amtelectronics.com www.amtelectronics.com

3 3

CONTROLS

Front panel

1. Guitar preamp operation indicator.

2. LEVEL – adjusts the preamp output signal level.

3. OUT – output for connection to an input of the power amplifier.

4. CAB.SIM. - output to Line input of a mixer.

5. LOW – adjusts low frequencies.

6. MID – adjusts middle frequencies.

7. HIGH – adjusts high frequencies.

8. IN – electric guitar input.

9. GAIN – adjusts the guitar preamp sensitivity level.

10. FOOT SWITCH – switches operating modes PREAMP / BYPASS

Right panel

11. DC 9V – jack for connecting power adapter of the guitar preamp.

12. Bottom cover of the preamp.

WARNING! All cable connections must be made ONLY

WITH GUITAR PREAMP SWITCHED OFF! (“BYPASS” mode)!

Only for qualified personnel

There are no user serviceable parts inside the device. The

repair of the device can only be carried out by qualified

personnel. If the device has not been in use for prolonged time

period it is necessary to remove the batteries from the device.

To prevent possible damages or injuries resulted by fire or

electric sort circuit do not let foreign objects and liquids get

inside the device.

Battery replacement

Use only the batteries recommended by the manufacturer.

To replace the batteries:

1. Remove the bottom cover of the preamp by unscrewing 4 (four)

fastening screws.

2. Remove the old battery and disconnect it from connector.

3. Connect the new battery to the connector and put in place.

4. Replace the bottom cover of the device and fasten it by means of 4

(four) fastening screws.

AUDIO CONNECTIONS AND SWITCHING

WARNING! All cable connections must be made ONLY

WITH GUITAR PREAMP SWITCHED OFF! (“BYPASS”

mode)!

The diagram of possible audio connections of the preamp with external units:

Produktspezifikationen

Marke:	AMT
Kategorie:	Nicht kategorisiert
Modell:	M1

Brauchst du Hilfe?

Wenn Sie Hilfe mit AMT M1 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert AMT

AMT B1 Bedienungsanleitung

27 August 2024

AMT E1 Bedienungsanleitung

27 August 2024

AMT M1 Bedienungsanleitung

27 August 2024

AMT S1 Bedienungsanleitung

27 August 2024

AMT SS-20 Bedienungsanleitung

27 August 2024

AMT R1 Bedienungsanleitung

30 April 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
