OPERATING INSTRUCTIONS
· Batteries: Locate battery compartment latch on top of megaphone
(A). Open and insert 8 "C" size batteries (not included) into the bat-
tery sleeves (B). (C) Follow battery diagram on label and sleeves for
battery direction. Close megaphone.
· Battery Status: The megaphone has 3 LED's LOW, MID, HIGH (D), that
will tell you the current strength of the battery. Note: Drained batteries do
not give sufficient sound volume. Replace the batteries when LOW
LED lights when trigger is squeezed. Remove batteries when not in
use for a long time.
· Talk: Make sure that the switch is in the (E) Off / Talk position. Place
mouth about one inch from microphone squeeze trigger and speak. (F), (G)
To increase volume, rotate volume control left to right. (H)
When you have a fresh set of batteries you may get "feedback" when talk-
ing. To eliminate feedback you need to turn down the gain. Locate the gain
control in the battery compartment. Turn until you do not hear any feed-(J)
back. Less gain, turn counter clockwise. More gain, turn clockwise.
· Siren: To activate , move switch to the right. Siren will be heard. Siren (E)
There is no control of the volume.
· Whistle: To activate Whistle (E), move switch to the left. Whistle will be
heard. There is no control of the volume.
· Property Label: Located on the bottom of the bell. Use marking pen to
write ownership name on megaphone.
A
E
IF YOU HAVE ANY QUESTIONS OR PROBLEMS PLEASE CALL
OUR CUSTOMER SERVICE DEPARTMENT AT 1-800-267-5486
C
B
D
H
F
G
Thank you for purchasing
AmpliVox S602R MITY- MEG 25 Watt MEGAPHONE
We encourage you to visit our website to register www.ampli.com
your product for its warranty coverage, sign up to receive our
newsletter, download our catalog, and learn more about the com-
plete line of AmpliVox audio visual products, including portable PA
systems, and lecterns.
J
WHY USE RECHARGEABLE BATTERIES?
Save Money—While rechargeable batteries cost more initially, they can be reused hundreds of times
and last for years.
Protect the Environment Conserve Resources —
The corrosive materials and heavy metals in batteries can impair human health and the environment.
Rechargeable batteries use greatly reduces the quantity of batteries manufactured, used and discarded.
· Rechargeable Battery Pack is available for this model: Optional Lithium-ion bat-S1405
tery pack with built-in wall charger. Replaces the 8 "C" size batteries.
· A fully charged battery will provide 8 hours of typical operation, defined as speaking 35% of
the time at mid volume, and over one year of standby / idle time
Available only from AmpliVox Resellers or AmpliVox Portable Sound Systems
WARRANTY
Limited One (1) Year Warranty
AmpliVox warrants this product to be free from defects in materials and workmanship (subject to the terms
set forth below) for a period of one (1) year from the date of purchase ( Warranty Period ). “ ”
During the Warranty Period, AmpliVox will repair or replace (at AmpliVox discretion) this product or any de-
fective parts ( Warranty Service ). “ ”
Repair or replacement under the terms of this warranty does not give right to any extension or a new begin-
ning of the period of warranty.
CLAIMS UNDER THE WARRANTY
To obtain Warranty Service, contact AmpliVox (800-267-5486) to be assigned a Return Authorization number
(RA#). After receiving RA #, the defective unit is to be returned to AmpliVox in either its original packaging or
packaging affording an equal degree of protection. You will bear the cost of shipping the product to Am-
pliVox. If the product is covered by the warranty, AmpliVox will bear the cost of shipping product back to you
after the completion of service under this warranty.
Return shipping will be charged to you for products not covered by the warranty or requiring no warranty re-
pair.
The following information must be presented to obtain Warranty Service: (a) the RA# must
be clearly and legibility marked on the outside of shipping carton, (b) proof of purchase,
which clearly indicates the name and address of the seller, the date of purchase and the
product type, which is evidence that this product is within the Warranty Period. Please fur-
ther include (c) your return address, (d) daytime telephone number, and (e) reason for return.
LIMITATION OF WARRANTY
This warranty is only valid for the original purchaser and will automatically terminate prior to expiration if this
product is sold or otherwise transferred to another party. The warranty provided by AmpliVox in this state-
ment applies only to products purchased for use, and not for resale. It does not apply to open box purchases,
which are sold as is and without any warranty. Specifically exempt from warranty are limited-life consum-“ ”
able components subject to normal wear and tear, such as microphone windscreens, ear cushions, modular
plugs, ear tips, decorative finishes, batteries, and other accessories. This warranty is invalid if the factory-
applied serial number, date code label, or product label has been altered or removed from this product. This
warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence, Acts of Nature, ac-
cident, disassembling or modification of, or to any part of, the product. This warranty does not cover damage
due to improper operation, maintenance or installation, or attempted repair by anyone other than AmpliVox.
Any unauthorized repairs will void this warranty.
Repairs or replacements as provided under this warranty are the exclusive remedy of the consumer.
AmpliVox shall not be liable for any incidental or consequential damages for breach of any express or implied
warranty on this product except to the extent prohibited by law, this warranty is exclusive and in lieu of all
other express and implied warranties what so ever, including but not limited to the warranty of merchantability
and fitness for a practical purpose.
NOTE! This warranty gives you specific legal rights. You may have other rights which vary from location to
location. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
implied warranties, so the above exclusions may not apply to you. This warranty does not affect your legal
(statutory) rights under your applicable national or local laws.
AmpliVox - 650 Anthony Trail, Suite D, Northbrook, IL 60062 - Phone: (800)267-5486 Fax: (800)267-5489 www.ampli.com
Dispose of the product according
to local standards and regulations
April, 2014
