Seite 1/83
MN-35947 • REV. 10 • 0 6/16
CTP6-10E, CTP6-10G
CTP10-10E, CTP10-10G
CTP7-20E, CTP7-20G
CTP10-20E, CTP10-20G
CTP20-10E, CTP20-10G
CTP20-20E, CTP20-20G
INSTALLATION
CTC6-10E, CTC6-10G
CTC10-10E, CTC10-10G
CTC7-20E, CTC7-20G
CTC10-20E, CTC10-20G
CTC20-10E, CTC20-10G
CTC20-20E, CTC20-20G
WARNING
Improper installation, alteration,
adjustment, service, cleaning, or
maintenance could result in PROPERTY
DAMAGE, SEVERE INJURY, or DEATH.
Read and understand the installation,
operating and maintenance instructions
thoroughly before installing, servicing, or
operating this equipment.
WARNING
For your safety
DO NOT store or use gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
W164 N9221 Water Street • P.O. Box 450
Menomonee Falls, Wisconsin 53052-0450 U.S.A.
PHONE: 262.251.3800 • 800.558.8744 U.S.A. / CANADA
FAX: 262.251.7067 • 800.329.8744 U.S.A. ONLY
www.alto-shaam.com Consult instructions
for operation and use.
DANGER
Before starting the appliance, make certain
you do not detect the odor ofgas.
If you smell gas:
• Shut o the gas supply immediately.
• Do not attempt to light any appliance.
• Do not touch any electrical elements.
• Extinguish any open flame.
• Evacuate the area.
• Use a telephone outside the property and
immediately contact your gas supplier.
• If unable to contact your as supplier,
contact the fire department.
i
Delivery 1 ..........................................................................
Unpacking 1 .....................................................................
Safety Procedures and Precautions 2 ..............................
Installation
Installation Codes and Standards 4 .............................
Ventilation Requirements 4 ...........................................
Sound Pressure 4 ..........................................................
Installation Duties and Responsibilities (new const.) 5 .
Installation Duties and Responsibilities (existing) 6 ......
Pre-Installation Checklist 7 ...........................................
Specications, CTP6-10E 9 ..........................................
Specications, CTC6-10 10E ........................................
Specications, CTP6-10G........................................ 11
Specications, CTC6-10G 12 .......................................
Specications, CTP10-10E 13 ......................................
Specications, CTC10-10E 14 ......................................
Specications, CTP10-10G...................................... 15
Specications, CTC10-10G 16 .....................................
Specications, CTP7-20E 17 ........................................
Specications, CTC7-20E 18 ........................................
Specications, CTP7-20G........................................ 19
Specications, CTC7-20 20G .......................................
Specications, CTP10-20E 21 ......................................
Specications, CTC10-20E 22 ......................................
Specications, CTP10-20G...................................... 23
Specications, CTC10-20G 24 .....................................
Specications, CTP20-10E 25 ......................................
Specications, CTC20-10E 26 ......................................
Specications, CTP20-10G...................................... 27
Specications, CTC20-10G 28 .....................................
Specications, CTP20-20E 29 ......................................
Specications, CTC20-20 30E ......................................
Specications, CTP20-20G...................................... 31
Specications, CTC20-20G 32 .....................................
Lifting Instructions 33 ....................................................
Clearance Requirements 34 ..........................................
Positioning on Site, Countertop Models .................. 34
Positioning on Site, 20-10, 20-20 Models................ 35
Options and Accessories 36 .........................................
Electrical Safety Regulations 37 ...................................
Electrical Connection for Gas Models ..................... 38
Electrical Connection for Electric Models ................ 39
Electrical Kit Installation - 50 Hz .............................. 41
Electrical Kit Installation - 60 Hz .............................. 42
Ventilation Requirements 43 .........................................
Gas Supply & Installation 44 .........................................
Gas Leak Testing ...................................................... 48
Gas Exhaust 48 .............................................................
Water Quality Requirements 49 ....................................
Water Supply & Installation ...................................... 50
Water Drainage......................................................... 51
Mobile Equipment Restraint ..................................... 53
Combihood PLUS™ Installation 54 ..............................
Grease Collection Hook-up ...................................... 56
Liquid Cleaner Hook-up ........................................... 57
CT PROformance Start-up Procedures ................... 58
CT PROformance Screen Calibration ...................... 58
CT Classic Start-up Procedures 60 ..............................
Post-Installation Checklist 61 .......................................
Function Test Checklist ............................................ 63
Preventative Maintenance ........................................ 65
Error Codes 71 .............................................................
Service Parts 79 ............................................................
Warranty
Original Equipment Limited Warranty ...................... 80
Transportation Damage and Claims ......................... 81
INSTALLATION
TABLE OF CONTENTS
Please post the following instructions in a prominent
location in the event the user smells gas.
MN-35947 • Rev 10 • 06/16 • COMBITHERM CT PROFORMANCE AND CT CLASSIC SERIES • INSTALLATION MANUAL • 1
D e l i v e r y
This Alto-Shaam appliance has been thoroughly
tested and inspected to ensure only the highest
quality unit is provided. Upon receipt, check for any
possible shipping damage and report it at once to the
delivering carrier. See Transportation Damage and
Claims section located in this manual.
This appliance, complete with unattached items
and accessories, may be delivered in one or more
packages. Ensure all standard items and options
have been received with each model as ordered.
Save all the information packed with the appliance.
Register online at www.alto-shaam.com to ensure
prompt service in the event of a warranty parts and
labor claim.
This manual must be read and understood by all
people using or installing the equipment model.
Contact the Alto-Shaam Tech Team Service
Department if you have any questions concerning
installation, operation, or maintenance.
1-800-558-8744; servicedept@alto-shaam.com
U n p a c k i n g
• Carefully remove the appliance
from the carton or crate.
NOTICE: Do not discard the
carton and other
packaging material
until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
• Read all instructions in this manual carefully
before installing this appliance, using the appliance
or performing routine maintenance. Following
procedures other than those indicated in this
guide to use and clean the appliance is considered
inappropriate and may cause damage, injury or
fatal accidents, in addition to invalidating the
guarantee and relieving Alto-Shaam of all liability.
• DO NOT DISCARD THIS MANUAL.
This manual is considered part of the appliance
and is provided for the owner or manager of the
business and for training personnel. Additional
manuals are available from the Alto-Shaam
Tech Team Service Department.
• Remove all protective plastic film, packaging
materials, and accessories from the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
WARNING
Appliance and accessories may be
heavy. To prevent serious injury, always
use a su icient number of trained and
experienced workers when moving or
leveling appliance and handling accessories.
ENVIRONMENTAL CONDITIONS
• Operational Environmental Conditions
• Unit must acclimate to room temperature in the
environment it is placed. 24 hours is recommended.
• Ambient temperature range of 60°F to 110°F (16°C to 43°
C).
• Relative humidity of less than 95% non-condensation.
• Atmospheric pressure range of 50KPa to 106KPa.
Serial number is required for all inquiries.
Always include both model and serial number(s) in any
correspondence regarding the appliance.
Model: ______________________________________________
Serial Number: ______________________________________________
Purchased From: ______________________________________________
Date Installed: Voltage: ____________________ _____________
