Seite 1/16
www.alfatronelectronics.com
ALFATRON ELECTRONICS GmbH GERMANY
ALF-TPUK150-RS
18Gbps HDMI over HDBaseT Extender
with Bi-directional IR (150M)
VER 1.0
ALF-TPUK150-RS
Preface
For optimum performance and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep this manual for future
reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lightning strikes, etc. The use of surge
protection systems is highly recommended to protect and extend the life of your
equipment.
FCC Statement
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. It has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void the
user’s authority to operate the equipment.
Do not dispose of this product with the normal household waste at the end of its life cycle.
Return it to a collection point for the recycling of electrical and electronic devices. This is
indicated by the symbol on the product, user manual or packaging. The materials are
reusable according to their markings. By reusing, recycling or other forms of utilisation of
old devices you make an important contribution to the protection of our environment.
Please contact your local authorities for details about collection points.
ALF-TPUK150-RS
Table of Contents
1. Introduction...................................................................................................... 1
2. Features ............................................................................................................ 1
3. Package Contents.......................................................................................... 2
4. Specifications................................................................................................... 3
5. Operation Controls and Functions ............................................................ 5
5.1 Transmitter Panel...................................................................................... 5
5.2 Receiver Panel .......................................................................................... 6
5.3 IR Pin Definition.......................................................................................... 8
6. Application Example................................................................................. ..10
7. After Sales …………………………………………………………………...11
8. Warranty ……………………………………………………………………..12
