Seite 1/4
AGROTM
Based on the popular AG 500 saturation channel, the AGRO was designed to give
bass players a wide range of tonal flexibility. From vintage tube-like warmth to
full on dirt, this circuit will allow you to add rich harmonic overdrive to your
sound while maintaining the full, round tone of your instrument. The AGRO can
be run in front of your amp, in your FX loop, or as a preamp straight into a
power amp. Whichever way you use your new AGRO – Rock On!
Owners Manual
Manual Version 1.2
I. Getting Started
A. Safety Instructions
Please follow these guidelines:
A) Keep all sources of fire, such as lighted candles, away from the
product.
B) This product is approved for use in any climate.
C) Do not expose the product to dripping or splashing. Do not
place objects filled with fluid on the product.
D) Product must be connected to a mains socket outlet with a
protective earthing connection.
E) The appliance coupler (AC adapter) is the disconnect device.
The disconnect device shall remain readily operable at all times.
B. Manual Conventions
In this manual, words that appear in
italics
represent actual physical
controls on the AGRO.
C. Basic Setup
1. Plug in your instrument, the footswitch, and your amplifier. With
Master
volume down, turn on the AGRO and your amplifier.
2. While playing, turn up the AGRO’s
Master
control until you reach your
normal playing level. Because the AGRO features Aguilar’s saturation
circuitry there is no input gain control.
3. Adjust the
Saturation
control to the desired amount of overdrive. The
minimum position provides a little tube-like breakup. In the maximum
position…stand back! If your bass has low output or you don’t have the
instrument volume up all the way it may be necessary to turn the
Saturation
up further to hear the desired amount of overdrive.
4. Adjust tone controls to taste.
2
II. Features and Functions
A. Front Panel Features
Contour
: broad range mid scoop @ 1kHz
(ccw=max scoop (~20dB) cw=flat)
Treble
: + 6dB/- 10dB @ 4kHz shelving
Mid
: + 4dB/- 10dB @ 600Hz peaking
Bass
: + 8dB/- 6dB @ 40Hz shelving
Deep
: +6dB <100Hz shelving
Presence
: + 6dB/-20dB >4kHz shelving
Engage
switch: When this switch is pushed in the AGRO saturation effect
is active. When the switch is in the out position, the effect will be
bypassed. When the effect is on, the
Operate
LED is lit. When the effect
is off, the LED will not be lit.
B. Rear Panel Features
Input: A second ¼” input jack is provided on the rear panel for your
convenience. The rear panel input jack disconnects the front panel jack
when you insert a cable.
Outputs: Two ¼” outputs are provided.
Output 1
on the left is line level
and
Outpu 2
on the right is selectable for either line level or instrument
level, controlled by the switch to its right. When the switch is in the out
position
Output 2
is line level, and when the switch is pushed in
Output 2
is instrument level. You should select the output level appropriate for your
application. For instance – line level signals are typically used directly into
a power amp. Instrument level signals are typically run into a preamp,
the input of a bass head, or in an FX loop. Modern mixing consoles are
set up to accommodate a wide range of signals. Both outputs are
buffered and may be used at the same time.
t
Footswitch: The footswitch that comes with your AGRO allows you to
turn the effect on and off without using the
Engage
button on the front of
the unit. When the effect is on, the
Operate
LED is lit. When the effect is
off, the LED will not be lit, and the effect will be bypassed.
DC In Jack: This is a standard 2.1mm DC jack. The center terminal
polarity is positive. Input: 24V 0.5A regulated DC.
Power Switch: The “-” symbol is on, and “o” is off.
3
