Advantech SQF-S25V8-960G-SCC Bedienungsanleitung

Advantech Solid-State-Laufwerk (SSD) SQF-S25V8-960G-SCC

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Advantech SQF-S25V8-960G-SCC (26 Seiten) in der Kategorie Solid-State-Laufwerk (SSD). Dieser Bedienungsanleitung war für 24 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Download PDF

Seite 1/26

SQFlash

2.5 SATA SSD 840 ”

Speciﬁcations subject to change without notice, contact your sales representatives for the most update information.

REV 0.9 Page 1 of Oct. 9, 2019 26

2.5 SATA SSD 840 ”

Datasheet

(SQF-S x-x - x)25 xx SC

SQFlash

2.5 SATA SSD 840 ”

Speciﬁcations subject to change without notice, contact your sales representatives for the most update information.

REV 0.9 Page 2 of Oct. 9, 2019 26

CONTENTS

1. Overview .......................................................................................... 4

2. Features ........................................................................................... 5

3. Specification Table .......................................................................... 6

4. General Description ........................................................................ 8

5. Security Features .......................................................................... 11

6. Pin Assignment and Description .................................................. 12

6.1 2.5” SATA-SSD Interface Pin Assignments (Signal Segment) ....................................... 12

6.2 2.5” SATA-SSD Interface Pin Assignments (Power Segment) ....................................... 12

6.3 Hardware Quick Erase / Write Protect (Optional, either one support only) .................... 13

7. Identify Device Data ...................................................................... 14

8. ATA Command Set ......................................................................... 17

9. System Power Consumption ........................................................ 24

9.1 Supply Voltage .............................................................................................................. 24

9.2 Power Consumption ...................................................................................................... 24

10. Physical Dimension .................................................................... 25

Appendix: Part Number Table .......................................................... 26

SQFlash

2.5 SATA SSD 840 ”

Speciﬁcations subject to change without notice, contact your sales representatives for the most update information.

REV 0.9 Page 3 of Oct. 9, 2019 26

Revision History

Rev.

Date

History

0.1

2018/5/16

1. Preliminary

0.2

2018/8/22

1. Update PN information

0.3

2018/10/31

1. Update TBW information

0.4

2018/12/14

1. Update Security Features section and TBW

0.5

2019/2/25

1. Update performance information

2. Update power consumption information

0.6

2019/5/10

1. Added performance information

0.7

2019/5/16

1. Update H/W write protect description

0.8

2019/10/2

1. Update performance, consumption information

0.9

2019/10/09

1. Update 120GB performance and power consumption

2. Update 240GB performance and power consumption

3. Update ordering P/N

1.0

2019/10/15

1. Update Identify Device Data for 120GB

Advantech reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or

design. Information furnished by Advantech is believed to be accurate and reliable. However, Advantech does not assure any liability

arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither

does it convey any license under its patent rights nor the rights of others.

Produktspezifikationen

Marke:	Advantech
Kategorie:	Solid-State-Laufwerk (SSD)
Modell:	SQF-S25V8-960G-SCC
Schutzfunktion:	Shock resistant, Vibration proof
Breite:	69.85 mm
Tiefe:	100.1 mm
Höhe:	7 mm
Betriebstemperatur:	0 - 70 °C
Zertifizierung:	CE
Betriebsanleitung:	Ja
Schnittstelle:	Serial ATA III
Komponente für:	Überwachungssystem
ECC:	Ja
Nachhaltigkeitszertifikate:	RoHS
SSD Speicherkapazität:	960 GB
SSD-Formfaktor:	2.5"
Datenübertragungsrate:	6 Gbit/s
Lesegeschwindigkeit:	560.2 MB/s
Stoßfest (in Betrieb):	1500 G
Schreibgeschwindigkeit:	533.5 MB/s
Zufälliges Lesen (4KB):	95316 IOPS
Zufälliges Schreiben (4KB):	69934 IOPS
Speichertyp:	3D TLC
Vibrationen in Betrieb:	20 G
