Seite 1/19
Translation of the original instructions
A
contribution to reduce your energy footprint
Ventilating rooms - sure, dry and comfortable
WIN-CONTROL WS 20.1
Hybrid - window closer
2
WIN-CONTROL WS 20.1
Dear customer,
thank you very much for choosing a high quality product by
ABE Arnhold and placing your trust in us. On the following
you will get important information permitting you an optimal
and safe use of your window closer. Please read these instruc-
tions carefully and completely before the device is used for the
first time.
Keep these instructions ready to
hand for future reference when
required. If you pass the device
to another user, be sure to pass
these instructions, too. They are
also available for download as
pdf file from our homepage
http://www.abe-arnhold.de.
Enjoy your new
HYBRID - Window closer!
Sincerely Yours,
ABE Arnhold Technische Erzeugnisse GmbH & Co. KG
Copyright © ABE Arnhold Technische Erzeugnisse GmbH & Co. KG
These instructions have been compiled with the greatest possible care.
Nevertheless we reserve the right to optimize and to adapt technical-
ly these instructions at any time.
3
T ABLE OF CONTENTS
1. Intended use and safety instructions p. 5
2. The HYBRID - Window closer p. 12
Utility and functioning
3. Installation of the window closer p. 15
3.1. Images of components p. 15
3.2. Scope of delivery p. 16
3.3. Necessary tools p. 17
3.4 Installation instructions p. 18
3.5 Accessory: rain sensor p. 24
4. Operation of the window closer p. 28
4.1 Time set p. 28
4.2 Activation of the window closer p. 29
4.3 Closing the window by using the closing button p. 29
4.4 Opening the window completely p. 30
4.5 Warning by a close signal p. 31
4.6 Interruption of the closing action p. 31
4.7 Change of batteries p. 31
4.8 Dismounting the device p. 33
5. Product properties p. 35
5.1 CE mark, declaration of conformity and certification p. 35
5.2 Guarantee p. 35
5.3 Technical data p. 37
WIN-CONTROL WS 20.1
4
WIN-CONTROL WS 20.1
A t t e n t i o n ! Automatic start of the de-
vice! The device starts automatically after a
pre-set closing time, after activating the
closing button and - if a rain sensor is in-
stalled - , if it starts to rain!
Warn in g aga in st hand in ju ri e s !
When the closing signal is sounded do n o t
touch between the window casement and the
window frame! While dismounting the device
and while extending the spring do n o t
touch between the device and the clip!
Explanation of symbols
F o l l o w t h e i n s t r u c t i o n s !
This symbol is located on the device. For a
safe and correct operation of the device it is
absolutely necessary to follow the instructions
in this manual!
A t t e n t i o n ! The device is intended for
indoor use only.
5
WIN-CONTROL WS 20.1
1. Intended use and safety instructions
1.1. Intended use
The window closer is constructed according to the state of
the art and the recognised safety regulations. Neverthe-
less, improper use can cause serious dan- or not intended
ger for the user or others as well as material damage of
the device and/or other equipment.
The window closer is a tool for closing window casements
made of plastic, wood or aluminium, which are in a tilt
position. The window lower edge must not be lower than
85 cm.
A different application or use extending beyond this pur-
pose is not a considered use for the intended purpose.
The use of the device is entirely at the user‘s own risk.
Acknowledgement of the contents of these operating in-
structions forms part of the intended use.
1.2. Safety instructions
W a r n i n g: Important safety instructions!
For safety of persons it is important to follow these in-
structions. These instructions are to be stored.
6
WIN-CONTROL WS 20.1
1.2.1. General safety information
Always comply the general safety- and accident prevention
advice! In addition to the information in these instructions
the general safety and accident prevention advices of the
legislator must be kept in mind.
Pass these operating instructions on to third parties! Take
care that third parties only use this device after receipt of
the operating instructions!
Always pay attention and note what you do! Do not work
with this device under the influence of drugs, alcohol or
medication!
Note who may use the device! The device may be used by
children aged 8 and above as well as persons with limited
physical, sensory or mental aptitudes or lack of experience
and/or knowledge if they are supervised or they are in-
structed in the safe use of the device by responsible per-
sons and if they understand the resulting risk to human
health. Children under 8 years have to be kept away from
the device.
Children may not play with the device. Cleaning and
maintenance are not allowed to be made by children
without supervision!
