A-NeuVideo ANI-88HDRH Bedienungsanleitung
A-NeuVideo
Router
ANI-88HDRH
Lesen Sie kostenlos die đź“– deutsche Bedienungsanleitung fĂĽr A-NeuVideo ANI-88HDRH (24 Seiten) in der Kategorie Router. Dieser Bedienungsanleitung war fĂĽr 13 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/24
ANI-88HDRH
8X8 HDR 4K@60Hz HDMI 18G MATRIX SWITCHER SCALER
w/ USB POWER PORTS
A-NeuVideo.com
Frisco, Texas 75036
INSTRUCTION MANUAL
PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the box:
• ANI-88HDRH Matrix
• Remote control unit
• Rack ear set
• 24V / 6.25A Adaptor with power cord
SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of îšżre, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power o󰀨 and disconnect unit from AC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
ow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualiîšżed service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect Input ports îšżrst, then remove the power cable; îšżnally, disconnect the interconnecting cables to
other devices.
16. Do not drive the Inputs with a signal level greater than that required to drive equipment to full Output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualiîšżed service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain.
D. The equipment does not appear to operate normally, or exhibits a marked change in performance.
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL.
TABLE OF CONTENTS
A NEUVIDEO
1
CONTENTS
INTRODUCTION ..........................................................................1
FEATURES & SPECIFICATIONS ................................................2
OPERATION CONTROLS & FUNCTIONS ................................3
REMOTE CONTROL & IR CABLE PIN ASSIGNMENT ...............5
LCD MENU TREE & RS-232 PROTOCOLS ..............................6
RS-232 & TELNET COMMANDS .................................................8
TELNET CONTROL ..................................................................12
WEBGUI CONTROL .................................................................13
CONNECTION DIAGRAM ........................................................18
SUPPORTED RESOLUTIONS .................................................19
IR CABLE PIN ASSIGNMENT ...................................................20
INTRODUCTION
This 8x8 HDMI 6G (18G per channel) Matrix provides the ability to
connect up to (8) 6G HDMI sources and up to (8) 6G HDMI displays
and freely switch between them. This unit comes with full support for
6G resolutions up to and including 4K@60Hz (4:4:4, 8-bit) as well
as support for 48-bit Deep Color, HDR (High Dynamic Range), HD
audio and other features deîšżned by the HDMI 2.0a speciîšżcation.
With a comprehensive EDID management feature that includes
the ability to select between built in default EDID, EDID copied
from connected sink devices, as well as a conîšżgurable EDID, this
matrix can solve many inter-connectivity problems. This unit also
features (8) USB ports which supply up to 5V/1A power for use
with connected optical îšżber or AOC îšżber cable extenders. By using
these specialized cables your HDMI content can be extended much
further than would be possible with normal HDMI cables. The built
in OSD has the ability to display user editable general information
text. This unit provides an intuitive set of front panel controls with
an OSD as well as RS-232, Telnet, WebGUI and IR remote control
options. This product has a 3 year warranty.
SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or
audio ampliîšżers.
• The use of cables is highly “Premium High Speed HDMI”
recommended.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
w(8) to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
su󰀩cient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update or
to keep current the information contained in this document.
We reserve the right to make improvements to this document and/
or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer îšżle, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise — without the express written permission and consent.
© Copyright 2019. All Rights Reserved.
Version 1.7 AUG 2019
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
