Seite 1/26
1
ZOTAC ZBOX nano XS
ZOTAC ZBOX nano XS
User’s Manual
No part of this manual, including the products and software described in it,
may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the
express written permission of ZOTAC.
Products and corporate names mentioned in this manual may not be reg-
istered trademarks or copyrights of their respective companies, and are
used for identiî‚¿cation purposes only. All trademarks are the property of their
respective owners.
Every effort has been made to ensure that the contents of this manual are cor-
rect and up to date. However, the manufacturer makes no guarantee regard-
ing the accuracy of its contents, and reserves the right to make changes
without prior notice.
CAUTION:
Risk of explosion if the battery is replaced with an incorrect type. Batteries
should be recycled where possible. Disposal of used batteries must be in
accordance with local environmental regulations.
2
ZOTAC ZBOX nano XS
Table of Contents
Product speciî‚¿cations -------------------------------------------------------------------------- 3
Safety information -------------------------------------------------------------------------------- 4
Setting up your system 4 -----------------------------------------------------------------------
Care during use 4 --------------------------------------------------------------------------------
Welcome --------------------------------------------------------------------------------------------- 5
Package contents 5 ------------------------------------------------------------------------------
Getting to know your ZOTAC ZBOX nano XS-------------------------------------------- 6
Front view 6 ----------------------------------------------------------------------------------------
Rear view----------------------------------------------------------------------------------------- 7
BIOS settings of speciî‚¿c functions --------------------------------------------------------- 8
How to disable the ring LED indicator 8 ----------------------------------------------------
How to enable USB2.0 hotplug charge (for S3/S4/S5 status) 10 ----------------------
High Current/Fast Charging USB ports ---------------------------------------------- 11
How to disable CIR controller (for internal IR receiver) ------------------------------- 11
Customizing the ZOTAC ZBOX nano XS -------------------------------------------------- 13
Installing a memory module 14 -----------------------------------------------------------------
Installing an mSATA --------------------------------------------------------------------------- 15
Connecting a SPDIF cable 16 ------------------------------------------------------------------
Setting up the ZOTAC ZBOX nano XS ------------------------------------------------------ 17
Positioning the ZOTAC ZBOX nano XS ---------------------------------------------------- 18
Mounting the ZOTAC ZBOX nano XS to a LCD monitor 18 -----------------------------
IR receiver 19 ---------------------------------------------------------------------------------------
Remote control (optional) 20 --------------------------------------------------------------------
Function keys 20 -------------------------------------------------------------------------------
Lithium cell installation 21 --------------------------------------------------------------------
Installing drivers and software --------------------------------------------------------------- 22
Installing an operating system 22 --------------------------------------------------------------
Installing system drivers 22 ----------------------------------------------------------------------
Using your ZOTAC ZBOX nano XS ---------------------------------------------------------- 23
Conî‚¿guring wireless connection ----------------------------------------------------------- 23
Conî‚¿guring wired connection --------------------------------------------------------------- 23
Using a static IP 23 ----------------------------------------------------------------------------
Using a dynamic IP (PPPoE connection) 24 --------------------------------------------
Conî‚¿guring audio output via an HDMI device ------------------------------------------ 24
