Seite 1/22
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
English Edition
Visit our website (www.zalman.co.kr) and watch the RESERATOR 1 installation
video to facilitate the installation process.
※Please read this manual thoroughly before installation.
※The specifications of this product and its components may change without prior notice to improve the performance thereof.
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
2
1.Make sure that the power source’s output voltage and frequency are compatible with
the power input requirements of the water pump before installing. (Input voltage and
frequency of the water pump can be located on the box and sink cover.)
2.Do not place in dusty or humid conditions, under direct sunlight, or near a heat source
such as a room heater.
3. Do not drop or subject to excessive force.
4.Check CPU socket compatibility first.
5.Familiarize yourself with this manual.
6. Do not mix any contaminant with the coolant when filling, for it may cause product
failure.
7. Use of a multiple-outlet power strip is recommended, for you can connect or disconnect
power to the PC and the Reserator 1’s pump simultaneously.
Cautions & Warnings
When Installing
1. Always turn on the water pump first before using the system.
2.If the coolant isn’t circulating or the pump is making a strange noise, turn off the pc
system immediately.
3.Do not place any object on the product.
4. Install on a flat surface with no vibration or slant; do not tilt or lay horizontally.
5.Use distilled or tap water for coolant, regularly check the amount of coolant, and
replenish as needed.
6.If a leak is found, turn off the system immediately and examine the problem before
using the system again.
7. If the system will not be used for an extended period of time, turn off the water pump.
8. When moving the system, separate the reserator from the PC case before moving.
9. Make sure to not let any air bubbles into the Water Block and tubes while in use.
10. Always check that the water pump is properly functioning.
When in Use
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
3
English
Reserator 1 is designed with an optimal heat dissipation area based on Zalman
Tech’s HCET (High Capacity Extrusion Technique) and high efficiency cooling
technology. As a result, this product achieves excellent cooling performance
even with natural convection, making it the world’s first fanless, noiseless water-
cooling system. The reservoir, radiator, and the water pump are conveniently
integrated into one assembly, and the heatsink is anodized to prevent corrosion
and rust. In addition, the kit includes the high-performance ZM-WB2 Gold water
block which is not susceptible to galvanic corrosion.
1. Features
Contents
Cautions & Warnings
Contents
1. Features
3
2. Specifications
4
3. Installation View
5
4. Components
6
5. Installation
8
6. Installing External Water Pump
14
7. Separate Reserator and Water Block
17
8. FAQ
20
9. Exploded View
21
Zalman Noise Prevention System
