Seite 1/5
1033524A-1/15
RocketBox 15s .........................35 lbs. / 15 kg
RocketBox 11 ...........................35 lbs. / 15 kg
RocketBox 16 ...........................42 lbs. / 19 kg
GEAR BOXES
RocketBox 16
RocketBox 11
RocketBox 15s
Part #1033524 Rev.A
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL
YAKIMA RACKS AND
ACCESSORIES BE PROPERLY
AND SECURELY ATTACHED
TO YOUR VEHICLE. IMPROPER
ATTACHMENT COULD RESULT
IN AN AUTOMOBILE ACCIDENT,
AND COULD CAUSE SERIOUS
BODILY INJURY OR DEATH TO
YOU OR TO OTHERS. YOU ARE
RESPONSIBLE FOR SECURING
THE RACKS AND ACCESSORIES
TO YOUR CAR, CHECKING
THE ATTACHMENTS PRIOR
TO USE, AND PERIODICALLY
INSPECTING THE PRODUCTS
FOR ADJUSTMENT, WEAR, AND
DAMAGE. THEREFORE, YOU
MUST READ AND UNDERSTAND
ALL OF THE INSTRUCTIONS AND
CAUTIONS SUPPLIED WITH
YOUR YAKIMA PRODUCT PRIOR
TO INSTALLATION OR USE. IF
YOU DO NOT UNDERSTAND ALL
OF THE INSTRUCTIONS AND
CAUTIONS, OR IF YOU HAVE
NO MECHANICAL EXPERIENCE
AND ARE NOT THOROUGHLY
FAMILIAR WITH THE
INSTALLATION PROCEDURES,
YOU SHOULD HAVE THE
PRODUCT INSTALLED BY A
PROFESSIONAL INSTALLER
SUCH AS A QUALIFIED GARAGE
OR AUTO BODY SHOP.
NO PRE-ASSEMBLY REQUIRED
MAXIMUM LOAD LIMITS:
box contents
DO NOT EXCEED
YOUR RACK’S
WEIGHT LIMIT!
Check with your Yakima
dealer or on the internet,
go to “Choose my Rack”
at YAKIMA.com, for your
vehicle’s load limits.
box weight rack weight
(if appropriate)
1033524A-2/15
Loosen red knobs and open
clamps. Do not remove knobs.
Place box on vehicle with
clamps in front of crossbars.
A friend could help with this.
Loosen track thumb wheels 1/2
turn. Do not remove wheels.
REMOVING THUMBWHEELS
WILL CAUSE DISASSEMBLY OF
LEVER/CLAMP MECHANISM.
OPEN THE BOX
(Use the key to
unlock the box).
• TO OPEN THE BOX, unlock it.
• With the key still inserted,
raise the lid.
The key cannot be removed
while the box is open.
BARS THAT MOVE:
TIGHTEN YOUR CROSSBARS IF
YOU LOOSENED THEM.
If your vehicle has a fairing, remove the fairing prior to box installation.
Q TOWERS:
NEVER REPOSITION
THE TOWERS!
CROSSBAR SPREAD
RocketBox 16 ....................30" - 36" (76 - 91 cm)
RocketBox 11.....................30" - 36" (76 - 91 cm)
RocketBox 15s ..................24" - 36" (61 - 91 cm)
INSIDE THE BOX:
LOAD CARGO BOX ONTO VEHICLE:
1033524A-3/15
Adjust box on top of car.
Measure from towers for reference.
IF POSSIBLE, POSITION BOX TO
AVOID INTERFERENCE WITH BACK
HATCH AND/OR SUNROOF.
OPEN LID TO GAIN ACCESS TO KNOBS.
Tighten knobs to
engage clamps. TIGHTEN ALL
THUMB WHEELS.
• Check clamp opening for crossbar clearance.
• Loosen red knob further if necessary.
Slide clamps along tracks
(inside box) to engage crossbars.
