Seite 1/15
HF/VHF/UHF
SSB/CW/AM/FM ULTRA-COMPACT TRANSCEIVER
FT-818ND
Operating Manual
Contents
Introduction 1 ......................................................
Safety Precautions 2 ..........................................
Accessories & Options 4 ...................................
Supplied Accessories ...................................... 4
Available Options 4 ............................................
Installation 5 ........................................................
Connecting the Supplied YHA-63 Antenna 5 .....
Connecting the Microphone 6 ............................
Shoulder Strap Installation 6 ..............................
Rubber Foot Installation 6 ..................................
Alkaline Battery Installation and Use 7 ..............
External Power Connections 8 ...........................
SBR-32MH Ni-MH Battery Pack
Installation and Use 9 ........................................
Installation 9 ....................................................
Charging 9 .......................................................
Front Panel Control & Switches 10 ...................
Display Icons 13 ..............................................
Side Panel Switch & Connectors 14 .................
Rear Panel Connectors 15 .................................
Operation 16 ........................................................
Turning the Transceiver On and O󰀨 .............. 16
Supply Voltage Display 16 .................................
Operating Band Selection 17 .............................
Mode Selection 17 .............................................
Adjusting the Audio Volume Level 17 .................
Menu Quick Start 18 ..........................................
Adjusting the RF Gain and Squelch 18 ..............
Setting the Operating Frequency 19 ..................
Stacked VFO System 19 ....................................
Operation on 5 MHz Band (U.S. Version Only)
... 20
Receiver Accessories ................................... 21
Clariîšżer (Receiver Incremental Tuning) ........ 21
IF SHIFT 22 .......................................................
AGC (Automatic Gain Control) 22 ......................
Noise Blanker 23 ................................................
IPO (Intercept Point Optimization) 23 ................
ATT (Front End Attenuator) 23 ...........................
AM/FM DIAL.................................................. 24
Automatic Power-O󰀨 Feature ....................... 24
Transmitter Operation 25 ...................................
SSB Transmission ......................................... 25
Basic Setup/Operation 25 ...............................
VOX Operation 26 ...........................................
CW Transmission .......................................... 27
Operation using Straight Key/
External Keying Device 27 ..............................
Operation using Built-in Electronic Keyer 29 ...
FM Transmission ........................................... 30
Basic Setup/Operation 30 ...............................
Repeater Operation 30 ....................................
DCS Operation 32 ...........................................
ARTSTM (Auto Range Transpond System)
Operation 33 ....................................................
CW Identiîšżer Setup .................................... 33
Digital Mode Operation (SSB-Based AFSK)
.... 34
RTTY (Radio TeleType) Operation 34 .............
PSK31 Operation 35 .......................................
“USER” Dened Digital Modes ................... 36
Packet (1200/9600 bps FM) Operation 37 .........
AM Transmission .......................................... 38
Split Frequency Operation 38 ............................
Time-Out Timer ............................................. 39
Weather Fax Monitoring 39 ................................
Memory Operation 40 .........................................
QMB Channel 40 ...............................................
QMB Channel Storage 40 ...............................
QMB Channel Recall 40 ..................................
Memory Operation on “Regular”
Memory Channels 41 .........................................
Normal Memory Storage 41 ............................
Split-Frequency Memory Storage 41 ...............
Memory Channel Recall 42 .............................
Masking Memory 42 ........................................
Memory Operation on “HOME” Channel
Memories 43 ......................................................
HOME Channel Storage 43 .............................
HOME Channel Recall 43 ...............................
Labeling Memories 44 ........................................
Setting the Spectrum Scope Mode 45 .............
Activate the Spectrum Scope 45 .....................
Spectrum Scope Monitor Operation 45 ............
Smart Search™ Operation 46 ............................
Scanning Operation 47 ......................................
Scanning Operation 47 ......................................
Scan Skip Programming (Memory Mode Only)
...
48
Programmable Memory Scan (PMS) Operation
... 49
Dual Watch Operation 50 ...................................
Operation on Alaska Emergency
Frequency: 5167.5 khz (U.S. Version Only)
... 51
Menu Operation 52 .............................................
Cloning 63 ...........................................................
CAT System Programming 64 ...........................
CAT Data Protocol 65 ........................................
Constructing and Sending CAT Commands
... 65
Opcode Command Chart 66 ...........................
Installation of Optional Accessories 68 ...........
Optional Filters YF-122S/YF-122C/YF-122CN
... 68
Power-on Microprocessor Reset Procedure
... 69
Appendix 69 ........................................................
BAND DATA FORMAT 69 ..................................
Speciîšżcations ................................................ 70
1
Introduction
The FT-818 is a compact, innovative multiband, multimode portable transceiver for the
amateur radio MF/HF/VHF/UHF bands. Providing coverage of the 160-10 meter bands
plus the 6 m, 2 m, and 70 cm bands, the FT-818 includes operation on the SSB, CW, AM,
FM, and Digital modes, yielding the most comprehensive performance package available
for portable operation.
Designed for use with either an external DC power source or internal batteries. The
FT-818 provides 6 watts of power output from a 13.8-Volt external power supply. When
using the Ni-MH battery pack or Alkaline Battery Holder, the FT-818 will autoSBR-32MH -
matically reduce the output power (2.5 Watts or more).
The multi-function Liquid-Crystal Display includes Blue, Amber, and Violet backlighting,
which may be disabled for battery conservation. The display includes bar-graph indication
of power output, ALC voltage, SWR, and modulation level. Also include are a number of
operating status icons, as well as the function displays for the three operating function
keys ( , , and ).
Among the advanced features of the FT-818 are many incorporated only in large base-sta-
tion transceivers. These include Dual VFOs; Split-Frequency operation; IF Shift; Clariîšżer
(“R.I.T.”); IF Noise Blanker; AGC Fast/Slow/Auto/O󰀨 selection; RF Gain and Squelch con-
trol; IPO (Intercept Point Optimization) and a receiver front-end Attenuator; AM Aircraft
reception; AM and FM Broadcast reception; VOX; Built-in Electronic Keyer; Adjustable CW
Pitch; Automatic FM Repeater Shift (ARS); Built-in CTCSS Encoder/Decoders; ARTS™
(Auto-Range Transponder System); Smart Search™ Automatic Memory Loading System;
Spectrum Scope; 200 Memories plus Home Channels and Band-limiting Memories; Al-
pha-Numeric Labeling of Memories; Automatic Power-O󰀨 (APO) and Time-Out Timer (TOT)
functions; Computer Interface capability; and Cloning capability.
We urge you to read this manual in its entirety, so as to gain a full understanding of the
amazing capability of the exciting FT-818 Portable Transceiver.
