Seite 1/20
GS508XX / GS509XX
MOUNTING SET SUNSHADE TRIANGLE
MOUNTING SET SUNSHADE
SQUARE/ RECTANGLE
EN
Original Instructions 03
DE
Übersetzung Der Originalbetriebsanleitung 04
NL
Vertaling van de oorspronkelijke gebruiksaanwijzing
05
FR
Traduction de la notice originale 06
ES
Traducción del manual original 07
IT
Traduzione delle istruzioni originali 08
SV
Översättning av bruksanvisning i original 09
FI
Alkuperäisten ohjeiden käännös 10
NO
Oversatt fra orginal veiledning 11
DA
Oversættelse af den originale brugsanvisning 12
PL
Tłumaczenie instrukcji oryginalnej 13
RO
Traducere a instrucţiunilor originale 14
PT
Tradução do manual original 15
HU
Eredeti használati utasítás fordítása 16
CS
Překlad püvodního návodu k používání 17
TR
Orijinal talimatların çevirisi 18
WWW.VONROC.COM
2
A
A2 PCS 2 PCS
B3 PCS 4 PCS
C1 PCS 2 PCS
D12 PCS 16 PCS
E12 PCS 16 PCS
GS508XX GS509XX
CONTENT
EN
3
WWW.VONROC.COM
INSTALLING
Lay out the sunshade on the spot where it should
be placed and choose the most ideal mounting
points for the corners. It is important to have sturdy
mounting points and that they are pointed to the
center of the sunshade. The following can serve as
attachment points: walls, balustrades, balconies or
ground anchors. If you have any doubts about the
sturdiness of a construction, you should consult
an expert. The required strength of the construc-
tion depends on the size of the sunshade and the
amount of wind on site.
When determining the position, take into account
that there is some space in every corner to put
the sunshade under tension. It depends on the
individual sunshade how much space is needed,
but as a guideline you can use a space of 40cm at
each corner.
1. To fix the mounting plates (B) in concrete or
masonry, drill 4 holes per plate in the wall with
a diameter of 8mm.
2. Place the plugs (E) in the drilled holes and fix
the mounting plates with the screws (D).
3. With a rectangular sunshade, make sure that
you can stretch it diagonally as well as along
the long sides by using the turnbuckles (A) as
shown in figure A. For the other corners use a
carabiner (C).
4. Regularly check and retighten the turnbuckles.
WARRANTY TERMS
VONROC products are developed to the highest
quality standards and are guaranteed free of
defects in both materials and workmanship for the
period lawfully stipulated starting from the date of
original purchase. Should the product develop any
failure during this period due to defective material
and/or workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the product by unauthorized
service centers.
• Normal wear and tear.
• The product has been abused, misused or
improperly maintained.
• Non-original spare parts have been used. This
constitutes the sole warranty made by company
either expressed or implied. There are no other
warranties expressed or implied which extend
beyond the face hereof, herein, including the
implied warranties of merchantability and
fitness for a particular purpose. In no event
shall VONROC be liable for any incidental or
consequential damages. The dealers remedies
shall be limited to repair or replacement of
nonconforming units or parts.
The product and the user manual are subject to
change. Specifications can be changed without
further notice.
