Control Voltage Processor
Congratulations on obtaining your new Verbos Electronics Control Voltage
Processor. This Euro-Rack format module allows mixing, scaling, inverting,
crossfading, slewing, compressing, offsetting and modulating of not only control
voltages but any signals inside your modular synthesizer.
The Top Section
The top section of the module is a Slew Rate Processor with independent control
of the positive and negative moving voltages. In addition to the panel control for
each of these, there is a c.v. input for each with a reversing attenuator to scale
the control amount. A Trigger input and manual gate button will send the output
up to 8 volts at the Positive rate and back down at the Negative rate. The Shape
can be continuously swept from linear to curved, as expected from classic por-
tamento circuits. The curves are “true RC” in the sense that they are not created
using feedback, therefore they always start fast and end slow throughout the
voltage range from -11 volts to +11 volts. A Gate Out goes high for negative volt-
ages and low for positive ones and allows looping if it is patched to the trigger
in. Bounce, a feature unique to this module, allows control voltage to overshoot
its destination by an amount set by the control, at the rate of the Positive control.
This gives the effect of letting go of a tape machine’s reel and hearing the pitch
wobble.
The Lower Sections
The lower two sections are identical voltage processors. Inputs 1 and 2 have
reversing attenuators, allowing inverting, scaling, addition and subtraction. Inputs
3 and 4 are a voltage controlled crossfader, which can also be used as a VCA
that opens or closes with voltage or even a 4 quadrant modulator. The Offset
control will add or subtract a xed voltage to the mix. The voltage range of these
processors is more than +/-11 volts.
18HP • 240g • +12v 85mA • -12v 83mA
c.v. output
Shape control Negative control
Bounce
control
Voltage Processor
Offset control
Gate output
Select c.v. input
(crossfades between inputs 3 & 4)
Positive control
input reversing
attenuators
Select control
Slew Rate Processor
Trigger input
c.v. output
c.v. inputs
c.v. input
Trigger button
