Issue 3
1 947934
V-9934
+-
Remote Mic In
V-9933A
One pair of a twisted
pair telephone wire.
Up to 1000 ft.
V-9934
REMOTE MICROPHONE
GENERAL
The V-9934 is a Remote Microphone for use
with the V-9933A, Noise Sensing Volume
Control.
SPECIFICATIONS
Purpose
The V-9934 provides remote noise sensing for
the V-9933A.
Features
• Self-contained microphone and pre-amp
• Phantom powered; no power supply
required
• Screw terminal connections
• Up to four units may be paralleled on one
V-9933A
• Each V-9934 may be on a 1000’ wire run
• Uses CAT3/5/5e/6 twisted pair telephone
cable (One pair)
Dimensions/Weight
• 1.50" H x 2.90" W x .81" D
(3.81cm H x 7.37cm W x 2.06cm D)
• 1.0 oz. (.03 kg)
Mounting
The V-9934 is designed for wall mounting.
When mounting this unit in a noisy area, make
sure that the front is not obstructed in any way.
It should be mounted in the noisy area 12-15
feet high. Care should be taken not to mount
the V-9934 directly adjacent to any noise
sources such as HVAC blowers, ceiling fans,
conveyors, etc.
Wiring Diagram
TECHNICAL ASSISTANCE
When trouble is reported, verify connections to
the V-9933A.
2
Assistance in troubleshooting is available from
the factory. When calling, you should have a
VOM and a telephone test set available and be
calling from the job site. Call (540) 563-2000 for
Technical Support, or visit our website at
http://www.valcom.com.
The V-9934 is not field repairable. Valcom
equipment contains no user serviceable
parts inside. Valcom, Inc. maintains service
facilities in Roanoke, VA. Should repairs be
necessary, attach a tag to the unit clearly stating
your company name, address, phone number,
contact person and the nature of the problem.
Send the unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
VALCOM LIMITED WARRANTY
Valcom, Inc. warrants its products to be free from defects in materials and workmanship under conditions of normal use and service
for a period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or
refund of any such defective device within the warranty period, provided that:
1. inspection by Valcom, Inc. indicates the validity of the claim;
2. the defect is not the result of damage, misuse or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (A service
charge plus parts and labor will be applied to units defaced or physically damaged);
4. freight charges for the return of products to Valcom are prepaid;
5. all units ‘out of warranty’ are subject to a service charge. The service charge will cover minor repairs (Major repairs will
be subject to additional charges for parts and labor).
This warranty is in lieu of and excludes all other warranties, expressed or implied, and in no event shall Valcom, Inc. be
liable for any anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection
with the purchase, operation or use of the product.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the
carrier should be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the
F.O.B. point.
Headquarters:
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019-5056
Phone: (540) 563-2000
FAX: (540) 362-9800
