Document Number 411-0058-41 Rev A – August 2022
User Guide for the
Vaddio IR Remote Controller
August 2022
998-2105-000 (Worldwide)
Installing the Batteries
The remote uses two AAA batteries.
1. Remove the cover from the back of the remote. You may need to press down on the
upper edge while sliding it off.
2. Install the batteries as shown in the diagram in the battery opening.
3. Slide and snap the cover back into place.
Tips for Using the Remote
Presets: The remote provides access to camera presets. Your camera’s web interface may
provide access to additional camera presets.
Camera selection: The remote has three IR channels, so it can control up to three
cameras independently. Check your camera’s manual for information on setting it as
camera 1, camera 2, or camera 3. By default, Vaddio cameras respond as camera 1
Troubleshooting tip: If the camera does not respond to the remote, press the Camera 1 button and try
again. If that doesn’t fix the problem, try the other camera selection buttons.
Auto-framing cameras: Auto-framing pauses when you press any button that affects the shot (arrows,
home, zoom, presets).
IR Remote Controller Quick Reference
The remote may have controls for capabilities that your camera does not have. Some
buttons behave in different ways depending on the camera’s capabilities.
Power button and indicator – Set the camera to standby mode, or
return to full-power mode.
Arrow buttons – Pan and tilt.
Home button – Function depends on the model of camera. For Auto-
framing cameras, press to resume auto-framing.
Network button – Display the camera's IP address on the video
output(s).
Backlight button – Adjusts for excess light behind the camera’s
subject.
Mute button – Mute connected or built-in microphone(s).
Volume +/– button – Increase or decrease the volume from the
connected or built-in speaker.
Focus +/– buttons – Adjust the focal distance in or out, when Manual
focus mode is selected.
Zoom +/– button– Increase or decrease the zoom.
Focus Auto/Man buttons – Select automatic or manual focus.
Pan Dir buttons – Set pan direction relative to the person using the
remote. Std is from the camera’s perspective. Rev is from the
perspective of a person facing the camera.
Set, Clr, and Preset buttons – Set, clear, or select preset shots.
User Guide for the Vaddio IR Remote Controller
2
Vaddio is a brand of Legrand AV Inc.· · Phone 800.572.2011 / +1.763.971.4400 ·www.legrandav.com
Fax +1.763.971.4464 · Email ·av.vaddio.support@legrand.com
Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for
identification purposes and are trademarks of their respective owners. All patents are protected under
existing designations. Other patents pending.
©2022 Legrand AV Inc.
Storing and Clearing Presets
Depending on the camera, presets may store zoom, pan/tilt location, color settings, or some combination
of these.
Your camera may have additional presets available through its web interface.
To store a preset:
Set up the shot. Then hold down the button and press one of the numbered preset buttons.Set
To clear a preset:
Press and hold the button while pressing the number of the preset you want to clear.Clr
User Guide for the Vaddio IR Remote Controller
