Seite 1/28
Outdoor LP Gas Barbecue Grill
Model No. GBC1405SP
Manufactured in China for: Blue Rhino Global Sourcing, Inc.
Winston-Salem, NC 27105 USA ‱ 1.800.762.1142 ‱ BlueRhino.com
© Blue Rhino Global Sourcing, Inc.
UniFlameÂź is a trademark of Blue Rhino Global Sourcing, Inc. GBC1405SP-OM-100 EF
Table of Contents
Important Safeguards Page 2...........................................
Expanded View & Hardware 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assembly Instructions 5...............................................
Installing LP Gas Tank 9...............................................
Inserting and Securing LP Gas Tank 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting LP Gas Tank 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disconnecting LP Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operating Instructions 9...............................................
Checking for Leaks............................................... 9
Operating Main Burners 9 ...........................................
Cleaning and Care 10 ................................................
Product Registration 10...............................................
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Limited Warranty ................................................. 11
Troubleshooting 12 ..................................................
The use and installation must conform with local codes or, in the absence of local
codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas
and Propane Installation Code, CSA B149.1, Propane Storage and Handling Code, or
B149.2, Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, CSA or the and
Z240 RV Series, Recreational Vehicle Code, as applicable.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
If you are assembling this unit for someone else, give this manual to him or her to
read and save for future reference.
OWNER’S MANUAL
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
WARNING
FOR YOUR SAFETY:
1. Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly before
installing or servicing this equipment.
3. Failure to follow these instructions could
result in ïŹre or explosion, which could cause
property damage, personal injury, or death.
4. This instruction manual contains important
information necessary for the proper
assembly and safe use of the appliance.
5. Read and follow all warnings and
instructions before assembling and using
the appliance.
6. Follow all warnings and instructions when
using the appliance.
7. Keep this manual for future reference.
DANGER
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
WARNING
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
DANGER
Never operate this appliance unattended.
Made from 75% Bagasse
(environmentally friendly sugar
cane pulp by-product)
Outdoor LP Gas Barbecue Grill
Model No. GBC1405SP
2
WThis grill is for outdoor use only, and should not be used in a building,
garage or any other enclosed area.
WDo NOT operate, light or use this appliance within ten feet (3.05 m) of
walls, structures or buildings.
WFor residential use only. This grill is NOT for commercial use.
WThis grill is not intended for and should never be used as a heater. TOXIC
fumes can accumulate and cause asphyxiation.
WThis grill is safety certified for use in the United States and/or Canada
only. Do modify for use in any other location. Modification will NOT
result in a safety hazard and will void your warranty.
WThis grill, from the factory, is for use with liquid propane (LP) gas only.
The conversion to or attempted use of natural gas in this LP gas grill is
dangerous, may cause bodily harm and will void your warranty.
WLP gas characteristics:
a. LP gas is flammable and hazardous if handled improperly. Become
aware of the characteristics before using any LP gas product.
b. LP gas is explosive under pressure, heavier than air, and settles/
pools in low areas.
c. LP gas in its natural state has no odor. For your safety, an odorant is
added that smells like rotten cabbage.
d. Contact with LP gas can cause freeze burns to skin.
WApartment dwellers: Check with management to learn the requirements
and fire codes for using a LP Gas grill in your apartment complex.
If allowed, use outside on the ground floor with a ten foot (3.05 m)
clearance from any structure. Do NOT use on or under balconies.
WLP gas cylinder needed to operate. Only cylinders marked “propane”
may be used.
WThe LP gas cylinder must be constructed and marked in accordance
with the of the U.S. Department Specifications for LP-gas Cylinders
of Transportation (D.O.T.) or the National Standard of Canada, CAN/
CSA-B339, Cylinders, Spheres and Tubes for the Transportation of
Dangerous Goods; and Commission.
WLP gas cylinder must be arranged for vapor withdrawal.
WThe LP gas cylinder must have a listed overfilling prevention device
(OPD).
WOnly use LP gas cylinders equipped with a cylinder connection device
compatible with the connection for outdoor cooking appliances.
WThe LP gas cylinder must have a cylinder collar to protect the cylinder
valve.
WNever use a LP gas cylinder with a damaged body, valve, collar or
footing.
WDented or rusted LP gas cylinders may be hazardous and should be
checked by your LP gas supplier prior to use.
WThe LP gas cylinder should not be dropped or handled roughly.
WLP gas cylinders must be stored outdoors out of the reach of children
and must not be stored in a building, garage or any other enclosed area.
Your cylinder must never be stored where temperatures can reach over
125°F.
WDo NOT insert any tool or foreign object into the valve outlet or safety
relief valve. You may damage the valve and cause a leak. Leaking
propane may result in an explosion, fire, severe personal injury or death.
WDo NOT block holes in sides or back of grill.
WNever keep an LP gas cylinder in a hot car or car trunk. Heat will cause
the gas pressure to increase, which may open the relief valve and allow
gas to escape.
WPlace dust cap on cylinder valve outlet whenever the cylinder is not in
use. Only install the type of dust cap on the cylinder valve outlet that is
provided with the cylinder valve. Other types of caps or plugs may result
in leakage of propane.
WIf grill is not in use, the gas must be turned off at the supply cylinder
and disconnected.
WDo NOT store a spare LP gas cylinder under or near this appliance.
WNever fill the cylinder beyond 80 percent full.
WA fire causing serious injury or damage to property may occur if the
above is not followed exactly.
WNever attempt to attach this grill to the self-contained LP gas system of
a camper trailer, motor home or house.
WNever use charcoal, lighter fluid, lava rocks, gasoline, kerosene or
alcohol with this product.
WYour grill has been checked at all factory connections for leaks.
Recheck all connections as described in the “Operating Instructions”
section, as shipping can loosen connections.
WCheck for leaks even if your unit was assembled for you by someone
else.
WDo NOT operate if a gas leak is present. Gas leaks may cause a fire or
explosion.
WYou must follow all instructions in “Checking for Leaks” section before
operating. To prevent fire or explosion hazard when testing for a leak:
a. Always perform a leak test before lighting the grill and each time
the cylinder is connected for use.
b. No smoking. Do NOT use or permit sources of ignition in the area
while conducting a leak test.
c. Conduct the leak test outdoors in a well-ventilated area.
d. Do NOT use matches, lighters, or a flame to check for leaks.
e. The use of alcohol, prescription or non-prescription drugs may
impair the consumer’s ability to properly assemble or safely operate
the appliance.
f. Strong odors, colds, sinus congestion, etc. may prevent the
detection of propane. Use caution and common sense when testing
for leaks.
g. Do NOT use grill until any and all leaks are corrected. If you are
unable to stop a leak, disconnect the LP gas supply. Call a gas
appliance serviceman or your local LP gas supplier.
WThis grill is designed to operate at an inlet pressure of: 11 inches water
column.
WDo NOT store or use gasoline or other flammable liquids or vapors
within 25 feet (7.62 m) of this appliance.
WDo NOT use in an explosive atmosphere. Keep grill area clear and free
from combustible materials, gasoline and other flammable vapors and
liquids.
WMinimum clearance from sides and back of unit to combustible
construction is 36 inches (91.4 cm). Do NOT use this appliance under
any type of overhang or roof.
WIt is essential to keep the grill’s valve compartment, burners and
circulating air passages clean.
WInspect grill before each use.
WDo NOT alter grill in any manner. Any alteration will void your warranty.
WDo NOT use the grill unless it is COMPLETELY assembled and all parts
are securely fastened and tightened.
WDo NOT build this model of grill in any built-in or slide in construction.
Ignoring this warning could cause a fire or an explosion that can
damage property and cause serious bodily injury or death.
WThis grill should be thoroughly cleaned and inspected on a regular
basis.
WClean and inspect the hose before each use of the appliance. If there
is evidence of abrasion, wear, cuts or leaks, the hose must be replaced
prior to operation.
WUse only the regulator and hose assembly provided. Use only the
replacement regulator and hose assembly specified by Blue Rhino
Global Sourcing, Inc.
WUse only Blue Rhino Global Sourcing, Inc. factory authorized parts. The
use of any part that is not factory authorized can be dangerous and will
void your warranty.
WDo NOT operate this appliance without reading “Operating Instructions”
in this manual.
WDo NOT touch metal parts of grill until they have completely cooled
(about 45 min.) to avoid burns, unless you are wearing protective gear
(pot holders, gloves, BBQ mittens, etc.).
WDo NOT install or use in or on boats or recreational vehicles.
WDANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage
to property.
WWARNINGS:
Important Safeguards
Need help? 1.800.762.1142
Do not return to place of purchase.
Recipes
BlueRhino.com/recipes
Replacement Parts
parts.BlueRhino.com /
1.800.762.1142
3
WWhen cooking, fire extinguishing materials should be readily accessible.
In the event of an oil/grease fire, do not attempt to extinguish with
water. Use type BC dry chemical fire extinguisher or smother with dirt,
sand or baking soda.
WDo NOT use grill in high winds.
WNever lean over the grill when lighting.
WDo NOT leave a lit grill unattended. Keep children and pets away from
grill at all times.
WDo NOT leave grill unattended while preheating or burning off food
residue on high. If grill has not been cleaned, a grease fire can occur
that may damage the product.
WDo NOT place empty cooking vessels on the appliance while in
operation.
WUse caution when placing anything on the grill while the appliance is in
operation.
WDo NOT attempt to move grill when in use. Allow the grill to cool before
moving or storing.
WLP gas cylinder must be properly disconnected and removed prior to
moving this grill.
WStorage of grill indoors is permissible only if the cylinder is
disconnected, removed from the grill and properly stored outdoors.
WAlways open grill lid carefully and slowly as heat and steam trapped
within grill can cause severe burns.
WDo NOT attempt to disconnect the gas regulator from the cylinder or any
gas fitting while the grill is in use.
WAlways place your grill on a hard, non-combustible, level surface. An
asphalt or blacktop surface may not be acceptable for this purpose.
WMove gas hoses as far away as possible from hot surfaces and dripping
hot grease.
WKeep all electrical cords away from a hot grill.
WAfter a period of storage and/or nonuse, check for leaks, burner
obstructions and inspect for any abrasion, wear or cuts to the hose.
WFailure to open lid while igniting the grill’s burners, or not waiting 5
minutes to allow the gas to clear if the grill does not light, may result in
an explosive flame-up.
WNever operate grill without its heat plates installed.
WAlways use a meat thermometer to ensure food is cooked to a safe
temperature.
WUse protective gloves when assembling this product.
WDo NOT force parts together as this can result in personal injury or
damage to the product.
WNever cover entire cooking area with aluminum foil.
WDeaths, serious injury or damage to property may occur if the above is
not followed exactly.

Produktspezifikationen

Marke: Uniflame
Kategorie: Grill
Modell: GBC1405SP

Brauchst du Hilfe?

Wenn Sie Hilfe mit Uniflame GBC1405SP benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Grill Uniflame

Uniflame

Uniflame GBC1405SP Bedienungsanleitung

24 August 2024

Bedienungsanleitung Grill

Neueste Bedienungsanleitung fĂŒr -Kategorien-

Tefal

Tefal CB2231 Easy Grill Comfort Bedienungsanleitung

10 Oktober 2024
Neff

Neff N64K40N0 Bedienungsanleitung

7 Oktober 2024
Barbecook

Barbecook Party Quickstart Bedienungsanleitung

5 Oktober 2024
Tristar

Tristar SA-2146 Bedienungsanleitung

4 Oktober 2024
Roesle

Roesle MAGNUM PRO G3 Bedienungsanleitung

2 Oktober 2024
Roesle

Roesle No.1 F60 AIR Bedienungsanleitung

2 Oktober 2024
Roesle

Roesle Smoker No.1 F50-S Bedienungsanleitung

2 Oktober 2024
Roesle

Roesle Videro G4 Bedienungsanleitung

2 Oktober 2024
Dacor

Dacor OBC36 Bedienungsanleitung

2 Oktober 2024
Trebs

Trebs Comfortcook 99314 Bedienungsanleitung

30 September 2024
