Seite 1/20
Manual
Belt sander
LIBA-4X24N3
Model Code
LIBA-4X24N3
Applies for:
100370
Power Sanding belt
4”x 24”1 200 W
ENGLISH
ESPAĂ‘OL
CAUTION Read this manual thoroughly
before using the tool.
2
Technical data
Power requirements
General power tool safety warnings
Safety warnings for belt sander
Parts
Start up
Maintenance
Authorized Service Centers
Warranty policy
3
3
4
5
5
6
8
9
10
LIBA-4X24N3
ENGLISH
CAUTION
Contents
Keep this manual for future references.
The illustrations in this manual are for reference
only. They might be different from the real tool.
To gain the best performance of
the tool, prolong the duty life,
make the Warranty valid if
necessary, and to avoid hazards
of fatal injuries please read and
understand this Manual before
using the tool.
IP Grade IP20
3
LIBA-4X24N3
100370
4” x 24”
Class II
60 Hz
Belt sander
16 AWG x 2C with insulating temperature of 221 °F
1200 W
Code
Description
Belt
Voltage
Frequency
9,4 A
Current
Power
50 minutes work per 20 minutes idle. Maximum 6 hours per day.
Duty cycle
Conductors
Insulating
Power cord grips used in this product: Type “Y”.
Build quality: Reinforced insulation.
Thermal insulation on motor winding: Class E.
127 V
Technical data
Power requirements
ENGLISH
Tools with double insulation and reinforced insulation are
equipped with a polarized plug (one prong is wider than the other). This plug will
only fit in the right way into a polarized outlet. If the plug cannot be introduced into
the outlet, reverse the plug. If it still doesn’t fit, call a qualified electrician to install
for you a polarized outlet. Do not alter the plug in any way. Both types of insulation
eliminate the need of both a grounded third power cord with three prongs or a
grounded power connection.
When using an extension cable, verify the gauge is enough for
the power that your product needs. A lower gauge cable will cause voltage drop in the line, resulting in power loss and
overheating. The following table shows the right size to use depending on cable’s length and the ampere capability
shown in the tool’s nameplate. When in doubt use the next higher gauge.
WARNING
WARNING
from 0 A and up to 10 A
from 10 A and up to 13 A
from 13 A and up to 15 A
from 15 A and up to 20 A
18 AWG(*)
16 AWG
14 AWG
8 AWG
16 AWG
14 AWG
12 AWG
6 AWG
3 (one grounded)
from 6 ft to 49 ft | higher than 49 ft
Ampere
Capacity Number of
Conductors Extension gauge
* It is safe to use only if the extensions have a built-in artifact for over current protection.
AWG = American Wire Gauge. Reference: NMX-J-195-ANCE
WARNING
WARNING Avoid the risk of electric shock or severe injury. When the power cable gets damaged
it should only be replaced by the manufacturer or at a Authorized Service Center.
The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use.
Do not expose to rain, liquids and/or dampness.
Before gaining access to the terminals all power sources should be disconnected.
WARNING When operating power tools outdoors, use a grounded
extension cable labeled “For Outdoors Use”. These extensions are specially designed for
operating outdoors and reduce the risk of electric shock.
500 m/min
Speed
