2001 East Terra Lane | O’Fallon, MO 63366-4434 | p 636.240.2400 | f 636.272.7546 | true-residential.com | info@true-residential.com
Specifications subject to change without notice.
A D A H E I G H T
BP_210945_05.23
1 5 S TAINL E S S S O L I D DOO R C L E A R I C E MAC H I NE – A D A"
T U I A D A - 1 5 -R S -A ~ S
T U I A D A - 1 5 -R S / L S -A ~ S
TUI A DA-15-RS -A ~S (Right hi nged )
TUI A DA-15-LS-A~S (Lef t hinged)
F E AT U R E S
• Articulating, soft close hinge allows fully integrated, flexible
installations.
• Produces up to 75lbs. of clear ice per day with a storage
capacity of 28lbs.
• Bin Level Control for entertaining flexibility (50%, 65%, 70%,
85%, 100%).
• Patented TruLumina® LED lighting gently illuminates your
product and allows you to choose from 14 different color
options with the push of a button.
• Concealed digital control located behind toekick.
• Exclusive True Magna Scoop for easy storage on door.
• Industry exclusive, standard built-in drain pump.
• External water filter kit included – rated up to 1250 gallons.
• Automatic cleaning system.
• All undercounter models UL rated for outdoor use.
• Environmentally friendly R290 refrigerant.
• Energy Star rated.
B U I L D Y O U R T R U E
Customize your True with a variety of finish and hardware
options at .
true-residential.com/custom
S P E C I F I C AT I O N S
Dimensions (w x h x d) 147
/8" x 317
/8" x 2319/32"
Cutout Dimensions (w x h x d) 15" x 32" x 24"
Operating Requirements
Air Temperature
Water Temperature
Water Pressure (PSIG)
40˚F – 100˚F
40˚F – 100˚F
20 – 80
Maximum Ice Capacity (lbs/day)
Rated Ice Capacity (lbs/day)
Rated Ice Storage (lbs)
Rated Energy Consumption
(kWh/lbs)
Rated Water Consumption (Gal/lbs)
75
75
28
6.65 / 100
24.2 / 100
Plumbing
Water Supply: ¼" OD copper,
braided stainless steel or PEX
tubing and compression fittings
(not included).
Drain Pump Connection: 1/2" NPT.
Weight (lbs.) 140
Voltage 115/60/1
Amps 2.85
Power Cord Length (ft.) 9
Energy Star Rated Yes
2001 East Terra Lane | O’Fallon, MO 63366-4434 | p 636.240.2400 | f 636. 272.7546 | true-residential.com | info@true-residential.com
Specifications subject to change without notice.
A D A H E I G H T
BP_210945_05.23
14 7/8"
377mm
31 7/8"
810mm
3 7/8"
99mm
15/16"
24mm
23 19/32"
599mm
3 23/32"
95mm
25 1/2"
648mm
90°
16 7/8"
428mm
38"
965mm
1 23/32"
44mm
POWER CORD
2 9/32"
58mm
WATER LINE
3 21/32"
93mm
DRAIN LINE
4 31/32"
126mm
7 17/32"
191mm
2 7/16"
62mm
1 5 S T A I N L E S S S O L I D D O O R C L E A R I C E M AC H I N E – A D A"
M O D E L O P T I O N S
M O D E L F I N I S H
TUIADA-15-RS-A~S Stainless solid door right-hinged
TUIADA-15-LS-A~S Stainless solid door left-hinged
A C C E S S O R I E S ( O P T I ON A L )
Descaling solution
Replacement water filter
Anti-condensation pads
W A R R A N T Y
2 year full (parts & labor)
5 year sealed system (parts & labor)
T U I A D A - 1 5 -R S / L S -A ~ S
F R O N T S I D E B A C KT O P
O P E N I N G D I M E N S I O N S
ROUGH
OPENING
HEIGHT
32" min
ROUGH
OPENING
WIDTH
15" min
ROUGH
OPENING
DEPTH
24" min
