Owner’s Manual
SmartOnline®
Single-Phase 8kVA—10kVA
Intelligent True On-Line UPS Systems (Rack-Mount/Tower)
Includes power module, external battery module and PDU
Detachable PDU features outlets and maintenance bypass switch*
Rack-Mount and tower adaptable
*An optional detachable hardwire PDU is available; contact Tripp Lite for details.
Not suitable for mobile applications.
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Important Safety Warnings 2
Mounting 3
Features 4
Connection 6
Optional Connection 8
Manual Bypass Operation 9
Specifications 11
Operation 12
Storage and Service 26
Warranty and Product Registration 26
Español 27
Français 53
Русский 79
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
2
Important Safety Warnings
SAVE THESE INSTRUCTIONS.
This manual contains important instructions and warnings that should be followed during the installation and maintenance of
all Tripp Lite SmartOnline Rack-Mount/Tower UPS Systems and their batteries.
UPS Location Warnings
Install your UPS indoors, away from excess moisture or heat, direct sunlight, dust and conductive contaminants.
Install your UPS in a structurally sound area. Your UPS is extremely heavy; take care when moving and lifting the unit.
Only operate your UPS at indoor temperatures between 32° F and 104° F (between 0° C and 40° C). For best results, keep indoor
temperatures between 62° F and 84° F (between 1 C and 29° C).
Leave adequate space around all sides of the UPS for proper ventilation.
Do not install the UPS near magnetic storage media, as this may result in data corruption.
Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this manner will seriously inhibit the unit's
internal cooling, eventually causing product damage not covered under warranty.
UPS Connection Warnings
Isolate the UPS before working on this circuit.
Required Protective Devices and Cable Cross-Sections.
Recommended upstream protection.
UPS wer Rating Upstream Circuit BreakerPo
8kV
A D
cur 50Ave
10kV
A D
cur 60Ave
G L1
L1
2 poles circuit breaker
To UPS Normal sourceAC
L2(N)
L2(N)
The power supply for this unit must be single-phase rated in accordance
with the equipment nameplate. It also must be suitably grounded.
Equipment Connection Warnings
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life
support equipment or to significantly affect its safety or effectiveness is not recommended.
Connect your UPS power module’s grounding terminal to a grounding electrode conductor.
The UPS is connected to a DC energy source (battery). The output terminals may be live when the UPS is not connected to an AC supply.
Maintenance Warnings
Your UPS power module and battery module(s) do not require routine maintenance. Do not open them for any reason. There are no user-
serviceable parts inside.
Battery Warnings
Do not operate your UPS without connecting it to an external battery module.
Connect only Tripp Lite battery modules to your UPS power module’s external battery connector.
Batteries can present a risk of electrical shock and burn from high short-circuit current. Observe proper precautions. Do not dispose of the
batteries in a fire. Do not open the UPS or batteries. Do not short or bridge the battery terminals with any object. Unplug and turn off the
UPS before performing battery replacement. Use tools with insulated handles. There are no user-serviceable parts inside the UPS. Battery
replacement should be performed only by authorized service personnel using the same number and type of batteries (Sealed Lead-Acid).
The batteries are recyclable. Refer to your local codes for disposal requirements or visit tripplite.com/support/recycling-program for recycling
information. Tripp Lite offers a complete line of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at tripplite.
com/products/battery-finder/ to locate the specific replacement battery for your UPS.
Do not open or mutilate the batteries. Released electrolyte is harmful to the skin and eyes, and may be toxic.
Fuses should be replaced only by factory authorized personnel. Blown fuses should be replaced only with fuses of the same number and type.
Service and repair should be done only by trained personnel. During any service work to the UPS, it should be turned off or manually
bypassed via the transformer. Note that potentially lethal voltages exist within this unit as long as the battery supply is connected.
Do not connect or disconnect battery module(s) while the UPS is operating from the battery supply or when the detachable PDU is not in
bypass mode.
During “hot-swap” battery module replacement your UPS will be unable to provide battery backup in the event of a blackout.
Only connect compatible battery module(s).
Legend.
B Contactor solenoid.
Q Mains input thermal-magnetic itchsw
T Two-pole contactor 100 A 1; coil ltage: according to the mains input.AC vo
Remar
k: Q needs to use the approved component of Safety Certification.
External po rwe
distribution unit UPS
L
Q
B
T
N
L
N
3
Mounting (Rack)
4-Post Mounting
1 The included plastic pegs A will temporarily support the empty rack-mount shelves B
while you install the permanent mounting hardware. Insert a peg near the center of the
front and rear bracket of each shelf as shown (each front bracket has 6 holes and each
rear bracket has 3 holes). The pegs will snap into place.
After installing the pegs, expand each shelf to match the depth of your rack rails. The
pegs will fit through the square holes in the rack rails to support the shelves. Refer to the
rack unit labels to confirm that the shelves are level in all directions.
Note: The support ledge of each shelf must face inward.
2 Secure the shelves B to the mounting rails permanently using the included screws and
cup washers C as shown.
For 2U equipment mounting, place 4 screws total at the front and 4 screws total at the
back.
For 3U equipment mounting, place 6 screws total at the front and 4 screws total at the
back.
Tighten all screws before proceeding.
Warning: Do not attempt to install your equipment until you have inserted and
tightened the required screws. The plastic pegs will not support the weight of your
equipment.
3 Attach mounting ears D to the front mounting holes of your equipment E using the
screws provided F. The ears should face forward.
4 Using an assistant, lift your equipment and slide it onto the mounting shelves. Attach your
equipment to the rack by passing the screws, nuts and washers (user-provided) G
through its mounting ears and into the rack rails.
5 (Optional) Attach 2 PDU hanger brackets to the right-side, rear mounting rail using
included screws and cage nuts. Important: determining where to attach your PDU hanger
brackets will depend on your rack configuration. Generally it is recommended to mount
the top bracket in the bottom two square holes of the U space that the UPS and PDU are
mounted in. The second bracket should be installed 3U measures down and placed in the
top two square holes of the U. (For example: If the PDU and UPS are mounted in 7U, the
first bracket will be installed in the bottom two square holes of 7U. The second bracket
would be installed in the top two square holes of 4U.
Mount your equipment in either a 4-post or 2-post rack or rack enclosure. The user must determine the fitness of hardware and procedures
before mounting. If hardware and procedures are not suitable for your application, contact the manufacturer of your rack or rack enclosure.
The procedures described in this manual are for common rack and rack enclosure types and may not be appropriate for all applications.
Note: The power module and battery module must be installed in separate shelves.
2-Post Mounting (Optional)
To mount your equipment in a 2-post rack, you must purchase a Tripp Lite 2-Post Rackmount Installation Kit (model: 2POSTRMKITWM, sold
separately) for each module installed. See the Installation Kit’s owner’s manual for complete mounting instructions.
3
E
D
G
F
4
1
BB
A
A
A
2
2
B
B
B
B
C
C
C
C
7
6
5
4
Mount Here
