01 / Before You Start

• Separate load wires for fan and light are required.

• A neutral wire is required to install the smart switch.

• The smart switch is designed for single-pole (one

location) wiring (not compatible with 3-way/multi-way

switch wiring).

• Supported fan type: speed control (most AC motor

pull-chain ceiling fans) with a recommended rating of

less than 60W.

• For optimal fan performance, please manually adjust the

fan speed to the highest settings with the independent

speed control of your fan, (e.g., pull chain).

• use to control exhaust fans, DC motor fans, and DO NOT

fans with integrated fan speed controls (i.e., fans with

remote control or Bluetooth/Wi-Fi enabled).

Line up the smart switch with the mounting holes. Secure

it with screws.

Ensure the UP arrow on the back of the wallplate points up

and attach the wallplate. Then turn on the circuit breaker.

3Unscrew the old switch and pull it out of the wallbox Use a .

voltage detector to test all wires connected to the old switch

and in the wallbox to conrm that all power is o for the

wallbox.

CAUTION !

1. - The product should be installed by a Risk of Electric Shock

qualied electrician.

2. - Disconnect power supply before servicing. High Voltage

02 / Wire Your Switch

1Turn o turn othe light and fan of the old switch and the

circuit breaker. Check whether your power is o by turning

your fan and light on and o a few times. Make sure your old

switch is turned o before continuing wiring.

OFF

3) Turn o the circuit breaker. Use a voltage detector to test

all wires connected to the old switch and in the wallbox to

conrm that all power is o. Label the energized wire as

the . Line wire

OFF

1) Turn on your light switch, turn o your fan switch, and turn

on the circuit breaker to see that your light is working.

2) Use a voltage detector to identify the energized wire

among the two load wires. This should be the load wire of

your light switch.

3) Turn o the circuit breaker and the light switch. Use a

voltage detector to test all wires connected to the old

switch and in the wall box to conrm that all power is o.

Label the energized wire as . Then label the Lighting Load

other one as .Fan Load

1. Turn Power O & Pull Out the Old Switch

• : Usually a bundle of white wires, not connected to Neutral

the old switch. They may be folded up in the very back of

your wallbox. If the old switch is smart, then the neutral wire

may be connected to the switch.

• : Usually a green or bare copper wire. Ground

• : Usually black. One end is connected to Line (Live/Hot)

the circuit breaker, the other to your old switch.

• : Usually black or red. One end is connected to the Load

switch, the other to your electrical device.

Get to know the wires in your wall box.

Note: The wire colors used in this guide are recommended by the

National Electric Code (NEC). Your actual wire colors may vary.

Note: If you nd your old switch or other metal parts are still

energized, please consult a qualied electrician for help.

Note: If you nd more than one wire is energized, please refer to:

https://www.tp-link.com/support/faq/3682/

Note: DO NOT remove any wires.

2. Identify the Wires

1Disconnect all wires from the old switch, and connect them

to the smart switch as below. Check that all the wires are

correct. Pull gently to make sure each wire is secure.

3. Remove Old Switch and Install Smart Switch

Tools You’ll Need

• Electrical Detector

• Philips or Slotted Screwdriver • Pliers

• Electrical Insulated Gloves

(Recommended)

*Images may dier from your actual product.

Smart Ceiling Fan Control

and Dimmer Switch

Quick Start Guide

2Remove the wallplate of your old switch and use a voltage

detector to test terminals and other metal parts of the old

switch to conrm that all power is o for the switch.

Fan Light

Identify and label the and wires in the wall Ground Neutral

box.

Identify the , , and wires of the Line Fan Load Lighting Load

old switch according to their wire colors and the existing

marks, if any, and label them with the provided wire labels.

5Identify and label the and wires.Lighting Load Fan Load

4Identify and label the wire.Line

1) Turn on the circuit breaker. Make sure your old light and fan

switch is turned o.

Take care to avoid electric shocks.

Line wire

L n Loadighti g

F oadan L

L n Loadighti g

F oadan L

Installation Guide & FAQs:

Scan QR code or visit

https://www.tp-link.com/support/faq/3682/

Take care to avoid electric shocks.

Fan Light

OFF

Flip the page over to continue.

F oadan L

L n Loadighti g

Fan Light

Light Load

2) Use a voltage detector to identify the energized wire

( ). Line wire

Note: Take a photo of the old switch wiring conditions for later

reference. Make sure all labels and wires are clearly displayed in

the picture.

The recommended wiring order: Ground > Neutral > Fan &

Lighting Load > Line.

If you cannot identify and label the Line, Fan Load, and

Lighting Load wires, you can follow and to make it. Steps 4 5

Otherwise, you can skip and . Steps 4 5

Detach the Wallplate

1. DOWNLOAD KASA

2. SET UP

3. THIRD-PARTY SERVICES

Tap the + button in the app and select and Smart Switch

then your model Then follow the step-by-step app .

instructions to set up your smart switch.

Kasa works with Alexa, Google Assistant, and other

third-party services to control your switch by voice.

Go to in the Kasa Smart Me > Third-Party Services

app to integrate Third-Party Services.

03 / Set Up Your Switch

Get the app from the App Store or Kasa Smart

Google Play.

SpecicationsTroubleshooting

Rating: 120V~ 60Hz

Lighting Load: 300W INC/HAL, 150W LED

Light Dimming Type: Leading Edge Dimming / TRIAC Phase Cut

Ceiling Fan Load: 1.5A Max Load, 4-Speed

Supported Fan Type: AC Motor Speed Control

Switch Type: E.D. (Lighting), μ (Fan)

Operation Temperature: 0~40℃

Required Outlet Box Dimensions: H > 2.95 in./75 mm, W > 1.81

in./46 mm, D > 2 in./51 mm

Operating Control, Type 1 action

Pollution Degree 2, Rated Impulse Voltage 2500 V

Software Class A, NEMA Type 1

Need some help?

Visit https://www.tp-link.com/support

for technical support, user guides, FAQs,

warranty & more

Introduction

Light On/O

Button & LED

Fan On/O

Button & LED

Fan Speed

Control Bar

Dimmer

Control Bar

Detach the

wallplate

Restart Button

HomeKit Numeric Code

• For HomeKit setup.

Note: You can nd another Homekit setup code label

in the package and stick it anywhere you like as

needed for setup.

LED Status

Starting up;

Disconnected from Cloud.

Solid red

Blinking red quickly

Blinking white quickly

Blinking red slowly

Solid white

Blinking red & white slowly

Connecting to Wi-Fi.

Ready for setup.

Restoring to factory default settings.

Blinking white slowly Firmware updating.

Blinking red & white quickly Resetting Wi-Fi.

Disconnected from Wi-Fi.

Connected to Cloud.

Safety Information

Before installing, servicing, or removing the switch, read and

follow all safety precautions including the following:

• CAUTION – Risk of Electric Shock – More than one

disconnect switch may be required to de-energize the

equipment before servicing. A circuit breaker which

disconnects the Line and Neutral conductor simultaneously

is suitable. Ensure power is o at the circuit breaker before

removing or installing any switch. Use a non-contact

voltage tester to ensure the power is o.

• The Smart Switch must be installed and used in accordance

with the National Electric Code (NEC) or your local electrical

code. If you are unfamiliar with these codes and require-

ments, or are uncomfortable performing the installation,

consult a qualied electrician.

• Do not install the Smart Switch with wet hands or when

standing on wet or damp surfaces.

• Install only in a suitable UL Listed or equivalent outlet box

(suitable dimensions: H > 2.95 in./75 mm, W > 1.81 in./46

mm, D > 2 in./51 mm).

High Voltage – Disconnect power supply before servicing

CAUTION

Haute tension. Débrancher l'alimentation électrique avant

d'utiliser

MISE EN GARDE

Appearance

Button Explanations

Restart

Press and hold either of the buttons for

about to reset Wi-Fi while retaining 5s

other settings.

Press to restart your switch.

Single press the corresponding button to

to turn on/off your light/fan.

Press and hold either of the buttons for

about to restore your switch to 10s

factory default settings.

Brightness

100%

Fan Speed

Level 4

Level 1

Fan Speed Control Bars:

Slide to any of the 4 speed

levels.

Dimmer Control Bars: Slide

to decrease or increase the

brightness.

Carefully insert a at-bladed screwdriver into the opening

at the bottom of the wallplate and pull forward to remove

the wallplate.

123

456

Q1: Have any trouble with the wiring?

A1: If you fail to wire the smart switch or encounter any

troubles in the wiring process, you can visit

https://www.tp-link.com/support/faq/3682/ for the

installation FAQ.

Q2: Cannot nd your switch in the setup process?

A2: Your phone looks for the smart switch via Bluetooth. If it is

unable to nd your switch, you can:

1. Move your smartphone closer to the smart switch and

disconnect other Bluetooth devices from your phone.

2. Turn o Bluetooth on your phone, then turn it back on

and try again.

3. Restart your switch by single pressing the Restart button.

4. If the problem persists, press and hold either of the

On/O buttons on the switch for about 10s to restore your

switch to factory default settings.

Q3: Failing to set up HomeKit for your smart switch?

A3: You can try the following methods to solve HomeKit setup

issue:

1. Press and hold either of the On/O buttons on the switch

for about 10s to restore your switch to factory default

settings and restart your phone. Then try again.

2. Move your iPhone/iPad and the smart switch closer to

the router to get a stronger Wi-Fi signal.

3. HomeKit setup will be disabled after 10 minutes from the

smart switch powering on. You can single press the Restart

button to try again.

4. Creating a new home in the Home app can greatly help

set up your smart switch.

Refer to the FAQ below for detailed troubleshooting:

https://www.tp-link.com/support/faq/3390/

Q4: How do I control the LEDs of the smart switch?

A4: You can manage them on the Kasa Smart app. Go to the

status page of your switch and go to >LED Status. You

can turn on/o your LEDs and set brightness and

schedules for them.

Q5: Are your lights too bright when dimming to the

minimum level, or do they icker?

A5: Open the Kasa Smart app and go to Device Settings to

adjust the dimming range.

Bulbs may vary in their dimming range. For optimal dimming

performance, recalibrate the brightness in the Kasa Smart

app after changing a bulb.

Q6: Is your fan speed too low?

A6: Ensure that the fan is manually adjusted to highest possible

setting with its pull chain or other independent speed

control.

For step-by-step setup instructions, please visit:

• Google Home Assistant:

https://www.tp-link.com/support/faq/1534/

• Amazon Alexa:

https://www.tp-link.com/support/faq/944/

Produktspezifikationen

Marke:	TP-Link
Kategorie:	Nicht kategorisiert
Modell:	Kasa KS240

Brauchst du Hilfe?

Wenn Sie Hilfe mit TP-Link Kasa KS240 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert TP-Link

TP-Link MC111CS Bedienungsanleitung

16 September 2024

TP-Link TL-SM311LM Bedienungsanleitung

13 September 2024

TP-Link Kasa KP125 Bedienungsanleitung

11 September 2024

TP-Link RE715X Bedienungsanleitung

11 September 2024

TP-Link TL-SG3428X-UPS Bedienungsanleitung

11 September 2024

TP-Link Kasa Smart HS103P2 Bedienungsanleitung

11 September 2024

TP-Link TL-POE10R Bedienungsanleitung

11 September 2024

TP-Link Deco BE25 Bedienungsanleitung

5 September 2024

TP-Link Omada ES205GP Bedienungsanleitung

5 September 2024

TP-Link Archer TXE50UH Bedienungsanleitung

4 September 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
