When Installing the Unit
• Refer all installation work to the dealer from
whom the speaker was purchased. Installation
work requires extensive technical knowledge and
experience. The speaker may fall off if incorrectly
installed, resulting in possible personal injury.
• Install the speaker only in a location that can
structurally support the full weight of the unit and
mounting bracket. Doing otherwise may result in
the speaker falling down and causing personal
injury and/or property damage.
• Since the unit is designed for in-door use, do not
install it outdoors. If installed outdoors, the aging of
parts causes the unit to fall off, resulting in personal
injury. Also, when it gets wet with rain, there is a
danger of electric shock.
• Donotuseothermethodsthanspeciedtoinstall
the speaker. Extreme force is applied to the speaker
and the speaker could fall off, possibly resulting in
personal injuries.
• Use screws that are appropriate for the ceiling's
material and structure. Failure to do so may cause
the speaker to fall, resulting in material damage and
possible personal injury.
• Ensure that all screws are securely tightened. If
they are loose after installation, the speaker could
fall down, possibly resulting in personal injury.
ThankyouforpurchasingTOA’sCeilingMountSpeaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
CEILING MOUNT SPEAKER
INSTRUCTION MANUAL
PC-1860EN
PC-2360EN
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe
operation.
• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future reference.
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
WARNING
Traceability Information for Europe
Manufacturer:
TOACorporation
7-2-1,Minatojima-Nakamachi,Chuo-ku,Kobe,Hyogo,
Japan
Authorizedrepresentative:
TOAElectronicsEuropeGmbH
Suederstrasse282,20537Hamburg,
Germany
1. SAFETY PRECAUTIONS 1 .............................
2. GENERAL DESCRIPTION AND FEATURES ... 2
3. INSTALLATION 3 ............................................
4. WIRING DIAGRAMS 4 ....................................
5. FREQUENCY RESPONSE (1 W, 4 M) 4 .........
6. SPECIFICATIONS 5 ........................................
2
When Installing the Unit
• Do not mount the speaker in locations exposed to
constant vibration. The speaker or its mounts can
be damaged by excessive vibration, potentially
causing the speaker to fall, which could result in
personal injury.
• Do not use anti-rust lubricant. If it contacts resin or
rubber parts, they could deteriorate and cause the
speaker to fall, possibly resulting in personal injury.
• Do not install the speaker in indoor swimming
pools or such locations where liquid chemicals are
used. The parts deteriorate if corroded, causing the
speaker to fall, which could result in personal injury.
When the Unit is in Use
• If any of the following irregularities occurs,
immediately switch off the amplier's power, and
inform the shop from where the speaker was
purchased. Further using the speaker may result in
reorelectricshock.
· If you detect smoke or a strange smell coming
from the speaker
· If water or any metallic object gets into the speaker
· If the speaker falls, or the speaker case breaks
• Topreventareorelectricshock,neveropennor
remove the speaker case. Refer all servicing to
your nearest TOA dealer.
When Installing the Unit
• Avoid touching the speaker's sharp metal edge to
prevent injury.
• To avoid electric shocks, be sure to switch off the
amplier'spowerwhenconnectingspeakers.
When the Unit is in Use
• Do not operate the speaker for an extended period
of time with the sound distorting. Doing so may
causethespeakertoheat,resultinginare.
• Do not stand or sit on, nor hang down from the
speaker as this may cause it to fall down or drop,
resulting in personal injury and/or property damage.
• Havethespeakercheckedperiodicallybytheshop
from where it was purchased. Failure to do so may
result in corrosion or damage to the speaker or the
mounts that could cause it to fall, possibly causing
personal injury.
2. GENERAL DESCRIPTION AND FEATURES
ThePC-1860ENandPC-2360ENarecertiedaccordingtotheEuropeanStandardEN54-24:2008.
Integratedwitha speaker unitandpanel,the PC-1860EN and PC-2360EN Ceiling MountSpeakers are of
metallic construction and ideal for use in a voice alarm system. They feature spring catch mechanism for easy
speaker mounting to the ceiling. The input impedance can be easily changed by changing the tap position of
the transformer. The push-in type input terminal block makes cable connections easy and allows bridge wiring.
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
WARNING
3
3-2. Changetheinputimpedanceasneeded.
The speaker's input is factory-preset to 1.7
kΩ. When changing the input impedance,
detach the black wire connected to the
matching transformer, and reinsert it into
the desired input tap referring to the tables
below.
3.3kΩ
1.7kΩ
COM
6.7kΩ
13kΩ
HOT (Black) COM (White)
Matching transformer
Impedance 1.7kΩ 3.3kΩ 6.7kΩ 13kΩ
100 V line 6W 3W 1.5W 0.8W
70 V line 3W 0.8W 0.4W1.5W
3. INSTALLATION
Step 1. Using the supplied paper pattern as a guide,
open a mounting hole of the dimension
speciedbelowintheceiling.
Ceiling
5 – 25 mm
(0.2" – 0.98")
øA
ModelNo. øA
PC-1860EN ø150 ±3 mm (ø5.91" ±0.12")
PC-2360EN ø200 ±3 mm (ø7.87" ±0.12")
Step 2. Hook the speaker mounting spring into the
mounting hole in the ceiling.
Ceiling Speaker
mounting
spring
Splash proof cover
Step 3. Makewiring.
3-1. Insert the lead-in cables (cables from the
amplier) and lead-out cables (cables to
other speakers) into the input connector.
[Whenmakingabridgeconnection]
Input connector
Matching transformer
Speaker cable
(From the amplifier)
Speaker cable
(To the next speaker)
Input connector
From
the amplifier To
the next speaker
COM (–)
HOT (+)
9 mm
(0.35")
Applicable cable
Solid wire: ø0.8 – ø1.6 mm
(equivalent to AWG 20 – 14)
View with splash proof cover
removed
Step 4. Mountthesplashproofcover.
Important
Hookthesplashproofcoverateverypoints
markedwitharrowsinthegurebelow.The
splash proof cover is compliant with the dust/
waterprotectionratingIP21C.
Check thatthe coveris securely xedtoall
hooking positions to protect the speaker unit,
transformer, and connection terminal from
water splash.
(1)
(1)
(1)
(1)
(2)
(3) Input connector
Cover hook
(1)Hookthesplashproofcovertothecover
hook.
(2)Hook the splash proof cover under the
Matchingtransformer.
(3)Hook the splash proof cover under the
Input connector.
AlltheguresinthissectionshowPC-1860EN.
