IP-A1PC580R
IP-A1PC580S
IP CEILING MOUNT SPEAKER
IP SQUARE SPEAKER
INSTRUCTION MANUAL
Thank you for purchasing TOA’s IP Speaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ......................................................................................................... 2
2. SUMMARY AND FEATURES .................................................................................................. 4
3. ABOUT SECURITY MEASURES ............................................................................................ 4
4. DIMENSIONAL DRAWINGS ................................................................................................... 5
5. NOMENCLATURE AND FUNCTIONS ................................................................................... 6
6. SYSTEM EXAMPLE .................................................................................................................. 8
6.1. SIP Broadcasting/Two-way Communication ........................................................................ 8
6.2. VMS Broadcasting ............................................................................................................... 8
7. HANDLING PRECAUTIONS .................................................................................................... 8
8. INSTALLATION PRECAUTIONS ............................................................................................ 9
9. INSTALLATION ......................................................................................................................... 9
9.1. IP-A1PC580R ........................................................................................................................ 9
9.2. IP-A1PC580S ..................................................................................................................... 10
10. CONNECTIONS ..................................................................................................................... 10
10.1. Connections to Line/Mic Input and Line Output Terminals .............................................. 10
10.2. Connections to Control Input and Output Terminals ....................................................... 11
10.3. Removable Terminal Plug Connections .......................................................................... 12
11. SETTINGS .............................................................................................................................. 13
11.1. System Settings Summary ............................................................................................... 13
11.2. System Requirements ...................................................................................................... 13
11.3. Connection with Browser ................................................................................................. 14
12. INITIALIZATION OF SETTINGS ......................................................................................... 15
13. CAUTIONS REGARDING THE AVC/H.264 PATENT LICENSE ..................................... 16
14. OPEN SOURCE SOFTWARE .............................................................................................. 16
15. ACCESSORIES ..................................................................................................................... 16
2
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the instructions in this section for
correct and safe operation.
• Be sure to follow all the precautionary instructions in this section, which contain important
warnings and/or cautions regarding safety.
• After reading, keep this manual handy for future reference.
WARNING
When Installing the Speaker
• Do not expose the speaker to rain or an
environment where it may be splashed by
water or other liquids, as doing so may result
in re or electric shock.
• Install the speaker only in a location that can
structurally support the weight of the speaker
and the mounting bracket. Doing otherwise
may result in the speaker falling down and
causing personal injury and/or property
damage.
• Since the speaker is designed for indoor use,
do not install it outdoors. The speaker is to be
connected only to PoE networks without routing
to the outside plant. If installed outdoors, the
aging of parts causes the speaker to fall off,
resulting in personal injury. Also, when it gets
wet with rain, there is a danger of electric shock.
• Do not mount the speaker in locations
exposed to constant vibration. The mounting
bracket can be damaged by excessive
vibration, potentially causing the speaker to
fall, which could result in personal injury.
When the Speaker is in Use
• Should the following irregularity be found
during use, immediately cut off the power
supply from a PoE switching hub and contact
your nearest TOA dealer. Make no further
attempt to operate the speaker in this condition
as this may cause re or electric shock.
· If you detect smoke or a strange smell
coming from the unit
· If water or any metallic object gets into the
speaker
· If the speaker falls, or the speaker case
breaks
· If the LAN cable is damaged (exposure of
the core, disconnection, etc.)
· If the speaker suddenly stops producing
sound
• To prevent a re or electric shock, never open
nor remove the speaker case as there are high
voltage components inside the speaker. Refer
all servicing to qualied service personnel.
• To prevent the electromagnetic wave from
badly inuencing medical equipment, make
sure to switch off the speaker’s power when
placing it in close proximity to the medical
equipment.
CAUTION
When Installing the Speaker
• Attach the safety wire to the speaker. If not
attached, the speaker could fall off, resulting
in personal injury.
• Avoid installing the speaker in humid or dusty
locations, in locations exposed to the direct
sunlight, near the heaters, or in locations
generating sooty smoke or steam as doing
otherwise may result in re or electric shock.
Indicates a potentially hazardous situation which, if mishandled,
could result in death or serious personal injury.
WARNING
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
CAUTION
3
This equipment is not suitable for use in locations where children may be present.
• Avoid touching the speaker’s sharp metal
edge to prevent injury.
When the Speaker is in Use
• Do not operate the speaker for an extended
period of time with the sound distorting. Doing
so may cause the speaker to heat, resulting in
a re.
• Have the speaker checked periodically by the
shop from where it was purchased. Failure
to do so may result in corrosion or damage
to the speaker or its mounting bracket that
could cause the unit to fall, possibly causing
personal injury.
FCC REQUIREMENTS
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Modications
Any modications made to this device that are not approved by TOA Corporation may
void the authority granted to the user by the FCC to operate this equipment.
The IP-A1PC580R and IP-A1PC580S IP speakers are capable of delivering
extremely high volume sound output. Therefore, close proximity to the
speaker over time could present the danger of hearing impairment. Be sure
to follow the instructions below when conducting performance tests:
• Turn down the sound volume before adjusting the volume.
• Do not position one’s ear close to the speaker.
• Point the speaker in a direction where no people are present.
• Avoid listening to high-volume output for prolonged periods of time.
