Manual
Wireless earbuds pro -TZ 66
Introduction
4
1
2
5
3
9
10
8
6 7
1.
Touch control button 6. -C Type charging point
2.
LED indicator earbud 7. Wireless charging base
3.
Eartip 8. Charging case
4.
Wingtip 9. Charging station earbud
5.
Charging contact points 10. LED indicator charging case
Connecting earbuds
Steps
1. Turn on Bluetooth on your device.
2. Pick up the earbuds from the charging case. The earbuds turn on, start pairing and
search automatically for Bluetooth connection.
3. Connect the earbuds to your device via <Thunderz TZ- 66> in the Bluetooth settings.
Note
When usingthe earbuds for the first time, remove the blue label
from the bottom side of the earbuds.
Automatic connection:
After the earbuds are succesfully connected to your devide the first time:
"Pick up the = earbuds automatic connection"
"Put earbuds charging in = case earbuds disconnect"
Touch control
Tip:
Either earbud can be used individually. When doing so, the functions
Volume - +/ and Next/ Previous song will be disabled.
LED indicator
Charging case
Earbud
Specifications
Package contents
1 x Wireless earbud pro L/R
1 × Charging case
2 × Eartips ( S/ M/ L ), 2 x (S/ Wingtip M), 1 x Casual tip
1 × -C Type Charging cable
1 × Manual
Reset
When one or both eabuds willnot connect to your device, reset the earbuds.
Steps
1. Remove <Thunderz TZ from- 66> all Bluetooth devices it has been
connected to, and turn off the Bluetooth on your device.
2. Turn off both earbuds and put them in to the charging case.
3. Pick up the earbuds charging and from the case turn on the earbuds. Turn
on Bluetooth on your device and connect <Thunderz TZ-66> to your
device in the Bluetooth settings.
4. The Bluetooth connection of the earbuds has now been reset.
Note
Always reset the 2 earbuds at same the time.
Warnings
1. The earbuds cannot be submerged in water and do not withstand when
used during shower or swimming.
2. Do not place the earbuds sunlight in direct or in moisture hot/ places.
3. Turn off the earbuds when not being used.
4. Do not try to disassemble the product.
5. Do not drop the earbuds or knock the earbuds to other surfaces.
6. If thevolume of the too earbuds is long on high volume, it may lead to
health problems. Be aware.
How to wear
1. Choose andplace the eartip that best suit your ears.
2. Insert the earbud in the inner ear.
3. Turn the wingtip and find the most comfortable position.
Gebruiksaanwijzing
Wireless earbuds pro -TZ 66
Introductie
4
1
2
5
3
9
10
8
6 7
1.
Touch control button 6. -Type C oplaadpunt
2.
LED indicator earbud 7. Draadloze oplaadbasis
3.
Eartip 8. Oplaadcase
4.
Wingtip 9. Oplaadstation earbud
5.
Oplaadcontactpunten 10. LED indicator oplaadcase
Verbinding maken
Stappen
1. Zet Bluetooth aan op je apparaat.
2. Pak de earbuds uit de oplaadcase. De earbuds activeren, pairen en zoeken
automatisch naar een Bluetooth verbinding.
3. Verbindt de earbuds met jeapparaat via <Thunderz TZ- 66> in de Bluetooth instellin gen .
Note
Wanneer jede earbuds voor de eerste keer gebruikt, zorg dandat
je het blauwe stikkertje onderaan de earbuds verwijdert.
Automatisch verbinding maken:
Nadat je de earbuds de eerste keer met je apparaat hebt verbonden:
"Earbuds de uit = oplaadcas e automatisch verbonden"
"Earbuds terug in de oplaadcase = verbinding verbreken"
Touch bediening
Tip:
Je kunt de earbuds ook afzonderlijk gebruiken. Hiermee vervallen wel de
controls - Volume +/ en Volgend/ vorig nummer.
LED indicator
Oplaadcase
Earbud
Specificaties
Verpakkingsinhoud
1 x Wireless earbud pro L/R
1 × Oplaadcase
2 × ( S/ Eartips M/ L ), 2 x Wingtip (S/M), 1 x Casual tip
1 × -C Type Oplaadkabel
1 × Gebruiksaanwijzing
Reset
Wanneer eenof beiden earbuds niet wilt connectenmet je apparaat, reset dan
beiden earbuds.
Stappen
1. Verwijder <Thunderz TZ 66> van je apparaat in de Bluetooth instellingen, - en
zet Bluetooth uit.
2. Zet beidenearbuds uiten stop deze inde oplaadcase.
3. Pak de earbudsuit deoplaadcase en zet de earbuds aan. Zet de Bluetooth
op je apparaat aan en verbindt <Thunderz TZ-66> aan je apparaat via de
Bluetooth instellingen.
4. De Bluetooth verbinding van de earbuds nu is gereset.
Note
Reset altijd de 2 earbuds tegelijkertijd.
Waarschuwingen
1. De earbuds kunnen niet ondergedompeld worden in water en je kunt niet
douchen of zwemmen met deze earbuds.
2. Plaats deearbuds nooit in direct zonlicht of opwarme/ vochtige plekken.
3. Zet de earbuds je uit wanneer deze niet gebruikt.
4. Probeer het product niet te demonteren.
5. Laat de earbuds niet vallen of stoot deze niet andere oppervlakken. tegen
6. Wanneer het volume de earbuds van te lang op een te hoog volume
staat, kandat leiden totgezondheidsklachten. Ben ervan bewust.
Earbuds plaatsen
1. Kies en bevestig de eartip die het best bij jeoor past.
2. Breng deearbud inde binnenkant van je oor.
3. Draai dewingtip in jeoorschelp en vind de meest comfortabele
positie.
Bluetooth version V5.0 + EDR
Bluetooth range 10 meters/ 33ft (unobstructed)
Dimensions earbud 25.2 x 23.3 x 21.9 mm
Dimensions charging case 71.1 x 40.0 x 27.2 mm
Weight earbud 4.5 gram/ 0.16 oz
Charging time earbuds 1 hr
Charging time charging case 1 hr (via Type-C)
Standby time 60 hrs
Battery capacity earbud 40 mAh
Battery capacity charging case 250 mAh
Input wireless charging base DC 5V/ 1A
Status
LED
Charging -C via Type cable Red light flashes
Fully via charged -C Type cable Red light on
The earbuds charge in the charging case Blue light on (3 sec.), off then
Low battery Red light flashes
Function Control
Play/ Pause 1 x Touch L/R
Next/ Previous song
2 x LTouch for next song
2 x Touch for previous Rsong
Volume + / -Volume 3 seconds Lhold press volume +,
3 seconds -, Rhold press volume
Answer/ Hang up call 1 x Touch RL/
Reject call 2 seconds hold press L/R
Voice assistent activation 3 x Touch L/R
Turn on earbud 3 seconds hold press L/R
Turn off earbud 5 seconds hold press L/R
Status
LED
Charging Red light on
Fully charged Blue light on (5seconden), then off
Low battery Red light flashes
Search connection Red and blue light flashing alternately
Connected No light
Music/ calling No light
Turn on Red and blue light flashing 2 for seconds
Turn off Red flashes light 2 for seconds
Bluetooth versie V5.0 + EDR
Bluetooth bereik 10 meter(zonder obstakels)
Afmetingen earbud 25,2 x 23,3 x 21,9 mm
Afmetingen oplaadcase 71,1 x 40,0 x 27,2 mm
Gewicht earbud 4,5 gram
Oplaadtijd earbud 1 uur
Oplaadtijd oplaadcase 1 uur (via -Type C)
Standbytijd 60 uur
Batterij capaciteit earbud 40 mAh
Batterij capaciteit oplaadcase 250 mAh
Input draadloze oplaadbasis DC 5V/ 1A
Status
LED
Opladen knippert -C via de Type kabel Rood licht
Volledig opgeladen de via -C Type kabel Rood licht aan
De earbuds laden op in de oplaadcase Blauw lichtaan daarna (3 sec.), uit
Lage Rood batterij licht knippert
Functie Bediening
Play/ Pauze 1 x Tippen L/R
Volgend/ Vorig nummer
2 x Tippen Lvolgend nummer
2 x RTippen vorig nummer
Volume + / -Volume 3 seconden ingedrukt houden volume L+,
3 seconden ingedrukt volume houden -, R
Oproep opnemen/ eindigen 1 x RTippen L/
Oproep weigeren 2 seconden ingedrukt houden L/R
Voice assistent activeren 3 x Tippen L/R
Aanzetten 3 seconden ingedrukt houden L/R
Uitzetten 5 seconden ingedrukt houden L/R
Status LED
Opladen Rood licht aan
Volledig licht opgeladen Blauw aan (5seconden), daarna uit
Lage batterij Rood licht knippert
Verbinding maken Rood enblauw licht knippert
Verbonden Geen licht
Muziek/ Geen bellen licht
Aanzetten Rood 2 en blauw licht knippert seconden
Uitzetten Rood 2 licht knippert seconden
