Seite 1/30
D01359820C
TASCAM MX CONNECT
TASCAM EZ CONNECT
U S E R S M A N UA L
1219.MA-2856C
TASCAM MX CONNECT 2
1 - TASCAM MX CONNECT / TASCAM EZ CONNECT
Contents
1 - TASCAM MX CONNECT / TASCAM EZ CONNECT....................2
Overview 2 .......................................................................................................
Conventions used in this manual 3 .........................................................
Trademarks and copyrights 3 ....................................................................
Operating environment 3 ...........................................................................
iOS devices 3 .............................................................................................
Android devices 3 ....................................................................................
Windows 3 ..................................................................................................
Mac 3 ............................................................................................................
Software versions 3 .................................................................................
Installing the dedicated software 4 ........................................................
iOS/Android devices 4 ...........................................................................
Windows 4 ..................................................................................................
Mac 5 ............................................................................................................
Working with Gatekeeper 6 .................................................................
2 - TASCAM MX CONNECT 7 ...........................................................
Connecting TASCAM MX CONNECT with an MX-8A 7 ......................
Using TASCAM MX CONNECT in demo mode 8 ..................................
Screen overviews 8 .......................................................................................
PRESET page 8 ................................................................................................
INPUT page 9 ...................................................................................................
Additional Input Settings screen 10 ..................................................
COMPRESSOR tab...............................................................................12
EQUALIZER tab 12 ....................................................................................
MIXER page 13 ................................................................................................
Additional Mixer Settings screen 15 .................................................
DUCKING settings area.....................................................................15
ANC settings area 16 ...............................................................................
ROUTING page 16 ..........................................................................................
OUTPUT page 17 ............................................................................................
Additional Output Settings screen 18 ..............................................
Additional test tone settings window 19 ........................................
EQUALIZER tab 19 ....................................................................................
DELAY tab 20 ..............................................................................................
SETTINGS page 20 ..........................................................................................
EZ CONNECT page 21 ...................................................................................
CONTROLLER page 22 ..................................................................................
Information display on the RC-W100 23 ..........................................
3 - TASCAM EZ CONNECT 24 ..........................................................
Connecting TASCAM EZ CONNECT with an MX-8A 24 .....................
Using TASCAM EZ CONNECT in demo mode 24 ................................
Making TASCAM EZ CONNECT settings 25 ...........................................
Setting the SOURCE SELECT area 25 .................................................
Setting the Volume Screen 26 .............................................................
Operating multiple MX-8A units
with TASCAM EZ CONNECT 28 ............................................................
Understanding information codes 29 ..............................................
Overview
TASCAM MX CONNECT
TASCAM MX CONNECT is control software designed for use with
the MX-8A matrix mixer by system integrators and managers.
From building a system that uses an MX-8A to daily management
and operation, it supports a wide range of functions.
pControl software designed for use with the MX-8A matrix mixer
by system integrators and managers
pInput module operation
pMatrix mixer operation
pMix and output routing operation
pOutput module operation
pCreate setups for the TASCAM EZ CONNECT control software
for end-users
pDemo mode enables testing TASCAM MX CONNECT operations
pOperations using RC-W100-R120 and RC-W100-R86 wall-
mounted controllers can be customized
pTASCAM MX CONNECT and TASCAM EZ CONNECT can be
downloaded for free from the App Store for iOS, Google Play for
Android and the TEAC Global Site (http://teac-global.com/) for
Windows and Mac.
TASCAM EZ CONNECT
The TASCAM EZ CONNECT is control software for end users with a
simple design and easy to use interface.
Control functions can be customized via the control software for
system integrators/managers.
By only assigning the necessary functions, it prevents end-users
from unintentional control errors or troubles.
Before using this software, read the Software Use License
Agreement and agree to its terms.
TASCAM MX CONNECT 3
1 - TASCAM MX CONNECT / TASCAM EZ CONNECT
Conventions used in this manual
The following conventions are used in this manual.
pSmartphones, tablets and computers are called devices”.
pMessages that appear on an iPhone, iPad or Android device are
shown in quotes like this: INFO.
pAdditional information is provided as necessary as tips, notes
and cautions.
TIP
These are tips about how to use the software.
NOTE
These provide additional explanations and describe special
cases.
ATTENTION
Failure to follow these instructions could result in damage to
equipment or lost data, for example.
VCAUTION
Failure to follow these instructions could result in injury.
Trademarks and copyrights
pTASCAM is a registered trademark of TEAC Corporation.
pAndroid and Google Play are trademarks of Google Inc.
pApple, Mac, macOS, iPad and the App Store are trademarks of
Apple Inc. in the U.S. and other countries.
pThe App Store is a service mark of Apple Inc.
pIOS is a trademark or registered trademark of Cisco Systems,
Inc. in the U.S. and other countries and is used under license.
pMicrosoft, Windows, Windows Vista and Windows Media
are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
pOther company names, product names and logos in this
document are the trademarks or registered trademarks of their
respective owners.
Operating environment
iOS devices
Supported operating systems
TASCAM MX CONNECT: iPadOS 13, iOS 12, iOS 11
TASCAM EZ CONNECT: iPadOS 13, iOS 13, iOS 12, iOS 11
Supported devices
TASCAM MX CONNECT: iPad with arm64 or newer processor
TASCAM EZ CONNECT: iPhone, iPad or iPod touch with arm64
or newer processor
Android devices
Supported operating systems
Android 5.0 9.0-
Supported devices
TASCAM MX CONNECT: Android tablet with a screen that is
at least 7 inches (8 inches or larger
recommended)
TASCAM EZ CONNECT: Android device with a screen that is at
least 4 inches
Windows
Supported operating systems
Windows 10 (32bit, 64bit)
Windows 8.1 (32bit, 64bit)
Windows 7 SP1 (32bit, 64bit) or newer
NOTE
It cannot be used with Windows 8, Windows XP or Windows
Vista.
Computer hardware requirements
Computer running Windows
CPU :
Intel Core i series or newer recommended
Memory
2 GB or more (at least 4 GB recommended)
Open disc space
At least 150 MB
Screen resolution/number of colors
1280×1024 (SXGA) or higher
True Color (32-bit) recommended
Mac
Supported operating systems
macOS Catalina (10.15)
macOS Mojave (10.14)
macOS High Sierra (10.13)
Supported models
Macs with Intel Core i/Core M series processors
Memory
2 GB or more (at least 4 GB recommended)
Open disc space
At least 150 MB
Screen resolution
1280×1024 (SXGA) or higher
Software versions
TASCAM MX CONNECT software version: 1.2.0
TASCAM EZ CONNECT software version: 1.1.1
