Seite 1/84

SC936 CHASSIS SERIES

USER’S MANUAL

1.0c

SC936E1-R710B

SC936A-R900B

SC936E1-R900B

SC936E2-R900B

SC936A-R1200B

SUPER ®

SC936 Chassis Manual

Manual Revision 1.0c

Release Date: January 20, 2009

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software, if any,

and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or

reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the SC936 chassis. Installation

and maintenance should be performed by experienced technicians only.

This Supermicro SC936 chassis features a unique and highly-optimized design

with Intel/AMD based DP, UP processors The chassis is equipped with a 900W or

1200W high-efciency power supply. High-performance fans provide ample opti-

mized cooling for FB-DIMM memory modules and hot-swappable drive bays offer

maximum storage capacity.

This document lists compatible parts available when this document was published.

Always refer to the our Web site for updates on supported parts and congura-

tions.

Produktspezifikationen

Marke:	Supermicro
Kategorie:	Festplatten-Array
Modell:	SuperChassis SC936E16-R1200B
Breite:	437 mm
Tiefe:	648 mm
Gewicht:	34020 g
Produktfarbe:	Schwarz
Höhe:	132 mm
Betriebstemperatur:	10 - 35 °C
Relative Luftfeuchtigkeit in Betrieb:	8 - 90 %
Zertifizierung:	80 PLUS Bronze, UL, CUL, FCC, TUV, CE, EN 60950/IEC 60950, CCC, CB
LED-Anzeigen:	Ja
Temperaturbereich bei Lagerung:	-40 - 70 °C
Luftfeuchtigkeit bei Lagerung:	5 - 95 %
Energiebedarf:	100 - 240V, 50 - 60Hz, 11.5 - 5.5A
Schnittstelle:	SFF 8087
Kompatible Speicherkarten:	Nicht unterstützt
Anzahl der unterstützten Speicherlaufwerke:	16
Gehäusetyp:	Rack 3U
Integrierter Kartenleser:	Nein
Unterstützte Speicherlaufwerk-Schnittstellen:	SATA
Lüfterdurchmesser:	80 mm
Anzahl Lüfter:	5 Lüfter
Datenübertragungsrate:	6 Gbit/s
Größe des Speicherlaufwerks:	3.5 "
Hot-Swap:	Ja
