CLK Mode(12H/24H)
Mounting Shoe
Sensor Wiring
Computer Battery Installation
While the default Maintenance Alert digit
200 RIGHTkm/m is flashing, Press the button
to choose km/m. Press the 200/400/600/800
left button to confirm and enter into Clock mode. (when the ODO
the Maintenance Alert digit you set, the will appear on
the screen to alert the rider, press the RIGHT button seconds 3
to cancel it.)
SPD CURRENT SPEED
ODO ODOMETER (0.001~99999km/m)
DST TRIP DISTANCE
MXS MAXIMUM SPEED
AVS AVERAGE SPEED
TM ELAPSED TIME
CLK CLOCK (12H/24H)
SCAN
“-” “+” COMPARATOR
SETTING SPEED SCALE ,(km/h m/h)
SETTING TYRE CIRCUMFERENCE (0mm~9999mm)
SETTING THE LAST VALUE OF ODOMETER /ODO
MAINTENANCE ALERT
FREEZE FRAME MEMORY
AUTO ON OFF /
15 function cycle computer
Instruction Manual
FUNCTIONS
Remove the battery cover from the bottom of the computer by using a
flat blade screwdriver, install battery with the positive (+) pole facing the
battery cover and replace the cover. Should the LCD show irregular
figures, take out the battery and reinstall it.
Speedometer Sensor
Attach the sensor transmitter to either front fork using the supplied cable
ties. Fit the magnet to a spoke using the diagram above as a guide.
Position the sensor & magnet as shown above. Take care to align the
magnet to either arrow on the sensor with 3~5 mm gap in between.
Route the sensor wire up the fork blade,
using the cable ties to secure it. Make
sure it does not hinder the movement
of the front wheel.
Attach the mounting shoe with the cable ties
to the handlebars as shown in the diagram.
Attach the computer to the mounting shoe
by sliding the unit until it snaps firmly into position.
To remove, press down on the release catch, and
remove the computer. To check for proper speed
function and sensor alignment, spin the front wheel with the computer in
speed mode. Adjust the position of sensor and magnet if there is on or
weak signal.
Computer
Wheel Size Input
‘ ’ appears on the screed when the battery has been installed, with 2060
one figure flashing enter the wheel circumference using the formula below.
In the example above you would enter . Press the button to 2198 RIGHT
advance the digits as needed and the button to confirm and LEFT
advance. (The circumference ranges 0mm~9999mm), press the LEFT
button to enter mode.KM/M
Setting(km/h)/(m/h)
Press the button to choose or .RIGHT km/h m/h
Press the button to enter mode.LEFT CLOCK
Setting Maintenance alert
In mode, press the button for seconds to ODO LEFT 2
set the value. The initial value is . when ODO 0000.0
one figure flashes, press the button to adjust it, RIGHT
and the LEFT button to confirm and start to set the
next figure. NOTE: Before re-installing the battery, take a note of your
mileage and then re-enter the value once the battery is replaced.
In CLOCK Mode, press the button for seconds LEFT 3
to enter 12/24H selection. Press once more to swap between 12/24 hours.
Press the RIGHT button to enter the Hour mode, when the figure indicating
HOUR starts to flash, press the LEFT button to adjust it. Continue to press
the RIGHT button to enter the Minute mode, when the figure indicating
MINUTE starts to flash, press the button to adjust. Press the LEFT RIGHT
button to confirm & press the RIGHT button again to switch to mode. ODO
Setting the Last value of Odometer
JOY-587A
3~5mm
KM/hr
S ET M O D E JOY-587
NO
OFF
Accessories
Malfunctions and Problems
Button Instruction
Freeze Frame Memory
Sleep Mode
Trip Time
Average Speed
Maximum Speed (MXS)
Reset of Mileage Parameter
In mode, press and hold both the and buttons ODO RIGHT LEFT
simultaneously for seconds to clear the tyre circumference and (km/m) 3
settings. The clock settings will remain unchanged.
Speedometer
In mode, the total distance is indicated ODO
on-screen.
The mileage range is ~ km(m). The 0.001 99999
display will return to when the value exceeds its 0
maximum limit, press the button to enter mode.RIGHT DST
Speed is shown at all times on-screen, its maximum reading is
99.9 0.1km/h(m/h), and is accurate to +/- km/h (m/h).
Speed Comparator
During riding, ‘ ’ and ‘ ’ indicates the current speed is higher or lower + -
than the average speed (AVS).
Odometer
Trip Distance (DST)
In mode, the distance for one trip is indicated DST
on the bottom line. ranges from km(m).DST 0~9999
When the value exceed the range limit, it resets to 0
automatically. Both the time and the distance records
will be cleared when the time of one trip exceed the range limits.
Press the button for seconds to clear the records of , ,LEFT 5 DST MXS
AVS TMand .
Press the button to enter mode.RIGHT MXS
In mode, maximum speed is indicated on the MXS
bottom line. Press the button for seconds to LEFT 5
clear the records of , , MXS DST AVS TM and .
In AVS mode, average speed is indicated on the
bottom line. Press the button for seconds to LEFT 5
clear the records of AVS DST MXS TM, , and .
Press the right button to enter mode.TM
In mode, trip time is indicated on the bottom line.TM
TM ranges from to , and will be reset 0:00:00 99:59:59
to when the value exceed the limit.0
Press the button for seconds to clear the records of , , LEFT 5 TM DST
MXS AVS and .
Press the button to enter mode.RIGHT SCAN
Scan
In mode , , , SCAN DST MXS AVS TM and modes are
indicated in turn every seconds.4
Press the button to enter Mode.RIGHT CLOCK
If no signal has been received for seconds, the computer will enter 300
into Sleep Mode, the value remains stored. It will turn back to the CLK
previous mode with all the data collected when the signal is received again
or any button is pressed.
Press the button at any time to enter into freeze frame memory LEFT
mode. Flashing data will appear on the screen. Press the TM RIGHT
button to view the records of , , DST MXS AVS TM. and
Press the button to choose any mode below : , , , RIGHT ODO DST MXS
AVS TM SCAN DST MXS AVS TM CLOCK, , ( , , & ) and . It is not necessary
to press the button except to select the Freeze frame Memory LEFT
mode.
In Freeze Frame Memory mode, press the button, data will be RIGHT
displayed, press button once more to return back to other modes.LEFT
Malfunction
Problems
No speedometer
Incorrect magnet / sensor alignment.
Inaccurate value is
indicated
Improper input, such as wheel
circumference.
Slow display response
Temperature exceeds operating limits
(0°C~55°C).
Black display
Temperature too high, or placed in direct
sunlight for too long. Let the unit cool
down.
Weak display
Poor battery contact or dead battery.
Display shows irregular
figures
Take out battery and re-install after 10
seconds.
Sensor Transmitter
Mounting Shoe
Cable Ties
Wheel Magnet
Model
548B
581A
Battery
1 5V.
AG13
AG10
