IMPORTANT
Installation Kit
120 92-3008P
Before starting, compare items on your invoice with items
received. Carefully check through packaging material.
If an item is missing, please call:
Crutchfield
Parts Supplied:
Kit Frame
Support Tray
Chevrolet
Revision 09/17/03
Kit assembly instructions are on the following pages.
Page 1 of 3
®
Copyright 2003 Crutchfield Corporation
*120923008P*
Mounting Brackets
Left
Right
(2) Studs (2) 3/8” Nuts
(4) 1/4” Hex Screws
Trimplate
at 1-888-955-6000
FIGURE 2
Shaft Supports
Installation Kit
120 92-3008P
Chevrolet
1. Press posts on trimplate kitinto holes on
frame to snap parts together and secure with hex
screws (Figure 1).
2. Use a utility knife to cut out shaft supports in
trimplate to create a DIN opening (Figure 2).
3. Push clips on into slots on rear of kit support tray
frame to secure (Figure 1).
4. Select the right and left side mounting brackets.
Break off the tabs that are shown as shaded (Figure 3).
5. Secure mounting brackets to sides of kit frame with studs
and nuts supplied (Figure 1).
6. Remove DIN sleeve from receiver and slide into
opening in trimplate. Secure sleeve to trimplate by
bending the securing tabs (Figure 4).
7. Slide receiver into sleeve/kit assembly.
DIN Receiver Assembly
2
®
Copyright 2003 Crutchfield Corporation
Securing Tabs
DIN Sleeve
Bend tabs after sleeve
is inside assembly.
FIGURE 1
Trimplate
Kit Frame
Support Tray
Left Mounting Bracket
Stud
Nut
Right Mounting Bracket
FIGURE 3
FIGURE 4
Break off
shaded tabs
Hex Screws
Tools Required
Utility
Knife
â–˛
Small Flat Blade
Screwdriver
1/4” & 3/8”
Sockets
Pliers
Installation Kit
120 92-3008P
Chevrolet
Spacers
(supplied with
your order)
1. Press posts on trimplate into holes on kit frame to
snap parts together and secure with hex screws
(Figure 1).
2. Push clips on into slots on rear of kit frame support tray
to secure (Figure 1).
3. Select the right and left side mounting brackets.
Break off all tabs shown as shaded (Figure 2).
4. Secure mounting brackets to sides of kit assembly with
studs nutsand supplied (Figure 1).
5. Choose the proper spacers (supplied with your order) to
allow receiver nosepiece to extend 1/8” to 1/4” beyond
face of trimplate (Figure 3).
6. Insert receiver shafts (with spacers in place) through
openings in trimplate. Secure receiver and faceplate
with shaftnuts supplied with receiver.
7. Attach control knobs.
1/8” -1/4”
â–˛
â–˛
Spacer
Shaft Receiver Assembly
3
FIGURE 3
Shaftnuts
®
Copyright 2003 Crutchfield Corporation
FIGURE 1
Trimplate
Kit Frame
Support Tray
Left Mounting Bracket
Faceplate
Control Knobs
Tools Required
â–˛
Deep Socket
(size depends upon receiver)
Stud
Nut
Right Mounting Bracket
FIGURE 2
Break off
shaded tabs
1/4” & 3/8”
Sockets
Hex Screws
Pliers
