Rev C Date: 7.30.2014
I:\Oper Manuals\Standard\Harmony_Combo_Conv_Svc_Abv_Rfg_Slf-Svc_Oper_Manual_54383.pub
Structural Concepts Corporation · 888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 · www.structuralconcepts.com
34” DEEP COMBINATION CONVERTIBLE SERVICE ABOVE REFRIGERATED SELF-SERVICE CASE
PLEASE NOTE THE FOLLOWING:
1. YOUR SPECIFIC MODEL NUMBER IS ON THE SERIAL LABEL ON CASE REAR (NEAR MAIN
POWER SWITCH).
2. SEE “MODELS (AND THEIR RESPECTIVE CASE DIMENSIONS) LISTED IN THIS MANUAL”
SECTION FOR ADDITIONAL INFORMATION REGARDING SPECIFIC CASE DIMENSIONS OF
STANDARD MODELS AND CDRs.
3. *(L) DENOTES DIFFERING CASE LENGTHS.
PN 54383
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION AND
OPERATING MANUAL
HMBC5 Case
Shown Above
Note 1: HMBC2 and HMBC3 have an
undivided upper section.
Note 2: HMBC4, HMBC5, HMBC6 have an
divided upper section (as shown above).
2
TABLE OF CONTENTS
TABLE OF CONTENTS ……………………………………………………………………………………...
MODELS LISTED IN MANUAL / DETERMINING THEIR RESPECTIVE CASE DIMENSIONS……..
OVERVIEW / NSF® TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS …………………...…..
INSTALLATION: REMOVAL FROM SKID (LEVELERS vs. CASTERS) ...……...…….……………….
INSTALLATION: LOWER FRONT GRILLE and LOWER REAR PANEL REMOVAL /
REPLACEMENT……………………………………………………………………………………….
INSTALLATION: ELECTRICAL CONNECTIONS …………………………………………………………
INSTALLATION: POSITIONING AND ALIGNING UNITS / GLASS SHELVING ……………………...
INSTALLATION: SETUP / POWER CORDS / TEMPERATURE CONTROLLER ……….……….…...
INSTALLATION, CONTINUED: REMOTE UNIT ELECTRICAL LEADS / REFRIGATION & DRAIN
CONNECTIONS …………...………………………………………………...……………………......
INSTALLATION: CASTERS / LEVELERS / CURVED GLASS / REAR DOORS …………………......
INSTALLATION: DISPLAY CASE START-UP, LIGHTS, TEMPERATURE CONTROLLER, SST ….
INSTALLATION: FRONT GLASS ALIGNMENT & ADJUSTMENT ……………………………………..
BAFFLES: AMBIENT VS. REFRIGERATED CONDITIONS …………………………………………….
OPTIONAL NIGHT AIR CURTAIN INSTALLATION & OPERATING INSTRUCTIONS ……………...
SECURITY GRID INSTRUCTIONS (OPTIONAL) ………………………………………………………...
DRAIN, HOSE AND BRACKET PLACEMENT ILLUSTRATIONS …………..…………..……….……..
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ……....…………...……..
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) …………………………….
MAINTENANCE: LIGHT FIXTURES / REAR SLIDING DOORS (TO BE PERFORMED BY STORE
PERSONNEL) ...........................................................................................................................
MAINTENANCE FUNDAMENTALS: BRACKET RETAINERS / SHELVES / DRAIN / TXV VALVE...
MAINTENANCE FUNDAMENTALS: REFRIG. PACKAGE., TEMPERATURE CONTROLLER,
CONDENSER PAN ACCESS (PERFORMED BY TRAINED SERVICE PROVIDERS ONLY)
MAINTENANCE FUNDAMENTALS: HONEYCOMB AIR DIFFUSERS / UPPER SECTION AIR
DUCT (SERVICE TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ...…..
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) .….….
TROUBLESHOOTING - CONDENSING SYSTEM (TRAINED SERVICE PROVIDERS ONLY) ...…..
TROUBLESHOOTING - EVAPORATOR SYSTEM (TRAINED SERVICE PROVIDERS ONLY) ……
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) …......
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....……….....…
TEMPERATURE CONTROLLER - CAREL® ...…..……………………..……..…………………...……..
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...……….….....
2
3
4-5
6
7
8
9
10
11
12
13
14
15
16
17-18
19
20
21
22
23
24
25
26-28
29
30
31-32
33
34-36
37
MODELS LISTED IN THIS MANUAL / DETERMINING THEIR RESPECTIVE CASE DIMENSIONS
DETERMINING YOUR MODEL AND ITS CASE DIMENSIONS:
Note 1. Your model number can be found on serial label at rear of case (near main power switch).
Note 2. Dimensions of each model can be found at www.structuralconcepts.com. Simply enter
the case model number into the Product Number Search box. Click the product specification
link for complete dimensions.
Note 3. If your specific model is not found, contact technical service (phone number is listed at
Technical Service section in this manual) for dimensions.
Note 4. CDRs (Customer Design Requests) are listed with a 4-digit number. All CDR dimensions
are identical to standard model dimensions.
THIS OPERATING MANUAL ENCOMPASSES THE FOLLOWING MODELS (AND THEIR
RESPECTIVE CDRs):
Models: HMBC2
HMBC3
HMBC4
HMBC5
HMBC6
