Quick-Start Guide
Manual Revision: 07/12/2018
Product Design
Actual product may vary from photos
Front View
Rear View
Package Contents
HDMI Splitter x 1
Universal Power Adapter (NA/JP, UK, EU, ANZ) x 1
Set of Mounting Brackets x 1
Requirements
Operating system requirements are subject to change. For the
latest requirements, please visit .
www.startech.com/ST128HD20
Video Source
HDMI Video Source x 1
Display
The number of displays required will depend on your display
conguration.
HDMI Display Device x 8
Cables
The number of cables required will depend on your device
conguration.
HDMI Cables x 9
SKU #: ST128HD20
8-Port HDMI Video Splitter - 4K 60Hz
Installation
1. Connect an , to the on the HDMI Cable HDMI Input Port HDMI
Splitter.
2. Connect the other end of the to the HDMI Cable HDMI Output
Port Video Source Device on the .
3. Connect an , to the on the HDMI Cable Output 1 Port HDMI
Splitter.
4. Connect the other end of the to the HDMI Cable HDMI Input
Port HDMI Display Device on the .
5. To connect extra to the , repeat Display Devices HDMI Splitter
Steps 1 - 2 (a max. of 8 can be connected to the Display Devices
HDMI Splitter).
6. Connect the to the on the Universal Power Adapter DC/5V Port
HDMI Splitter Universal Power . Connect the other end of the
Adapter AC Electrical Outlet to an .
7. Turn on the .HDMI Video Source
8. Turn on the .HDMI Display Device(s)
EDID
EDID settings are copied from the that is HDMI Display Device
connected to the and applied to the other Output 1 Port HDMI
Display Devices HDMI Splitter connected to the .
Note: Make sure to connect the display with the lowest resolution
to the , to ensure that all connected Output 1 Port HDMI
Display Devices using the lowest EDID settings for compatibility.
LED Indicators
LED Status
Power LED Lights when the is HDMI Splitter
connected to a power source.
Output LEDs Lights when an active video display
is connected to the Output Port.
For the latest information, specications, and support visit www.startech.com/ST128HD20.
On/O
Button
Power
LED
Output 1 - 8
LED
Reset
Button
Output 5 - 8
Ports
Input
Port
DC/5V
Port
Output 1 - 4
Ports
Safety Measures
