Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 11/14/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• DisplayPort® to Dual HDMI® Multi Monitor Adapter

• Instruction Manual

System Requirements

• DisplayPort® enabled computer system/video card

• HDMI® enabled monitor/display devices (e.g. monitor)

SP122DP2HD

DisplayPort® to Dual HDMI® Multi Monitor Adapter

*actual product may vary from photos

Installation

1. Make sure the computer system and monitors/display devices are

powered o.

2. Connect the integrated DisplayPort cable into the DisplayPort

connector on the host computer system/video card.

3. Connect the HDMI® monitor/display device(s) into the connectors

on the expansion module. Make sure to connect monitor/display

device(s) in order from 1 to 2.

4. Power on the monitor/display device(s).

5. Turn on the computer system.

6. The operating system will automatically detect the expansion

module and either clone/mirror a single image on both displays.

Or span the image across both displays.

7. To change the display setting/mode, change the display

resolution via the operating system’s display properties. To use

Clone/ Mirror Mode, set the display resolution to equal or less

than the maximum resolution of the smallest connected display.

Set the display resolution higher, to use Span Mode.

Overview

The SP122DP2HD DisplayPort® to Dual HDMI® Multi Monitor

Spanner Cloner is an innovative, external multi-display adapter that

allows you to add 2 HDMI® displays to your desktop or laptop from a

single DisplayPort source.

The DisplayPort to 2x HDMI® expansion module lets you combine

2 HDMI® monitors as one display, at a maximum resolution of

3840x1200, to make the ultimate wide screen desktop. The DP to

dual HDMI® can also clone your primary display and function as a

Display Port to dual HDMI® Video Splitter.

Compatible with a DisplayPort video card and HDMI® displays, the

graphics expansion module requires no software installation for

multi-display applications, simplifying conguration and

saving time.

Backed by a StarTech.com 2-year warranty and free lifetime

technical support.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Specications

Video Signal DisplayPort®

Number of Ports 2

External Connectors 1x DisplayPort® Male

2x HDMI® Female

Maximum Display

Resolution

One Display: 1920 x 1200

Two Displays: 3840 x 1200

HDCP Compliant Yes

Enclosure Material Plastic

Operating Temperature 0°C to 60°C (32°F to 140°F)
