Seite 1/10
Manual Revision: 08/12/2019
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
PEX1S952
PEX2S952
PEX1S952LP
PEX2S952LP
PCI Express RS232 Serial Adapter Card
with 16950 UART
*PEX2S952 shown
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s
authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual
i
Table of Contents
Introduction ...........................................................................................1
Features 1 .......................................................................................................................................................
Package Contents 1 ....................................................................................................................................
Jumper Conguration ..........................................................................2
Hardware Installation ...........................................................................3
Driver Installation .................................................................................3
Windows Vista Driver Installation 4 ......................................................................................................
Specications ..........................................................................................5
Technical Support ..................................................................................6
Warranty Information ............................................................................6


Produktspezifikationen

Marke: StarTech.com
Kategorie: Nicht kategorisiert
Modell: PEX2S952LP
Breite: 80 mm
Tiefe: 90 mm
Gewicht: 46 g
Mitgelieferte Kabel: Seriell
Produktfarbe: Rot
Höhe: 20 mm
Betriebstemperatur: -10 - 80 °C
Relative Luftfeuchtigkeit in Betrieb: 5 - 85 %
Verpackungsbreite: 145 mm
Verpackungstiefe: 175 mm
Verpackungshöhe: 32 mm
Paketgewicht: 149 g
Zertifizierung: CE, FCC, Microsoft WHQL, TAA
Betriebsanleitung: Ja
Eingebaut: Ja
Temperaturbereich bei Lagerung: -20 - 100 °C
Anzahl Produkte pro Versandkarton: 75 Stück(e)
Länge des Versandkartons: 690 mm
Breite des Versandkartons: 350 mm
Höhe des Versandkartons: 315 mm
Unterstützung anderer Betriebsysteme: Windows XP Embedded
Mittlere Betriebsdauer zwischen Ausfällen (MTBF): 87600 h
Serielle Schnittstelle: RS-232
Treiber enthalten: Ja
Unterstützte Linux-Betriebssysteme: Ja
Montageblöcke enthalten: Ja
Anzahl serielle Anschlüsse: 2
Hostschnittstelle: PCIe
Unterstützte Server-Betriebssysteme: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Anzahl Molex Anschlüsse 4pin: 1
Chipsatz: PLX/Oxford - OXPCIe952
Ausgangsschnittstelle: Seriell
Baudrate: 460.8 Kbit/s
FIFO (First In, First Out): 128 B
Formfaktor der Erweiterungskarte: Full-height / Low-profile
