Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: GuĆ­a del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuƔrio - pt.startech.com
Manual Revision: 02/07/2012
For the most up-to-date information, please visit: www.startech.com
MCMGBSC15 / MCMGBSC15GB / MCMGBSC15EU
1000 Mbps Gigabit Single-Mode Fiber Ethernet Media Converter
*actual product may vary from photos
Packaging Contents
ā€¢ī˜ 1ī˜xī˜MCMGBSC15ī˜/ī˜GBī˜/ī˜EUī˜mediaī˜converter
ā€¢ī˜ 1ī˜xī˜Powerī˜Adapter
ā€¢ī˜ 1ī˜xī˜Installationī˜Guide
System Requirements
ā€¢ī˜ Gigabitī˜(1000Mb/s)ī˜Ethernetī˜network
ā€¢ī˜ Gigabitī˜(1000Mb/s)ī˜Fiberī˜network
LED Indicators
LED Status Description
PWR
ON Powerī˜On
OFF Powerī˜Oī›²
FX LINK
ON Fiberī˜Linkī˜Detected
OFF Noī˜Fiberī˜Linkī˜Detected
TP
LINK
ON Ethernetī˜Linkī˜Detected
OFF Noī˜Ethernetī˜Linkī˜Detected
RX
ON Unitī˜isī˜receivingī˜dataī˜fromī˜Ethernetī˜port
OFF Noī˜incomingī˜dataī˜fromī˜Ethernetī˜port
RJ45ī˜Ethernetī˜port
SCī˜Fiberī˜port
LEDī˜
indicators
DCī˜powerī˜port Modeī˜switch
Front View
Rear View
FCC Compliance Statement
Thisī˜equipmentī˜hasī˜beenī˜testedī˜andī˜foundī˜toī˜complyī˜withī˜theī˜limitsī˜forī˜aī˜Classī˜Bī˜digitalī˜device,ī˜pursuantī˜toī˜partī˜15ī˜ofī˜theī˜FCCī˜Rules.ī˜Theseī˜limitsī˜areī˜designedī˜toī˜provideī˜reasonableī˜protectionī˜againstī˜
harmfulī˜interferenceī˜inī˜aī˜residentialī˜installation.ī˜Thisī˜ equipmentī˜generates,ī˜usesī˜andī˜canī˜radiateī˜radioī˜frequencyī˜energyī˜and,ī˜ifī˜notī˜installedī˜andī˜usedī˜inī˜accordanceī˜withī˜theī˜instructions,ī˜mayī˜causeī˜
harmfulī˜interferenceī˜toī˜radioī˜communications.ī˜However,ī˜thereī˜isī˜noī˜guaranteeī˜thatī˜interferenceī˜willī˜notī˜occurī˜inī˜aī˜particularī˜installation.ī˜Ifī˜thisī˜equipmentī˜doesī˜causeī˜harmfulī˜interferenceī˜toī˜radioī˜orī˜
televisionī˜reception,ī˜whichī˜canī˜beī˜determinedī˜byī˜turningī˜theī˜equipmentī˜oī›²ī˜andī˜on,ī˜theī˜userī˜isī˜encouragedī˜toī˜tryī˜toī˜correctī˜theī˜interferenceī˜byī˜oneī˜orī˜moreī˜ofī˜theī˜followingī˜measures:
ā€¢ī˜ Reorientī˜orī˜relocateī˜theī˜receivingī˜antenna.
ā€¢ī˜ Increaseī˜theī˜separationī˜betweenī˜theī˜equipmentī˜andī˜receiver.
ā€¢ī˜ Connectī˜theī˜equipmentī˜intoī˜anī˜outletī˜onī˜aī˜circuitī˜diī›²erentī˜fromī˜thatī˜toī˜whichī˜theī˜receiverī˜isī˜connected.
ā€¢ī˜ Consultī˜theī˜dealerī˜orī˜anī˜experiencedī˜radio/TVī˜technicianī˜forī˜help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
Thisī˜ manualī˜ mayī˜ makeī˜ referenceī˜ toī˜ trademarks,ī˜ registeredī˜ trademarks,ī˜ andī˜ otherī˜ protectedī˜ namesī˜ and/orī˜ symbolsī˜ ofī˜ third-partyī˜ companiesī˜ notī˜ relatedī˜ inī˜ anyī˜ wayī˜ toī˜ī˜
StarTech.com.ī˜ī˜Whereī˜theyī˜occurī˜theseī˜referencesī˜areī˜forī˜illustrativeī˜purposesī˜onlyī˜andī˜doī˜notī˜representī˜anī˜endorsementī˜ofī˜aī˜productī˜orī˜serviceī˜byī˜StarTech.com,ī˜orī˜anī˜endorsementī˜ofī˜theī˜product(s)ī˜
toī˜whichī˜thisī˜manualī˜appliesī˜byī˜theī˜third-partyī˜companyī˜inī˜question.ī˜ī˜Regardlessī˜ofī˜anyī˜directī˜acknowledgementī˜elsewhereī˜inī˜theī˜bodyī˜ofī˜thisī˜document,ī˜StarTech.comī˜herebyī˜acknowledgesī˜thatī˜allī˜
trademarks,ī˜registeredī˜trademarks,ī˜serviceī˜marks,ī˜andī˜otherī˜protectedī˜namesī˜and/orī˜symbolsī˜containedī˜inī˜thisī˜manualī˜andī˜relatedī˜documentsī˜areī˜theī˜propertyī˜ofī˜theirī˜respectiveī˜holders.
Technical Support
StarTech.comā€™sī˜lifetimeī˜technicalī˜supportī˜isī˜anī˜integralī˜partī˜ofī˜ourī˜commitmentī˜toī˜provideī˜industry-leadingī˜solutions.ī˜ī˜Ifī˜youī˜everī˜needī˜helpī˜withī˜yourī˜product,ī˜visitī˜www.startech.com/supportī˜andī˜accessī˜
ourī˜comprehensiveī˜selectionī˜ofī˜onlineī˜tools,ī˜documentation,ī˜andī˜downloads.ī˜ī˜
Forī˜theī˜latestī˜drivers/software,ī˜pleaseī˜visitī˜www.startech.com/downloads
Warranty Information
Thisī˜productī˜isī˜backedī˜byī˜aī˜twoī˜yearī˜warranty.ī˜
Inī˜addition,ī˜StarTech.comī˜warrantsī˜itsī˜productsī˜againstī˜defectsī˜inī˜materialsī˜andī˜workmanshipī˜forī˜theī˜periodsī˜noted,ī˜followingī˜theī˜initialī˜dateī˜ofī˜purchase.ī˜Duringī˜thisī˜period,ī˜theī˜productsī˜mayī˜beī˜returnedī˜
forī˜repair,ī˜orī˜replacementī˜withī˜equivalentī˜productsī˜atī˜ourī˜discretion.ī˜Theī˜warrantyī˜coversī˜partsī˜andī˜laborī˜costsī˜only.ī˜StarTech.comī˜doesī˜notī˜warrantī˜itsī˜productsī˜fromī˜defectsī˜orī˜damagesī˜arisingī˜fromī˜
misuse,ī˜abuse,ī˜alteration,ī˜orī˜normalī˜wearī˜andī˜tear.
Limitation of Liability
Inī˜noī˜eventī˜shallī˜theī˜liabilityī˜ofī˜StarTech.comī˜Ltd.ī˜andī˜StarTech.comī˜USAī˜LLPī˜(orī˜theirī˜oī›³cers,ī˜directors,ī˜employeesī˜orī˜agents)ī˜forī˜anyī˜damagesī˜(whetherī˜directī˜orī˜indirect,ī˜special,ī˜punitive,ī˜incidental,ī˜
consequential,ī˜orī˜otherwise),ī˜lossī˜ofī˜proī›¶ts,ī˜lossī˜ofī˜business,ī˜orī˜anyī˜pecuniaryī˜loss,ī˜arisingī˜outī˜ofī˜orī˜relatedī˜toī˜theī˜useī˜ofī˜theī˜productī˜exceedī˜theī˜actualī˜priceī˜paidī˜forī˜theī˜product.ī˜ī˜Someī˜statesī˜doī˜notī˜allowī˜
theī˜exclusionī˜orī˜limitationī˜ofī˜incidentalī˜orī˜consequentialī˜damages.ī˜Ifī˜suchī˜lawsī˜apply,ī˜theī˜limitationsī˜orī˜exclusionsī˜containedī˜inī˜thisī˜statementī˜mayī˜notī˜applyī˜toī˜you.
Speciī˜Ÿcations
Connectors
1ī˜xī˜RJ45ī˜Ethernet
2ī˜xī˜SCī˜Fiber
1ī˜xī˜Powerī˜connector
LEDs Power,ī˜Fiberī˜Link,ī˜Fiberī˜Receive,ī˜Ethernetī˜
Link
Fiber Type Singleī˜Modeī˜9/125ī˜micron
Maximum Distance 15km
Transmission
Standards
IEEE802.3ab,ī˜802.3z,ī˜802.3x
Duplex Mode Full/Halfī˜(Auto-Detect)
Dimensions 99.0mmī˜xī˜73.0mmī˜xī˜27.0mm
Weight 450g
Installation
1. Connectī˜theī˜Ethernetī˜cableī˜toī˜theī˜Fiberī˜Mediaī˜Converterī˜RJ45
Ethernetī˜port.
2. Connectī˜theī˜otherī˜endī˜ofī˜theī˜Ethernetī˜cableī˜toī˜theī˜router/switch/
computerī˜NIC.
3. Connectī˜theī˜ī›¶berī˜cableī˜intoī˜theī˜ī›¶berī˜receptacleī˜onī˜theī˜media
converter.
4. Plugī˜theī˜providedī˜powerī˜adapterī˜intoī˜theī˜mediaī˜converter,ī˜and
intoī˜anī˜availableī˜ACī˜powerī˜outlet.
5. Connectī˜theī˜otherī˜endī˜ofī˜theī˜ī›¶berī˜cableī˜intoī˜theī˜router/switch/
computerī˜NIC/anotherī˜mediaī˜converter.ī˜Rememberī˜toī˜reverseī˜the
TXī˜andī˜RXī˜leadsī˜betweenī˜theī˜twoī˜devices.
Installation
The Mode Switch on the rear of the media converter can be
used control the duplex mode on the fiber side of the media
converter.
In most cases, set the Mode Switch to AUTO. If you are
connecting to another media converter FORCE mode may
need to be selected.
Auto Mode:
Auto mode is set by default and the media converter will try
to auto negotiate the fiber link. In some cases, when
connecting to another media converter on the fiber side, both
units set to "Auto" can cause an endless loop and prevent a
link from being established.
Force Mode:
Force is the alternative operating mode. In cases where a link
is not being established, the media converter needs to be
statically set to one mode only. Set the mode switch to FORCE
in these instances (such as when connecting the media
converter to another media converter).
