Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 06/29/2018

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1 x USB to Serial and Parallel Adapter Cable

System Requirements

• USB enabled computer system with available USB port

• Microsoft® Windows® XP/Vista/7 (32/64-bit), CE 5.0, or Linux®

ICUSB2321284

USB to Serial RS232 and Parallel Adapter Cable

*actual product may vary from photos

Installation

Windows XP/Vista/7

1. Connect the USB adapter to an available USB port on the host

computer system.

2. If Windows attempts to install the drivers automatically, cancel

any prompts that appear, and insert the Driver CD into the

computer’s CD/DVD drive.

*installation photos for reference only

3. If AutoPlay is enabled, choose the option to browse/view the

contents of the CD. Otherwise, open My Computer and double-

click the CD/DVD drive.

4. Go into the “ICUSB2321284“ folder and then the folder for your

operating system version. Double-click the ‘Setup.exe” le to

being the installation wizard.

5. Proceed through the installation wizard. If you are prompted

with a Windows Security dialog box, click the “Install this driver

software anyway” button.

6. Once the installation wizard is complete, the drivers for the USB

adapter will be successfully installed.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a three (3) year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Specications

Host Interface USB 1.1

Chipset ID MosChip MCS7715CQ-GR

Connectors

1 x DB9 male

1 x DB25 female

1 x USB type A male

LEDs N/A

Supported Protocols RS232, IEEE 1284 (SPP)

Maximum Data Transfer

Rate 921.6 Kbps

Serial Data Bits 5, 6, 7, 8
