Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 07/18/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1 x FireWire ExpressCard

• 1 x FireWire Cable

• 1 x Instruction Manual

Features

• High speed data transfer rates of up to 400 Mbps

• Compliant with IEEE 1394-1995, 1394a-2000 and OHCI 1.1 standards

• Supports asynchronous and isochronous data transfer modes

• Hot swap capable - allows you to connect or disconnect devices

without turning o your notebook computer

System Requirements

• ExpressCard enabled computer system with available slot

• Microsoft® Windows® 2000/ XP(32/64-bit)/ 2003(32/64-bit)/

Vista(32/64-bit)/ 7(32/64-bit)/ 8(32/64-bit)/ Server 2008 R2, or

Apple® Mac OS® 10.5 and up, or Linux®

Instalation

Hardware Installation

The ExpressCard adapter will simply slide into the ExpressCard

slot on any compatible system. Push the card all the way in, until it

‘clicks’ and locks into place. To eject the card, simply push the card

further into the slot until it clicks, and then release and it will then be

ejected from the slot.

NOTE: Some ExpressCard/54 slots do not rmly hold an

ExpressCard/34 card, so a 34mm to 54mm stabilizer bracket may be

necessary (StarTech.com ID: ECBRACKET).

OPTIONAL: This card has an external power connector located on

the side. External power may be required if the FireWire peripheral

draws more power than the ExpressCard slot on the system is able

to provide.

Driver Installation

Windows 2000/XP/Server 2003/Vista/Server 2008 R2/7/8,

Mac OS X, Linux

No driver installation is required for these operating systems,

as this adapter card is natively supported, so the drivers are

already installed.

Verifying Installation

Windows 2000/XP/Server 2003/Vista/Server 2008 R2/7/8

From the main desktop, right-click on “My Computer” (“Computer”

in Vista/7), then select Manage. In the new Computer Management

window, select Device Manager from the left window panel.

Double-click on the “IEEE1394” category and a “TI” controller device

should be listed without any errors.

Connecting FireWire devices to ExpressCard

To begin using your FireWire peripherals with EC13942, simply insert

the FireWire connector provided by the peripheral or attached cable

into one of the FireWire ports provided by the ExpressCard. Please

note that for peripherals requiring lower voltages, EC13942 oers

built-in power capability. If more power is required, an external

12VDC (1A) power adapter (not included) can be connected to the

power jack on the ExpressCard.

EC13942

2 Port ExpressCard 1394a Firewire Card

*actual product may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Specications

Host Interface ExpressCard 1.0a

Form Factor ExpressCard/34 (34mm)

Chipset ID TI XI02200A

Connectors 2 x 6-pin FireWire female

1 x DC Power

Maximum Data Transfer

Rate FireWire400: 400Mbps

Power Adapter

(not included)

12V DC, 1000+mA, center positive,

type-H plug
