Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: GuĆ­a del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuƔrio - pt.startech.com
Manual Revision: 01/18/2012
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
ā€¢ī˜ 1xComponenttoVGAvideoconverter
ā€¢ī˜ 1xPowerAdapter
ā€¢ī˜ 1xInstructionManual
System Requirements
ā€¢ī˜ YPbPrComponentvideosource(i.e.DVR/PVR,DVDplayer,etc.)
ā€¢ī˜ VGAdisplaydevice(i.e.monitor,projector,HDTV,etc.)
ā€¢ī˜ AvailableACelectricaloutlet
ā€¢ī˜ RCAComponentVideocable
ā€¢ī˜ VGAvideocable
ā€¢ī˜ Optional:RCAstereoaudiocable
ā€¢ī˜ Optional:3.5mmAudiomini-jackcable
CPNT2VGAA / CPNT2VGAAGB / CPNT2VGAAEU
Component to VGA Video Converter with Audio
*actual product may vary from photos
Installation
1. Makesurethevideosourceanddisplaydevicearepoweredoī›²ī˜
beforemakinganyconnections.
2. ConnectthevideosourcetotheInputsideofthevideo
convertingusingRCAcomponentvideocables(notincluded).If
alsousingaudio,connectRCAstereoaudiocables(notincluded)
fromthesourcetotheconverter.
3. ConnectthedisplaydevicetothevideoconvertingusingaVGA
videocable(notincluded).Ifalsousingaudio,connecta3.5mm
audiomini-jackcable(notincluded)fromthespeakerstothe
converter.
4. Connecttheincludedpoweradapterfromanelectricalsourceto
thevideoconverter.ThePowerLEDwilllightupsolid.
5. Turnthedisplaydeviceon,followedbythevideosource.
Front View
Rear View
FCC Compliance Statement
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoī›²ī˜andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
ā€¢ī˜ Reorientorrelocatethereceivingantenna.
ā€¢ī˜ Increasetheseparationbetweentheequipmentandreceiver.
ā€¢ī˜ Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.
ā€¢ī˜ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to
StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)
towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall
trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.
Technical Support
StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess
ourcomprehensiveselectionofonlinetools,documentation,anddownloads.
Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads
Warranty Information
Thisproductisbackedbyatwoyearwarranty.
Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned
forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom
misuse,abuse,alteration,ornormalwearandtear.
Limitation of Liability
InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,
consequential,orotherwise),lossofproī›¶ts,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow
theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.
Specications
Video Signal Input YPbPrcomponentvideo
Video Signal Output VGA(RGBHV)
Connectors
3xRCAComponentvideofemale
2xRCAStereoaudiofemale
1xDE-15VGAfemale
1x3.5mmAudiofemale
1xDCPower
LEDs N/A
Supported Video
Resolutions
480i,480p,576i,576p,720p,1080i,
1080p
Video Bandwidth 70MHz(-3dB)
Enclosure Material Metal
Power Adapter 9VDC,600mA,centerpositive
Dimensions 67.0mmx57.5mmx38.0mm
Weight 150g
