Seite 1/24
2000W INVERTER GENERATOR
OWNERS OPERATING MANUAL
04395 05/22
FMXGN4200021
For service, spare parts or product information,
please contact Smart Marketing Group Pty. Ltd.
AUST. 1300 660 457 N.Z. 0800 474 876
www.stanleyproducts.com.au
2
UNLEADED 91
PETROL ONLY
NO ETHANOL
ELECTRIC SHOCK
HAZARD
ALTERNATE
POWER SOURCE
EXPLOSION
HAZARD
ASPHYXIATION
HAZARD
USE OUTDOORS
READ MANUAL
BEFORE USE
POSSIBLE BACK
STRAIN
- HEAVY WEIGHT
NO NAKED
FLAMES
NO LIQUID
NEAR PLUG
WEAR HEARING
PROTECTION
WARNINGS - READ
MANUAL BEFORE USE
HOT SURFACES
NEARBY
CONTENTS
Section Page
Specification 2
Suggested Applications 2
Introduction 3
Warranty Statement 4
General Safety Instructions 5 - 6
Specific Safety Instructions 7
Electrical Information 8
Fuel and Oil Information 8
Components and Controls 9
Operating Instructions 10-15
Maintenance Chart 17
Maintenance 18-19
Fault Chart 20-21
Service Log 22
TECHNICAL INFORMATION
Specifications
Inverter Generator FMXGN4200021
Engine type Single cylinder, 4 stroke 79.8cc
Rated engine speed 4800r/min
Oil tank capacity 400ml
Oil type 4 Stroke fully synthetic motor oil,
SAE 15W-40 (API SN Category)
Fuel tank capacity 4L
Fuel type Unleaded 91 Petrol - no ethanol
Spark plug E5RTC
Rated voltage 240V AC-50Hz
Rated output 1800W
Maximum output 2000W
Rated current 7.5A
Power factor 1.0
12V DC output 8.3A
USB output 5V, Max. 2.1A
Running Time 3.5hrs at rated output
Inverter Yes - Pure sine wave
Spark arrestor Yes
Noise
0W Load - 58db(A) @ 7m
900W Load - 64db(A) @ 7m
1350W Load - 67db(A) @ 7m
1800W Load - 68db(A) @ 7m
Net weight 18kg, not including fuel
SUGGESTED APPLICATIONS
These are some suggestions of appliances which could be
powered by this generator. These suggestions cannot all be run
at the same time, please read page 14 for full details:
• Televisions up to 150W
• AC/DC Camping fridges up to 150W
• DVD/Video players up to 400W
• Laptop computers up to 700W
• TV and DVD/Video player combination up to 800W
• Mobile phone/hand held games charging up to 900W
• Power tools up to 1300W
• Lighting up to 1650W
Never exceed 1650W in total when using multiple appliances.
3
INTRODUCTION
Dear Customer,
Thank you for purchasing this generator which has passed
through our extensive quality assurance processes. Every
care has been taken to ensure that it reaches you in perfect
condition. However, in the unlikely event that you should
experience a problem, or if you require any assistance please
do not hesitate to contact us;
If you have a problem, call customer service do not
return this generator to the place of purchase.
Note: For convenience we suggest taking a photocopy of your
purchase receipt as the original may fade.
Due to continual product development, the actual product may
differ slightly from the product pictured.
CUSTOMER SERVICE
Australia: 1300 660 457
New Zealand: 0800 474 876
Operating times: Monday – Friday
8.00am - 5.00 pm
Australian Eastern Standard Time (AEST)
EXPRESS WARRANTY STATEMENT
GENERATORS
You are not required to do anything to register your generator
purchase. Please attach the purchase receipt to this manual
and ensure both are kept safe. We hope you enjoy your
new generator, and if you have any problems call customer
service on the above phone numbers. Do not return to place of
purchase.
Smart Marketing Group Pty Ltd (SMG) warrants that this
generator will be free from manufacturing faults or defects
for 12 months from the date of purchase, providing original
purchase receipt is kept and shown when needed and is subject
to the terms and
conditions below.
If a warranty fault appears within the warranty period, SMG
reserves the right to replace or repair the product. In the event
that SMG chooses to replace the product, this original warranty
will expire at the original date. If the product includes various
accessories or components, only the defective accessory or
component will be replaced or repaired.
SMG reserves the right to replace defective parts of the
product with parts and components of similar quality, grade
and composition where an identical part or component is not
available.
Products presented for repair may be replaced by refurbished
products of the same type rather than being repaired.
Refurbished parts may be used to repair the products.
WHAT IS COVERED
• Manufacturing fault or defect.
HOW TO CLAIM UNDER THIS WARRANTY
• Call customer service, phone number to the left.
• Ensure you have the following: Original purchase receipt,
Model of generator, Serial number of generator.
• Discuss the issue.
• Customer service will advise which authorised service
agent to take the generator to provided the issue is a
warranty one.
• Take generator to authorised service agent for repair.
WHAT IS NOT COVERED
• Commercial use of generator.
• Use of Generator for hire.
• Use of generator in a commercial premises.
• Damage caused by incorrect oil.
• Damage caused by incorrect fuel or use of E10 ethanol fuel.
• Damage or deterioration due to transport.
• Damage caused by negligence, misuse, abuse or accident
or incorrect voltage and wattage.
• Any corrosion or rusting.
• Damage caused by incorrect set up and start up.
• Replacement parts due to general wear and tear.
• Generators with serial number defacement, modification or
removal.
• Generators which have been serviced by anyone other than
an authorised SMG service agent.
• Generators with no original purchase receipt.
• Generators which have been on sold, not original purchaser.
• Damage due non-servicing of generator as is required by
this manual.
• Blockages / damage caused by dust, dirt, spiders webs or
insects.
• Damage caused by the incorrect fitting of accessories.
• Damage caused by overloading, overworking the generator.
• Damage to attached equipment or third party accessories.
• Damage caused by attached equipment or third
party accessories.
CONTACT DETAILS
Smart Marketing Group Pty Ltd
33-35 Lionel Road, Mt. Waverley
Victoria 3149, Australia.
Tel (+613) 9543 7266
Fax (+613) 9543 9839
service.group@smga.com.au
