Seite 1/24
VOL/
PWR
STANDARD HORIZON
Simple Operation
Submersible Microphone
Programmable Scan & Priority Ch16 Scan
NOAA Weather Alert
Backlit LCD & Keys
ECLIPSE + GX1250SA
25 watt VHF/FM
Marine Transceiver
Owner’s Manual
TABLE OF CONTENTS
FCC NOTICE .......................................................................................................... 1
1 GENERAL INFORMATION .............................................................................. 3
1.1 INTRODUCTION ................................................................................. 3
1.2 FCC/ INDUSTRY CANADA INFORMATION ....................................... 4
2 ACCESSORIES ............................................................................................... 5
2.1 PACKING LIST .................................................................................... 5
2.2 OPTIONS ............................................................................................. 5
3 CONTROLS AND INDICATORS ..................................................................... 6
3.1 CONTROLS AND CONNECTIONS ..................................................... 6
3.2 INDICATORS ..................................................................................... 10
4 INSTALLATION ............................................................................................. 12
4.1 FREQUENCY AND DEVIATION TESTS ........................................... 12
4.2 LOCATION......................................................................................... 12
4.3 INSTALLATION USING REGULAR MOUNTING BRACKET ............ 13
4.4 CMB16 FLUSH MOUNT INSTALLATION ......................................... 14
5 OPERATION ................................................................................................. 15
5.1 RECEPTION ...................................................................................... 15
5.2 TRANSMISSION................................................................................ 15
5.3 TRANSMIT TIME - OUT TIMER (TOT) ............................................. 16
5.4 SIMPLEX/DUPLEX CHANNEL USE ................................................. 16
5.5 USA, CANADA, AND INTERNATIONAL MODE ............................... 16
5.6 NOAA WEATHER CHANNELS ......................................................... 17
5.7 NOAA WEATHER ALERT ................................................................. 17
5.8 MEMORY SCANNING ....................................................................... 18
5.9 PRIORITY SCANNING (PRI-SCAN) ................................................. 18
6 MAINTENANCE ............................................................................................. 19
6.1 REPLACEMENT PARTS ...................................................................... 19
6.2 TROUBLESHOOTING CHART ............................................................ 20
7 SPECIFICATIONS ......................................................................................... 21
7.1 GENERAL .......................................................................................... 21
7.2 TRANSMITTER ................................................................................. 21
7.3 RECEIVER......................................................................................... 21
GX1250SA Owner’s Manual page 1
FCC NOTICE
IMPORTANT NOTICE
The following device operating configurations must be satisfied:
— This radio is restricted to occupational use, work related
operations only where the radio operator must have the
knowledge to control its RF exposure conditions.
— The radio must be used with a maximum operating duty cycle not
exceeding 50%, in typical Push-to-Talk configurations.
— When transmitting, hold the radio in a vertical position with its
microphone 1 to 2 inches (2.5 to 5 cm) away from your mouth and
keep the antenna at least 1 inch (2.5 cm) away from your head
and body.
SAFETY / WARNING INFORMATION
WARNING - DO NOT operate the ECLIPSE+ radio when someone
(bystanders) outside the vehicle is within (to calculate) 3 feet (1 meter)
of the antenna.
ANTENNA INSTALLATION:
For rear deck trunk installation, the antenna must be located at least 3
feet (1 m) away from rear seat passengers in order to comply with the
FCC RF exposure requirements.
For roof top installation, the antenna must be placed in the center of
the roof.
