Seite 1/64
BEL1 Battery Event
Light 15W,
BEL1+ Battery Event
Light 15W
LED spotlight
user manual
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
30.03.2021, ID: 461293_461292 (V2)
Table of contents
1 General information 5.................................................................................................................................
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions 11..................................................................................................................................
3 Features 16.......................................................................................................................................................
4 Installation 17..................................................................................................................................................
4.1 Dealing with lithium batteries..................................................................................................... 22
5 Starting up 24..................................................................................................................................................
6 Connections and controls 25...................................................................................................................
7 Operating 31....................................................................................................................................................
7.1 Starting the device........................................................................................................................... 31
7.2 Main menu.......................................................................................................................................... 31
7.3 Using Wireless DMX (W-DMX)..................................................................................................... 41
7.4 Menu overview................................................................................................................................. 43
Table of contents
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
3
7.5 Functions in 5-channel DMX mode........................................................................................... 47
7.6 Functions in 9-channel DMX mode........................................................................................... 48
8 Technical 51specications.......................................................................................................................
9 Troubleshooting 55......................................................................................................................................
10 Cleaning 57.......................................................................................................................................................
11 Protecting the environment 58..............................................................................................................
Table of contents
LED spotlight
4
1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under .www.thomann.de
General information
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
5
1.1 Further information
On our website ( you will lots of further information and details on thewww.thomann.de) nd
following points:
Download This manual is also available as PDF for you to download.le
Keyword search Use the search function in the electronic version to the topics ofnd
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
LED spotlight
6
1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: control, button.[VOLUME] [Mono]
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: , .‘24ch’ ‘OFF’
Letterings
Displays
General information
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
7
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press .[Auto]
ðAutomatic operation is started.
3. Switch the device.o
1.3 Symbols and signal words
In this section you will an overview of the meaning of symbols and signal words that arend
used in this manual.
Instructions
General information
LED spotlight
8
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – dangerous optical radiation.
General information
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
9
Warning signs Type of danger
Warning – suspended load.
Warning – danger zone.
General information
LED spotlight
10
2 Safety instructions
This device is intended for use as an electronic lighting by means of LED technology. Theeect
device is designed for professional use only and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with physical, sensorial, and intellectualsucient
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the operating life of the device by regular breaks and by avoiding frequent
switching on and The device is not suitable for continuous operation.o.
Intended use
Safety instructions
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
11
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking
hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke! Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts
inside. Do not use the device if covers, protectors or optical components are missing or damaged.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a protective contact plug. Do not modify the mains cable
or the plug. Failure to do so could result in electric shock/death or If in doubt, seek advice from a registered electrician.re.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
Safety instructions
LED spotlight
12
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights.
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Follow the advice on
the correct handling of lithium batteries in the present section.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked ames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid
direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions in the chapterspecied
‘Technical of this user manual. Avoid heavy temperature and do not switch the device on immediatelyspecications’ uctuations
after it was exposed to temperature (for example after transport at low outside temperatures). Dust and dirt inside canuctuations
damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other malfunction.
Safety instructions
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
13
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC
outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the
user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric
shock or re.
NOTICE!
Risk of due to incorrect polarityre
Incorrectly inserted batteries may destroy the device or the batteries. Ensure that proper polarity is observed when inserting bat‐
teries.
NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a
longer period.
NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate
or PVC and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the butoor oor,
use felt-pad protectors or a carpet.oor
Safety instructions
LED spotlight
14
NOTICE!
Possible damage to lithium-ion batteries through incorrect storage
By deep discharge, lithium-ion batteries can be permanently damaged or lose some of their capacity. Before long breaks, charge the
batteries to around 50 % of their capacity and then switch the device. Store the device at room temperature or cooler in an envi‐o
ronment as dry as possible. If the batteries are stored for a longer period, recharge them to 50 % every three months. Fully charge
the batteries only shortly before use at room temperature.
Safety instructions
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
15
3 Features
Special features of the device:
nFive-colour LED (RGBAW, 15 W)
nItem no. 461293: Stand alone mode operation
nItem no. 461292: Operable in stand-alone mode or DMX
nItem no. 461293: Control via the supplied infrared remote control and via buttons and
colour display on the unit
nItem no. 461292: Control via DMX, wireless DMX, (Wireless Solution G5), with the supplied
infrared remote control and via buttons and colour display on the unit
nNumerous pre-programmed mixed colours and eects
nSound control
nVarious mounting options
nBattery or mains powered
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
Features
LED spotlight
16
4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Installation
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
17
NOTICE!
Risk of overheating
The distance between light output and the illuminated surface must be more
than 1.5 m (19.7in).
Provide ventilation.sucient
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
You can install the device using a stand, as well as standing or hanging upside down. When in
use, the device must always be attached to a solid surface or an approved truss.
Always work from a stable platform whenever installing, moving or servicing the unit. In doing
so, the area underneath the unit must be cordoned o.
Mounting options
Installation
LED spotlight
18
The safety cable must be threaded through the openings in the bracket.
Please note that this device must not be connected to a dimmer.
The infrared sensor for the remote control signals is located in front of the LEDs on the front
panel. Make sure it's not obstructed.
Infrared sensor for the remote
control
Installation
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
19
Press the lock of the battery holder to the centre of the housing and pull out the battery holder
like a drawer. Insert the battery. The battery is correct if the positive pole points to the housing
base of the remote control. Slide the battery holder back into the remote until it clicks into
place.
When shipping, the battery is already installed in the remote and protected against discharge
by a transparent plastic foil. Remove the plastic foil prior to use.rst
Inserting the battery into the
remote control
Installation
LED spotlight
20
Never attempt to recharge non-rechargeable lithium batteries. When charging lithium bat‐
teries you must use a suitable charging device intended for the purpose.
Before disposing of the device remove the lithium batteries. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape.
Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning
lithium battery.
Installation
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
23
5 Starting up
Create all connections while the device is Use the shortest possible high-quality cables foro.
all connections. Take care when running the cables to prevent tripping hazards.
Starting up
LED spotlight
24
1 Infrared sensor for the remote control signals
2 Mounting bracket
3 Locking screw for the mounting bracket
4 Only for item # 461292: [DMX]
The LED indicates an incoming Wireless DMX signal.
5 [Sound]
The LED indicates that the Sound control is active.
6 [Mic]
Microphone for sound control
7 button[Menu]
Activates the main menu and toggles between menu items. Closes an opened submenu.
8, 9 , buttons[Up] [Down]
Toggles between the menu items of a menu level, increases or decreases the displayed value by one.
Connections and controls
LED spotlight
26
Remote control
Connections and controls
LED spotlight
28
15 [BLACK OUT]
Enables or disables blackout.
16 [AUTO]
Starts or stops the Auto mode.
17 [SOUND]
Starts the music-controlled automatic show.
18 [STROBE]
Enables or disables the Strobe with the last selected colour.eect
19 [SPEED]
Allows you to set the speed of the automatic programmes with and .[+] [–]
20 [SENSITIVITY]
Allows you to set the sensitivity of the Sound control with and .[+] [–]
21 [%]
Resets during the setting of values (speed of the automatic programs, sensitivity of the music control) the displayed
value to zero.
Connections and controls
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
29
22 [MANUAL]
Activates the display of a constant colour, that can either be mixed individually with , and from the basic[R] [G] [B]
colours, or selected directly with one of the coloured buttons.
23 [FADE]
Allows you to choose between the two automatic options by pressing repeatedly.
24 , , [R] [G] [B]
Sets the intensity of the three primary colours red, green and blue when a constant colour is displayed.
25 , [A] [W]
Sets the intensity of the colours amber and white when a constant colour is displayed. button without function.[UV]
26 , [+] [–]
Increases or decreases the set value.
27 Buttons for directly selecting a mixed colour.
Connections and controls
LED spotlight
30
7 Operating
7.1 Starting the device
Connect the device to the power supply to start operation. After a few seconds, the display
indicates that a reset is in progress. The device is then ready for use. The display shows the
operating mode that was selected when the unit was last powered o.
7.2 Main menu
Press to activate the main menu. Use or to select a submenu. When the[Menu] [Up] [Down]
display shows the desired submenu press to open it up. To close the main menu, press[Enter]
[Menu]. The stored values are displayed in white in the display. Changed values are displayed
in red until they are with .conrmed [Enter]
The following table shows the setting options.
Operating
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
31
Main menu Menu level 2 Menu level 3 Menu level 4
Meaning
‘Step’ ‘Se00’ ‘Se99’… Sensitivity of the built-in
microphone for colour
change
‘Fade’ ‘Se00’ ‘Se99’… Sensitivity of the built-in
microphone for fade
eect
‘Static’ ‘Dimmer’ 0…255 Setting the overall
brightness
‘Strobe’ 0…255 Stroboscope witheect
adjustable speed
‘C-Macro’ 1…9 Selection of a mixed
colour
‘Red’ 0…255 Intensity red (0 % to
100 %)
Operating
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
37
Main menu Menu level 2 Menu level 3 Menu level 4
Meaning
‘ ’O Disabled
‘Display Rev’ Display inversion
‘On’ On, display is rotated by 180°
‘ ’O O, normal display
‘Limiter’ Lower the maximum brightness to extend battery life
‘On’ Enabled
‘ ’O Disabled
‘Dmx Fail’ Device behaviour on DMX signal failure
‘Blackout’ Blackout
‘Sound’ Sound-controlled auto run
‘Auto’ Auto run with fade eect
‘Hold’ Retaining last settings
Operating
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
39
BEL1+ Battery Event Light 15W
(item no. 461292)
Operating
BEL1 Battery EventLight 15W, BEL1+ Battery EventLight 15W
45

Produktspezifikationen

Marke: Stairville
Kategorie: Erleichterung
Modell: BEL1 Battery Event Light

Brauchst du Hilfe?

Wenn Sie Hilfe mit Stairville BEL1 Battery Event Light benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Erleichterung Stairville

Stairville

Stairville DCL Flat Par 5x4W Bedienungsanleitung

22 August 2024
Stairville

Stairville CX-30 RGBW BRS Bedienungsanleitung

21 August 2024
Stairville

Stairville xBrick Quad 16×8W RGBW Bedienungsanleitung

21 August 2024
Stairville

Stairville PAR56 MKII Bedienungsanleitung

21 August 2024
Stairville

Stairville DDC-12 LCD Bedienungsanleitung

21 August 2024
Stairville

Stairville MH-x30 LED Beam Bedienungsanleitung

21 August 2024
Stairville

Stairville Quad Par Profile 5x8W RGB WW Bedienungsanleitung

21 August 2024
Stairville

Stairville LED Flood Panel 150 40° Bedienungsanleitung

21 August 2024
Stairville

Stairville CX-30 RGB WW Bedienungsanleitung

21 August 2024
Stairville

Stairville LED Power & DMX Bar Bedienungsanleitung

21 August 2024

Bedienungsanleitung Erleichterung

Neueste Bedienungsanleitung für -Kategorien-

Goobay

Goobay 30780 Bedienungsanleitung

16 Oktober 2024
AFX

AFX Grace GRCP07CBBK Bedienungsanleitung

13 Oktober 2024
AFX

AFX Point PNTP0107L30D1BK Bedienungsanleitung

13 Oktober 2024
Smartwares

Smartwares 20.003.54 Bedienungsanleitung

9 Oktober 2024
Neewer

Neewer TL97C Bedienungsanleitung

8 Oktober 2024
Neewer

Neewer SRP18C Bedienungsanleitung

8 Oktober 2024
Qtx

Qtx Moonglow Bedienungsanleitung

7 Oktober 2024
Blumfeldt

Blumfeldt Shinecube XL Bedienungsanleitung

7 Oktober 2024
Qtx

Qtx HPWash100 Bedienungsanleitung

6 Oktober 2024
BeamZ

BeamZ DJ X5 Bedienungsanleitung

5 Oktober 2024
